Cub Cadet 521E Operator's Manual page 17

Model 521E
Ref. No. Part No.
1. 684-0054A Dash Assembly
2. 684-0126 Chute Crank Assembly
3. 710-1003 Special Screw: 310-16 x 0.375"
4. 710-1090 Hex Flange Screw 5/16-18 x 1.25"
5. 710-1268 Special screw
6. 710-1652 Self-Tapping Screw 1/4-20 x .625"
7. 712-3010 Hex Nut 5/16-18
8. 714-0104 Hairpin Clip
9. 714-0507 Cotter Pin
10. 715-0138 Roll Pin
11. 720-0201A Chute Crank Knob
12. 725-0201 Ignition Key
13. 725-1341B Ignition Key w/o Logo
14. 725-1346 Ignition Switch Nut
15. 725-1347 Ignition Switch Cap
16. 725-1425 Switch: Key, Recoil Start
17. 726-0100 Push Cap
18. 731-1089A Choke Cover
19. 731-1133B Spilling Cup
20. 731-2109 Shroud: 21" Beige
21.
735-0234 Rubber Grommet
22. 736-0119 Lock Washer
23. 736-0185 Flat Washer
24. 736-0225 Internal Lock Washer
25. 736-0451 Saddle Washer
26. 747-0697 Eyebolt
27. 747-0737 Upper Chute Crank
28. 750-0785 Spacer
29. 7510009636 Mitten Grip Handle
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Cub Yellow, the part number to
order would be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Cub Blue: 0685
Powder Black: 0637
Part Description
17
