Air conditioner
User manual
MWR-VH12N
• Thank you for purchasing this Samsung Product.
• Before operating this unit, please read this user manual carefully and retain it for future
reference.

Advertisement

Table of Contents
loading

Related Manuals for Samsung MWR-VH12N

Summary of Contents for Samsung MWR-VH12N

  • Page 1 Air conditioner User manual MWR-VH12N • Thank you for purchasing this Samsung Product. • Before operating this unit, please read this user manual carefully and retain it for future reference.

  • Page 2: Table Of Contents

    Contents Preparation Safety Precautions..................3 Basic function Name of each part.

  • Page 3: Safety Precautions

    Safety Precautions This content is intended to protect the user’s safety and prevent property damage. Please read it carefully for correct use of the product. Hazards or unsafe practices that may result in WARNING severe personal injury or death. Hazards or unsafe practices that may result in CAUTION minor personal injury or property damage.
  • Page 4 Safety Precautions Do not install this appliance near a heater, inflammable material. Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). Do not install this appliance in a location where gas may leak.
  • Page 5 To reinstall the air conditioner, please contact your nearest service center. Failing to do so may result in problems with the product, water leakage, electric shock, or fire. A delivery service for the product is not provided. If you reinstall the product in another location, additional construction expenses and an installation fee will be charged.
  • Page 6 Safety Precautions FOR OPERATION CAUTION Do not allow water to enter the product. This may result in fire or electric shock. Do not operate the appliance with wet hands. This may result in electric shock. Do not spray volatile material such as insecticide onto the surface of the appliance.

  • Page 7: Name Of Each Part

    Name of each part Display ⑧ ⑨ ⑦ ⑥ ① ⑤ ② ④ ③ Classification Indication Function ① Displays operation mode ② Displays set time ③ Displays Away mode ④ Displays filter cleaning alarm ⑤ Displays fan speed ⑥ Displays SPI (Optional) ⑦...
  • Page 8 Name of each part Buttons ⑤ ① ⑥ ② ③ ⑦ ④ Classification Button Function ① Power button Turns on or off the wired remote controller. ② Mode button Selects the mode you want to operate ③ Schedule button Sets the timer function. Completes the timer function/ ④...

  • Page 9: Basic Operation Of Erv

    Basic operation of ERV Press the Mode button to operate the basic operation. Heat-EX mode Collects cooling or heating energy generated by the indoor cooling or heating operation to reduce the energy loss during ventilation. By-Pass mode Intakes outdoor air directly into the indoor room. Auto mode Indoor air can be refreshed automatically depending on contamination level of indoor air.
  • Page 10 Basic operation of ERV Press the button to start ERV operation. Press the button to select operation mode. When all the options of ERV are selected, the operations like below become available. (Setting is available with installation of wired remote controller.) Press the button to adjust the fan speed.

  • Page 11: Away Operation

    Away operation Away mode enables the ERV to operate when you are out. Press the button to select the Away mode. The Away mode is cancelled if the operation mode is changed by another controller. When ERV stops operation, only 'Away' will be displayed. Fan speed is fixed as Low and it cannot be adjusted.

  • Page 12: On Timer Function

    On timer function When the ERV is turned off 1. Press the Timer button to set On time. When you press the Timer button one time, set time blinks. You can set the time in half hour unit from 30 minutes ~ 3 hours and hour unit from 3~24 hours with the ( ) and ( ) button.

  • Page 13: Delayed On Timer Function

    Delayed On timer function When the ERV is turned off 1. Press the Timer button to set delayed On time. When you press the Timer button one time, set time blinks. You can set the time in minute unit from 30 minutes to 1 hour with the ) and ( ) button.

  • Page 14: Delayed Off Timer Function

    Delayed Off timer function When the ERV is turned on 1. Press the Timer button to set delayed Off time. When you press the Timer button one time, set time blinks. You can set the time in minute unit from 30 minutes to 1 hour with the ) and ( ) button.

  • Page 15: Setting Additional Functions Of Erv Wired Remote Controller (Detailed Settings)

    Setting additional functions of ERV wired remote controller (Detailed settings) SEG used Main menu Sub menu Left and right Exit Up and down Set, Cancel 1. For detailed settings, press the button at the same time for more than 3 seconds.
  • Page 16 Setting additional functions of ERV wired remote controller (Detailed settings) Main Factory Function Page Range Remarks menu menu setting Reset to default value of user mode 0-Disuse, 1-Reset All lock 0-Unlock, 1-Lock Lock of operation On/Off key 0-Unlock, 1-Lock Lock of mode selection key 0-Unlock, 1-Lock Partial key lock...
  • Page 17 Example of locking all buttons 1. Press the buttons at the same time for more than 3 seconds. When main menu is displayed, press the button to select no.1. 2. Press the Away button to select the number you will set on the sub menu.
  • Page 18 (For India only) For more information on safe disposal and recycling, visit our website www.samsung.com/in/support or contact our Helpline numbers - 1800 40 SAMSUNG (1800 40 7267864) 1800 5 SAMSUNG (1800 5 7267864).
