10. OPTIONAL SA-K97U RS-232C INTERFACE BOARD
10-3. SA-K97U RS-232C Protocol & Commands
This section provides technical data for programmers.
Command description
To use the commands described in the following pages, prepare the VCR for communications as follows:
Transmit the command "JVC TABLE 1 ON" (F6H) to the VCR. The VCR will return "ACK" (0AH).
The VCR can now receive any command described in this section. To cancel the communications mode, transmit the command "JVC
TABLE 1 OFF" (F7H).
2-1 VCR control commands
Commands (1) through (12) are 1-byte commands. The VCR will return "ACK" (0AH) when the command is received. Confirm that "ACK"
(0AH) has been returned before transmitting the next command.
(1) OPERATE ON (7BH)
OPERATE OFF (7CH)
(2) PLAY (3AH)
(3) STILL (4FH)
(4) STOP (3FH)
(5) FF (ABH)
(6) REW (ACH)
(7) REV PLAY (4AH)
(8) TIMER ON (60H)
TIMER OFF (61H)
(9) OPE LOCK ON (69H)
OPE LOCK OFF (6AH)
(10) EJECT (A3H)
(11) F-FIELD STEP (ADH)
(12) REC CHECK (C1H)
Before transmitting either of the following commands ((13) or (14)), first transmit REC/DUB REQUEST (FAH), and confirm that "ACK" is
returned by the VCR.
(13) REC (CAH)
(14) REC PAUSE (CBH)
However, if the loaded cassette's safety tab has been removed, recording is not possible regardless of the fact that "ACK" has been
returned. Use the STATUS SENSE (D7H) command to confirm tape status. (See Section 2-3 (9)).
After transmitting commands VISS FWD (15) or VISS REV (16), transmit the appropriate numeric data (1-byte ASCII codes from 30H to 39H)
and the data input command (40H).
ASCII codes "30H – 39H" correspond with the numbers "0 – 9" (ie.: 0: 30H, 1: 31H, ... 9: 39H).
Each byte of numeric data and the data input command should be transmitted separately with "ACK" (0AH) confirmation from the VCR after
each transmission. The VCR's Menu switch <INDEX SEARCH> is set to OFF.
(15) VISS FWD (B0H)
(16) VISS REV (B1H)
Eg: To search for the 3rd alarm-input point from the current position.
TXD
B0H
0AH
RXD
The VCR starts INDEX search after returning "ACK". When the specified point is reached, the VCR returns COMPLETION (01H). If the end
or beginning of the tape is reached before the specified point, the VCR returns NOT TARGET (05H). (Sending either the 30H,30H or
30H,31H command will cause the VCR to search for the 1st alarm-input point).
48
: VCR operating mode is turned "ON".
: VCR operating mode is turned "OFF".
: Playback
: Pause/Still
: Stop
: FF/Forward search in the Play mode. (INDEX Search when Menu switch <INDEX SEARCH> is set
to ON.)
: REW/Reverse search in the Play mode. (INDEX Search when Menu switch <INDEX SEARCH> is
set to ON.)
: Reverse playback at normal speed
: Timer "ON"
: Timer "OFF"
: Operation lock "ON"
: Operation lock "OFF"
: Cassette ejection
VCR returns "ACK", and then returns CASSETT OUT (03H) after cassette has been ejected.
: Engages field advance when the VCR is in the Still mode. The tape is advanced by one field in the
Timelapse mode.
If the VCR is in any other mode, the Still mode is engaged.
: Engages REC CHECK. (function is the same as when locally controlled on the VCR.)
: Starts recording. The VCR returns "ACK".
: Engages Record-Pause mode. The VCR returns "ACK".
• To re-start recording, transmit REC (FAH+CAH).
• To cancel Record-Pause, transmit STOP (3FH). The VCR will enter the Stop mode.
: To advance the tape in the forward search mode to the designated alarm-input point. The alarm
point's 2-byte numeric data should be input after transmission of this command.
: To reverse the tape in the reverse search mode to the designated alarm-input point. The alarm
point's 2-byte numeric data should be input after transmission of this command.
30H 33H
0AH 0AH
40H
0AH
Search start
Time
01H (or 05H)
