For many operating systems you can install and run HP Library & Tape Tools from the
HP StorageWorks Tape CD-ROM to check your server's current SCSI configuration (see
"HP Library & Tape
the SCSI IDs in use.
The UNIX Configuration Guide on the HP StorageWorks Tape CD-ROM also contains instructions on
how to determine the SCSI IDs of existing devices on UNIX servers.
2.
Change the tape drive's SCSI ID, if necessary.
The SCSI ID is set using jumpers on a set of pins at the rear of the drive, as shown in figure 3. Use
tweezers or small pliers to move the jumpers to the pattern corresponding to the ID you want. Do not
remove the TP jumper. It should always be set.
NOTE:
Spare jumpers will be attached to the drive. The drive is supplied with compression
enabled. It can be disabled by removing the compression jumper, but this is not generally
recommended. For further details, refer to the
StorageWorks Tape CD-ROM.

Prepare mounting bay

CAUTION:
To avoid personal injury or damage to the server or tape drive, ensure that the server is disconnected
from the mains power supply while you install the drive.
1.
Assemble the necessary tools and materials:
• Phillips screwdriver
• Flat-bladed screwdriver (if your server uses slotted screws)
• Torx screwdriver (if your server uses torx screws)
• Your server manuals (for reference during installation)
2.
Perform a normal system shutdown and turn off the server and any connected peripherals.
3.
Remove the cover and front panel from the server, as detailed in your server's documentation.
As you work inside the server, you may have to disconnect other signal cables or power cables from
other devices to maneuver the new drive into place. If you have to do this, make a note of their
position and connections so you can put them back correctly later.
20
Installing an internal DAT tape drive
Tools" on page 55). This will provide information about the SCSI bus and
UNIX Configuration Guide
on the HP
