Archive Selection - ACRONIS BACKUP AND RECOVERY 10 ADVANCED SERVER SBS EDITION - UPDATE 3 User Manual

Select volumes to mount and configure the mount settings for every volume: assign a letter
or enter the mount point, choose the read/write or read only access mode.
When you complete all the required steps, click OK to mount the volumes.
6.5.1

Archive selection

Selecting the archive
1. Enter the full path to the location in the Path field, or select the desired folder in the folders tree.

If the archive is stored in Acronis Online Backup Storage, click Log in and specify the
credentials to log in to the online storage. Then expand the Online backup storage group and
select the account.
Exporting and mounting are not supported for backups stored in Acronis Online Backup Storage.
 If the archive is stored in a centralized vault, expand the Centralized group and click the
vault.

If the archive is stored in a personal vault, expand the Personal group and click the vault.

If the archive is stored in a local folder on the machine, expand the Local folders group and
click the required folder.
If the archive is located on removable media, e.g. DVDs, first insert the last DVD and then insert the discs in
order starting from the first one when the program prompts.
 If the archive is stored on a network share, expand the Network folders group, then select
the required networked machine and then click the shared folder. If the network share
requires access credentials, the program will ask for them.
Note for Linux users: To specify a Common Internet File System (CIFS) network share which is mounted on a
mount point such as /mnt/share, select this mount point instead of the network share itself.
 If the archive is stored on an FTP or SFTP server, type the server name or address in the Path
field as follows:
ftp://ftp_server:port _number or sftp://sftp_server:port number
If the port number is not specified, port 21 is used for FTP and port 22 is used for SFTP.
After entering access credentials, the folders on the server become available. Click the
appropriate folder on the server.
You can access the server as an anonymous user if the server enables such access. To do so,
click Use anonymous access instead of entering credentials.
According to the original FTP specification, credentials required for access to FTP servers are transferred
through a network as plaintext. This means that the user name and password can be intercepted by an
eavesdropper using a packet sniffer.

If the archive is stored on a locally attached tape device, expand the Tape drives group, then
click the required device.
When operating on a machine booted with bootable media:
 To access a managed vault, type the following string in the Path field:
bsp://node_address/vault_name/
 To access an unmanaged centralized vault, type the full path to the vault's folder.
2. In the table to the right of the tree, select the archive. The table displays the names of the
archives contained in each vault/folder you select.
