KEY
1) Cold start lever ( )
2) Multifunction computer
3) Ignition / steering lock switch ( -
4) Dimmer light switch (
nalling push button (
5) Horn push button (
6) High beam warning light (
7) Speedometer/odometer with trip counter
8) Neutral indicator warning light ( )
9) Mixer oil reserve warning light (
10) Turn indicator warning light (
11) Low beam warning light (
- )
- ) and high beam sig-
)
)
)
)
)
)
1 2
5
Fig. 20
6 7
11
Fig. 21
3
4
8 9
10
