- Page 1 ® UPER The SC513 -L420 Series & the SC513-L260 Series SC513 CHASSIS USER'S GUIDE...
- Page 2 The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product. Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not copy any part of this document.
-
Page 3: Table Of Contents
Chapter 1: Safety Information and Technical Specifications Table of Contents Chapter I: Safety Information and Technical Specifications ..1-4 1-1. Electrical Safety Guidelines ............. 1-4 1-2. General Safety Guidelines ............... 1-5 1-3. ESD Safety Guidelines ............... 1-6 1-4. Operation Safety Guidelines ............1-6 1-5. -
Page 4: Chapter I: Safety Information And Technical Specifications
SC513 Chassis User’s Guide Chapter 1-Safety Information and Technical Specifications 1-1 Electrical Safety Guidelines Warning: To avoid electrical shock, check the power cords as follows: Checking the Power Cords !Use the exact type of power cords as required. !Be sure to use the power cord(s) that came with safety certifications. !The power cord(s) must be compliant with the AC voltage requirements in your region. -
Page 5: General Safety Guidelines
Chapter 1: Safety Information and Technical Specifications Use rubber mats specifically designed as electrical insulators when working with computer systems. The power supply or power cord must include a grounding plug and must be plugged into grounded outlets. Motherboard Battery: CAUTION -Make sure not to install the onboard battery upside down to avoid possible explosion. -
Page 6: Esd Safety Guidelines
SC513 Chassis User’s Guide 1-3 ESD Safety Guidelines Electric Static Discharge (ESD) can damage electronic com- ponents. To prevent damage to your system board, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. Use a grounded wrist strap designed to prevent static discharge. - Page 7 Chapter 1: Safety Information and Technical Specifications STOP To avoid personal injury and property damage, please carefully follow all the safety steps listed below: Before accessing the chassis: 1. Turn off all peripheral devices connected to the SC513. 2. Press the power button to power off the system. 3.
-
Page 8: Product Compliance Information
6. The rack assembly must provide sufficient airflow to the chassis for proper cooling. 1-5 Product Compliance Information If integrated with a motherboard validated and recommended by Supermicro, and configured based upon the instructions outlined in this manual, the SC513 Chassis is compliant with the following safety standards/requirements: Product Safety... -
Page 9: Packing List And The Sc513 Specifications
Chapter 1: Safety Information and Technical Specifications 1-6 Packing List and the SC513 Specifications A. The SC513 chassis contains the following: The SC513L-260 Series: Component Part Number Blower FAN-0059 The SC513L-420 Series: Component Part Number FAN-0078 B. The Accessory Kit The Accessory Kit contains the following: Component Quantity... - Page 10 SC513 Chassis User’s Guide C. Power Supply Specifications of the SC513 Power supply spec 260W 420W Mfr. Model# SP262-1S SP423-1S Mfr. Part# PWS-0055 PWS-0053 Rated AC input voltage 100-240V AC 100-240V AC Rated input frequency 50-60 Hz 50-60 Hz Rated input current 5A MAX 7A MAX Rated output power...
-
Page 11: Chapter 2: Chassis Description And Installation Procedures
Chapter 2: Chassis Description and Installation Instructions Chapter 2: Chassis Description and Installation Instructions 2-1 Chassis Description A. Contents of the Accessory Kit: The following items are included in the Accessory Kit: A. Pan head w/ lock 6-32 x 4.5 mm [0.177] DRIVE D. -
Page 12: Chassis Front View And The Front Control Panel
SC513 Chassis User’s Guide C. Chassis Front View and the Front Control Panel Chassis Front View 1. Front Panel and I/O Device Definitions 1. Front Panel LED Indicators 3A. Two 2.5" Drives (*SC513L-420) 2. I/O Devices 3B. One 3.5" Drive (*SC513L-260) Front Panel LED Indicators LED Button Definitions 1A. - Page 13 Chapter 2: Chassis Description and Installation Instructions Front Control Panel LED Button Descriptions /(' %XWWRQ &RORU &RQGLWLRQ 'HVFULSWLRQ 3RZHU *UHHQ 2Q 6\VWHP 2Q 6\VWHP 2II $PEHU %OLQN +'' $FWLYLW\ 1R $FWLYLW\ /$1 /$1 *UHHQ 2Q /LQNHG %OLQN /$1 $FWLYLW\ 'LVFRQQHFWHG 2YHUKHDW 6\VWHP 2YHUKHDW 6\VWHP 1RUPDO...
- Page 14 SC513 Chassis User’s Guide D. Chassis Rear View SC513 Chassis Rear View...
-
Page 15: Chassis Installation
Chapter 2: Chassis Description and Installation Instructions 2-2 Chassis Installation A. Important Safety Guidelines STOP This product shall only be accessed, assembled and serviced by technically qualified personnel or technicians. To avoid personal injury and property damage, please read all the information provided in Chapter 1, and carefully follow all the Safety Guidelines listed before accessing or servicing the SC513 or its components. -
Page 16: Removing The Top Chassis Cover And The Hdd Tray Bracket
SC513 Chassis User’s Guide C. Removing the Top Chassis Cover and the HDD Tray Bracket from the chassis Before installing a hard drive into the chassis, you need to remove the (*Note: Removing top cover and the HDD tray bracket from the chassis. the top cover when the system is running will degrade thermal performance.) Procedures... -
Page 17: Removing The Hdd Drive Tray Housing And Installing A Hdd
Chapter 2: Chassis Description and Installation Instructions D. Removing the HDD Drive Tray Housing and Installing Hard Disks After the HDD Drive Tray Bracket is removed from the chassis, you can install HDDs into the HDD Drive Housing. Procedures 1. Remove the four screws on each side of HDD Tray Bracket as shown in the picture. -
Page 18: E Installing The Motherboard
SC513 Chassis User’s Guide E. Installing the Motherboard Be sure to disconnect the power supply before accessing or installing the mother- board into the chassis. (Refer to Chapter 1 for Safety Guidelines.) Procedures 1. Lay the chassis on a flat surface. 2. -
Page 19: Installing And Un-Installing The Heatsink Mechanism
Chapter 2: Chassis Description and Installation Instructions F. Installing and Un-installing the Heatsink Mechanism Heatsinks are heavy. Please handle with care!! *Note: Be sure to use Heatsink (# SNK-P0011) for a UP system, and use Heatsink (#SNK-P0007) for a DP System. Procedures: Heatsink Installation 1. -
Page 20: Removing And Installing The Front Bezel
SC513 Chassis User’s Guide G. Removing and Installing the Front Bezel To access the front panel, you will need to remove the front bezel from the chassis. Be sure to install the front bezel before operating the system. Procedures (-Removing the front bezel) 1. -
Page 21: H-1. Installing The Cooling Fan Module And The Air Shroud
Chapter 2: Chassis Description and Installation Instructions H-1. Installing the Cooling Fan Module and the Air Shroud for a DP System After the motherboard and the heatsink(s) have been installed in the chassis, you need to install cooling fans and an air shroud for proper system cooling. Procedures (*Installing the Cooling Fan Module for a DP System) 1. - Page 22 SC513 Chassis User’s Guide H-2. Installing the Blower and the Air Shroud for a UP System After the motherboard and the heatsink(s) have been installed in the chassis, you need to install cooling fans and an air shroud for proper system cooling. Procedures (*Installing the Blower for a UP System) 1.
- Page 23 Chapter 2: Chassis Description and Installation Instructions I. Installing the Chassis Inner Rails (*Optional for the SC513) (*Note: if your chassis does not come with chassis rails, please follow the procedure listed on the last page to install the SC513 directly into the rack.) Please make sure that the chassis covers and chassis rails are installed on the chassis before you install the chassis into the STOP...
- Page 24 SC513 Chassis User’s Guide 3. Locate the three holes on each side of the chassis and locate the three corresponding holes on each of the inner rail. 4. Attach an inner rail to each side of the chassis and secure the inner rail to the chassis by inserting three Type G screws through the holes on each side of the chassis and the inner rail.
-
Page 25: J-1. Rack Installation For The Traditional Up Design
Chapter 2: Chassis Description and Installation Instructions J-1 Rack Installation for the Traditional UP Design (*Optional for the SC513) After you have installed the inner rails on the chassis, you are ready to install the outer rails of rail assemblies to the rack. (* The rails are designed to fit in the racks with the depth of 28"... - Page 26 SC513 Chassis User’s Guide 7. Slide the SC513 chassis into the rack as shown below: (The SC513 may not slide into the rack smoothly or easily when installed the first time. However, some adjustment to the slide assemblies might be needed for easy installation.) 8.
-
Page 27: J-2. Rack Installation For The Open Rack Design
Chapter 2: Chassis Description and Installation Instructions J-2 Rack Installation for the Open-Rack Design (*Optional for the SC513) After you have installed the inner rails on the chassis, you are ready to install the outer rails of rail assemblies to the rack. (* The rails are designed to fit in the racks with the depth of 28"... - Page 28 SC513 Chassis User’s Guide 3. Attach the front (-short) bracket to the front end of the rack, and secure it to the rack with two Type H screws and Type I washers as shown below. 4. Attach the rear (-long) bracket to the rear end of the rack, and secure it to the rack with two Type H screws and Type I washers as shown below.
- Page 29 Chapter 2: Chassis Description and Installation Instructions 5. Measure the depth of your rack and adjust the length of the rails accordingly. Then, secure the rails to the chassis with Type G screws. 6. Slide the inner rails which are attached to the chassis into the outer rails on the rack.
-
Page 30: Installing The Sc513 Into The Racks
SC513 Chassis User’s Guide K. Installing the SC513 into the Racks (*Note: Please make sure that all components and all STOP chassis covers are properly installed in the chassis before you install the SC513 into the racks; otherwise, out-of warranty damage may occur.) Procedures 1.
