- Page 1 PORTABLE FORCED AIR HEATERS OWNER’S MANUAL Models: D20H, D30H, and D44H IMPORTANT: Read and understand this manual before assembling, start- ing or servicing heater. Improper use of heater can cause serious injury. Keep this manual for future reference.
-
Page 2: Safety Information
D20H, D30H AND D44H MODELS PORTABLE FORCED AIR HEATERS SAFETY INFORMATION WARNINGS IMPORTANT: Read this Owner’s Manual carefully and completely before trying to assemble, oper- ate, or service this heater. Im- proper use of this heater can cause serious injury or death from burns, fire, explosion, electrical... -
Page 3: Product Identification
PRODUCT IDENTIFICATION Hot Air Outlet Upper Shell Lower Shell Fuel Tank Side Cover ON/OFF Switch Figure 1 - D20H Model Hot Air Outlet Lower Shell Fuel Cap Side Cover Figure 2 - D30H and D44H Models 105843 OWNER’S MANUAL Fan Guard... -
Page 4: Tools Needed
(rear) of heater is over wheels. Line up holes on fuel tank flange with holes on wheel support frame. 4. For D20H model, place rear handle on top of fuel tank flange. For D30H and D44H models, place front handle and rear handle on top of fuel tank flange. -
Page 5: Theory Of Operation
10 seconds (2 minutes if heater has been running). 2. Repeat steps under To Start Heater. ON/OFF Switch Cool Figure 5 - ON/OFF Switch, D20H Model Output Filter ON/OFF Switch Figure 6 - ON/OFF Switch, D30H and... -
Page 6: Storing, Transporting, Or Shipping
D20H, D30H AND D44H MODELS PORTABLE FORCED AIR HEATERS STORING, TRANSPORTING, OR SHIPPING If shipping, transport companies re- Note: quire fuel tanks to be empty. 1. Drain fuel tank. Note: Some models have drain plug on underside of fuel tank. If so, remove drain plug to drain all fuel. -
Page 7: Troubleshooting
TROUBLESHOOTING FAULT CONDITION Motor does not start five seconds after heater is plugged in Motor starts and runs but heater does not ignite Heater ignites but ignition control assembly shuts heater off after a short period of time 105843 OWNER’S MANUAL WARNING: Never service heater while it is plugged in, operating, or hot. -
Page 8: Service Procedures
Guard Figure 7 - Upper Shell Removal, D20H Model Fuel Filter Side Cover Figure 9 - Fuel Filter Removal, D20H Model Fuel Filter, Bushing, and Lower Fuel Line Side Cover Figure 10 - Fuel Filter Removal, D30H and D44H Models... - Page 9 SERVICE PROCEDURES Continued IGNITOR 1. Remove upper shell and fan guard (see page 8). 2. Remove fan (see page 13). 3. Remove 4 side cover screws with a 5/16" nut driver. Remove side cover (see Figure 9 or 10, page 8). 4.
- Page 10 filter end cover. Air Intake Filter Lint Filter Air Output Filter Figure 13 - Air Output, Air Intake, and Lint Filters, D20H Model Air Intake Filter Lint Filter Air Output Filter Figure 14 - Air Output, Air Intake, and Lint Filters, D30H and D44H Models...
- Page 11 8) and the other end to nozzle adapter (see Figure 17, 18,or 19). Route air and fuel line approximately as shown. For D20H model heater, see Figure 17. For D30H model heater, see Figure 18. For D44H model heater, see Figure 19.
-
Page 12: Pump Rotor
15. Reinstall insert and rotor. 16. Perform steps 10 through 12 above. Blade Insert Rotor Air Output Filter Figure 23 - Rotor Location, D20H Model Insert Rotor Air Output Filter Figure 24 - Rotor Location, D30H and D44H Models Gap Adjusting... -
Page 13: Specifications
SERVICE PROCEDURES Continued IMPORTANT: Remove fan from motor shaft before removing motor from heater. The weight of the motor resting on the fan could damage the fan pitch. 1. Remove upper shell (see page 8). 2. Use 1/8" allen wrench to loosen set- screw which holds fan to motor shaft. -
Page 14: Illustrated Parts Breakdown
D20H, D30H AND D44H MODELS PORTABLE FORCED AIR HEATERS ILLUSTRATED PARTS BREAKDOWN D20H MODEL 12-1 12-2 12-18 12-17 12-16 Motor and Pump Assembly 12-3 12-4 12-5 12-6 12-7 12-15 12-14 12-12 12-8 12-9 12-13 12-10 12-19 12-11 105843... -
Page 15: Parts List
PARTS LIST D20H MODEL PART NUMBER DESCRIPTION 105793-01 ON/OFF Switch M50901-02BT Upper Shell 079919-01 Switch Cover 102432-01 Screw/Lockwasher, 1/2" 098512-64 Combustion Chamber M10908-2 Screw, #6-32 x 3/8" 103154-03 Photocell Bracket M16656-23 Photocell Assembly Burner Strap Assembly 100735-25 Nozzle Assembly 102548-05... - Page 16 D20H, D30H AND D44H MODELS PORTABLE FORCED AIR HEATERS ILLUSTRATED PARTS BREAKDOWN D30H MODEL 10-1 10-2 10-3 10-4 10-17 10-16 10-15 10-13 Motor and Pump Assembly 10-5 10-6 10-7 10-8 10-9 10-14 10-13 10-12 10-10 10-11 105843...
- Page 17 This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the PARTS LIST correct model and serial numbers (from the model plate), then the part number and description of the desired part. D30H MODEL PART NUMBER DESCRIPTION...
- Page 18 D20H, D30H AND D44H MODELS PORTABLE FORCED AIR HEATERS ILLUSTRATED PARTS BREAKDOWN D44H MODEL 10-1 10-2 10-3 10-4 10-17 10-16 10-15 10-18 Motor and Pump Assembly 10-5 10-6 10-7 10-8 10-9 10-14 10-13 10-12 10-10 10-11 105843...
- Page 19 This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the PARTS LIST correct model and serial numbers (from the model plate), then the part number and description of the desired part. D44H Model PART NUMBER DESCRIPTION...
-
Page 20: Wheels And Handles
D20H, D30H AND D44H MODELS PORTABLE FORCED AIR HEATERS WHEELS AND HANDLES D20H Model KEY PART ACCESSORIES Purchase accessories from your local dealer. AIR GAUGE KIT - HA1180 For all models. Special tool to check pump pressure. PART NUMBER DESCRIPTION... -
Page 21: Ec Conformity Declaration
3004 ED Rotterdam Holland Manufacturer: DESA International, Inc. 2701 Industrial Drive Bowling Green, KY 42101 U.S.A. Kerosene Portable Forced Air Heaters Model Numbers: D20H, D30H, and D44H DESA International, Inc. Vice President, Specialty Products Engineering OWNER’S MANUAL Douglas D. Rohrer Signature... -
Page 22: Warranty Information
DESA International, or any alteration or repair by others in such manner as in DESA International's judgement affects the Product materially and adversely, shall void this Warranty.
