Operator's Guide
15 HORSEPOWER
MODEL VERSION: "AB"
E15R4, E15RL4, E15TE4, E15TEL4, E15PL4
*216793*
216793

Advertisement

Table of Contents
loading

Related Manuals for BRP EVINRUDE E15R4

Summary of Contents for BRP EVINRUDE E15R4

  • Page 1 Operator’s Guide 15 HORSEPOWER MODEL VERSION: “AB” E15R4, E15RL4, E15TE4, E15TEL4, E15PL4 *216793* 216793...
  • Page 2 INJURY OR DEATH. KEEP THIS MANUAL IN A SAFE LOCATION FOR FUTURE REFERENCE. Copyright 2015 BRP US Inc. All rights reserved. No part of this manual may be reproduced or transmitted in any from or by any means without the expressed written permission of BRP...
  • Page 3 Be sure that the product has been checked by an authorized Evinrude dealer before you take delivery. Limited Warranty Please refer to the BRP Limited warranty provided to you with this product, the terms and conditions of which, as amended from time to time, are incorporated by reference into the manual.
  • Page 4 Product References, Illustrations and Specifications BRP reserves the right to make changes at any time, without notice, to features, specifications and model availability, and to change any specification or part at any time without incurring any obligation to update older models. The information in the Guide is based on the latest specifications available at the time of publication.
  • Page 5 ENOM00005-A Serial Number In the space below, please record the outboard motor's serial number (indicated both on the bottom cowl and on the cylinder block). The serial number will be needed when order- ing parts, and when making technical or warranty inquiries. Serial Number: ENOF01200-0 ENOF01201-0...
  • Page 6 ENOM00007-0 NOTICE: DANGER/WARNING/CAUTION/Note Before installing, operating or otherwise handling your outboard motor, be sure to thor- oughly read and understand this Owner's Manual and carefully follow all of the instruc- tions. Of particular importance is information preceded by the words “DANGER,” “WARNING,”...

  • Page 7: Table Of Contents

    CONTENTS 1. GENERAL SAFETY INFORMATION ....... 10 2. SPECIFICATIONS ..........12 3.
  • Page 8 11. TROUBLESHOOTING ......... . 79 12.
  • Page 9 INDEX 1 GENERAL SAFETY INFORMATION 2. SPECIFICATIONS 3. PARTS NAME 4. LABEL LOCATIONS 5. INSTALLATION 6. PRE-OPERATING PREPARATIONS 7. ENGINE OPERATION 8. REMOVING AND CARRYING THE OUTBOARD MOTOR 9. ADJUSTMENT 10. INSPECTION AND MAINTENANCE 11. TROUBLESHOOTING 12. TOOL KIT AND SPARE PARTS 13.

  • Page 10: General Safety Information

    GENERAL SAFETY INFORMATION ENOM00009-0 SAFE OPERATION OF BOAT As the operator/driver of the boat, you are responsible for the safety of those aboard and those in other boat around yours, and for following local boating regulations. You should be thoroughly knowledgeable on how to correctly operate the boat, outboard motor, and accessories.
  • Page 11 GENERAL SAFETY INFORMATION ENOM00010-0 SERVICING, REPLACEMENT PARTS & LUBRICANTS We recommend that only an authorized service shop perform service or maintenance on this outboard motor. Be sure to use genuine parts, genuine lubricants, or recommended lubricants. ENOM00011-A MAINTENANCE As the owner of this outboard motor, you should be acquainted with correct maintenance procedures following maintenance section of this manual (See page 56).

  • Page 12: Specifications

    SPECIFICATIONS ENOM00301-BR MODEL Item Overall Length mm (in) 1055 (41.5) Overall Width mm (in) 365 (14.4) Overall Height S·L·UL mm (in) 1085 (42.7) 1325 (48.6) 1362 (53.6) Transom Height S·L·UL mm (in) 413 (16.3) 562 (22.1) 669 (27.1) S kg (lb) 52 (115) 55.5 (122) 62.5 (138)
  • Page 13 SPECIFICATIONS ENOM00302-BR MODEL Item Overall Length mm (in) 640 (25.2) Overall Width mm (in) 350 (13.8) Overall Height S·L·UL mm (in) 1085 (42.7) 1235 (48.6) 1362 (53.6) Transom Height S·L·UL mm (in) 413 (16.3) 562 (22.1) 689 (27.1) S kg (lb) 54.5 (120) 61.5 (136) Weight...

  • Page 14: Parts Name

    PARTS NAME ENOM00303-BR R, TE, E, TP, P ENOF01202-0 Tilt Handle Drive Shaft Housing Water Plug Top Cowl Thrust Rod Oil Plug (Upper) (Level) Bottom Cowl Clamp Bracket Oil Plug (Lower) (Fill) Cooling Water Check Port Clamp Screw Oil Filter Power Tilt Switch Throttle Grip Spark Pulg...
  • Page 15 PARTS NAME R, TE, E, TP, P Power Tilt Type ENOF01203-A Primer Bulb Cord Assembly Fuel Tank Cap Engine Stop Switch Cord Air Vent Screw Power Tilt Switch Fuel Connector *4: Power tilt, tiller handle type only. *5: Remote control type only. Fuel Pick up Elbow Fuel Tank Clamp Screw...

  • Page 16: Label Locations

    LABEL LOCATIONS ENOM00019-A Warning label locations 3, 4 ENOF01204-A...
  • Page 17 LABEL LOCATIONS Warning label urge to read the owner’s Warning label regarding oil pressure manual . (See page 29). ENOF00131-0 Warning label regarding position of outboard motor when setting down. ENOF00006-0 For RC model ENOF00005 0 Warning label regarding stop switch 2-1.
  • Page 18 LABEL LOCATIONS Warning regarding fuel tank cap (See Warning tag regarding instructions of page 26). the fuel tank cap (See page 26). ENOF00012-0 Warning tag regarding combination of fuel tank and primer bulb ass'y (See ENOF00011-0 page 32). Warning regarding of fuel connector (See page 26).
  • Page 19 0 MANUFACTURE NAME q MODEL YEAR AND MONTH EPA Emissions Regulations trol Information decal as permanent evi- Outboards sold by BRP US Inc. in the dence of EPA certification. United States are certified to the United States Environmental Protection Agency...

  • Page 20: Installation

    INSTALLATION ENOM00024-A Do not operate the outboard motor until it has been securely mounted on the boat in 1. Mounting the outboard motor on accordance with the instructions below. boat ENOW00009-0 ENOW00006-B WARNING WARNING  Mounting the outboard motor without Before installing the outboard motor on the following this manual can lead to unsafe boat, hang the outboard motor with the...
  • Page 21 INSTALLATION ENOM00025-0 water surface is near the bottom cowl- Position ... Above keel line ing, in high waves, water may enter the Set engine at center of boat. engine cylinders.  Incorrect outboard motor mounting height or existence of underwater object(s), such as hull bottom design, bottom surface conditions or underwa- ter accessories, can cause water spray...

  • Page 22: Remote Control Device Installation

    INSTALLATION ENOW00008-A PTT type CAUTION 1. To attach the outboard motor to the  Mounting bolts should be installed with boat, use the bolts to secure the out- the bolt head at inside surface of the board motor brackets on transom transom.

  • Page 23: Battery Installation

    INSTALLATION ENOW00850-0 Connect the remote control cable to the Remote control box location engine, then run the cable to the remote control box, making sure it is not sharply bent, too taut and free from obstructions that could interfere with steering. ENOM00029-A 1, 2 3.

  • Page 24: Altitude Adjustment Kit Installation

    ENON00006-A Note and decrease fuel efficiency and perfor- mance. Contact authorized BRP dealer Recommended battery: 12V 70AH/5HR, 650 (Cold Cranking Amps (CCA), In case of more detail. cold whether: 12V100AH/5HR (850CCA)) Specifications and features of batteries vary among the manufacturers.

  • Page 25: Pre-Operating Preparations

    PRE-OPERATING PREPARATIONS ENOM00030-A these adverse effects are caused because 1. Fuel handling the ethanol in the gasoline can absorb moisture from the air, resulting in a separa- ENOW000017-0 tion of the water/ethanol from the gasoline in the fuel tank. CAUTION These may cause increased: Use of improper gasoline can damage your ...

  • Page 26: Fuel Filling

    PRE-OPERATING PREPARATIONS has washed protective oil films from inter- When or before refueling:  Be sure to remove the static electricity nal components. charged in your body before refueling.  The sparks due to static electricity may ENOW00018-0 cause explosion of flammable gasoline. WARNING ...

  • Page 27: Engine Oil Recommendation

    PRE-OPERATING PREPARATIONS properly fill the engine with oil follow the instructions, See page 58) ENOF00421-0 1. Air vent screw 2. Tank cap 2. Loosen the tank cap until it contacts ENOF01209-0 the tab lock and release internal pres- sure completely. After that, press Use only high quality 4-stroke engine oil to down the tab lock and open the tank insure performance and prolonged engine...

  • Page 28: Break-In

    PRE-OPERATING PREPARATIONS ]ENOM00033-A 4. Break-In  Keep peripheral area well ventilated. Your new outboard motor and lower unit  Always attempt to stay on the windward require break-in for the moving compo- side of emission. n e n t s a c c o r d i n g t o t h e c o n d i t i o n s described in the following time table.

  • Page 29: Warning System

    PRE-OPERATING PREPARATIONS ENOM00039-0 1. Warning lamp 5. Warning system If outboard motor encounters an abnormal condition of fault, the warning horn will emit a continuous beep or intermittent short beeps and the warning lamp (LED) will synchronize with the horn and engine speed will be limited (engine will not be stopped).
  • Page 30 PRE-OPERATING PREPARATIONS ENOM00041-D Warning indicators, faults and remedy Warning indicators Description of faults Remedy Sound Lamp (LED) On for several Normal system test when start up sec. Engine speed exceeds maximum High speed ESG allowable RPM Continuous Low speed ESG Low oil pressure Remarks *1: In this case, oil pressure switch is “ON”.
  • Page 31 PRE-OPERATING PREPARATIONS Remedy Reduce the throttle to less than half opening, and move to safe place quickly, and stop the engine. Check the propeller for bent or dam- aged blades. Consult an authorized dealer if engine shows the same result even after replacing propeller with new one.

  • Page 32: Engine Operation

    ENGINE OPERATION ENOM00042-0 case the cap is loosened by using another procedure when internal pressure of fuel Before starting tank is raised by heat from sources such as sun light. ENOW00022-A CAUTION ENOW00030-B WARNING The engine oil is drained for shipping from the factory.

  • Page 33: Starting The Engine

    ENGINE OPERATION 1. Full open the air vent screw on the fuel tank cap. ENOF00861-A 1. Pull 2. Insert 4. Squeeze primer bulb until it becomes ENOF00421-0 stiff to feed fuel to vapor separator. 1. Air vent screw 2. Fuel tank cap Direct arrow mark upward when prim- ing.
  • Page 34 ENGINE OPERATION And be sure to remove the propeller, when ENON00010-0 Note starting the engine in the test tank. (See page 68) Start-in-gear protection prevents engine Run the engine only at idling. from starting at other than neutral shift. In- gear starting of engine will move the boat immediately, potentially leading to falling down or causing passenger(s) to be thrown...
  • Page 35 ENGINE OPERATION 3. Set the throttle grip to START position. 5. Pull the starter handle slowly until you feel engagement, keep pulling till you feel less resistance. Then pull it quickly. repeat if necessary until started. ENOF01107-0 1. Throttle grip 4.
  • Page 36 ENGINE OPERATION ENOF01212-0 Side mount RC type ENOF00870-0 1. Be sure to install the stop switch lock 1. Neutral (N) 2. Control lever to the stop switch, and attach the stop 3. Fully open (Forward) switch lanyard securely to the operator 4.
  • Page 37 ENGINE OPERATION 7. Returns the Free accel lever to close cover and the top cowl after the engine has been started. position.  Do not pull starter rope if any bystander 8. Confirm warning lamp light up and is behind. The action can injure the then go off after engine has started.
  • Page 38 ENGINE OPERATION 3. Remove the bolts (5pcs) and remove ENOW00860-0 the recoil starter. CAUTION Be sure to keep the harness away from the rotation parts. 6. Be sure to install the stop switch lock to the stop switch, and attach the stop switch lanyard securely to the operator or to the operator's PFD (Personal Flo- tation Device.)

  • Page 39: Warming Up The Engine

    ENGINE OPERATION engine without warm up shortens the engine's life. ENOF01212-0 ENOF00320-0 ENOM00044-0 Engine speeds Idling speed after warming up. Remark: In case of cold engine starting, idling speed is increased about 400 rpm for several minutes. Clutch in (In gear) Clutch off (Out of gear) 900 rpm 950 rpm...
  • Page 40 ENGINE OPERATION  Do not attach the tether to a part of ENOW00863-0 clothing that can be torn easily when CAUTION pulled.  Arrange the tether so that will not be Idle speed may be higher during warming caught by any object when pulled. up of engine.
  • Page 41 ENGINE OPERATION 1. Throttle grip ENOM0900-0 Side mount RC type ENOW00867-0 WARNING Sudden acceleration and deceleration may cause passenger(s) to be thrown over- board or falling down. ENOF01210-0 1. Shift lever Forward 1. Turn the throttle grip to reduce engine speed.

  • Page 42: Stopping The Engine

    ENGINE OPERATION Reverse Tiller handle type 1. Turn the throttle grip to the slow posi- 1. Quickly pull the control lever to the tion. Reverse (R) position at 32°, where the gear is connected, while lifting up on the lock button located under the con- trol lever grip.
  • Page 43 ENGINE OPERATION ENOF00881-0 ENOF00314-C 2. Turn the main switch key to the OFF 1. Stop switch position or push the stop switch. ( Do 2. Stop switch lock not forget to turn the key off). START ENOF00884-0 1. Stop switch ENOF00882-0 2.

  • Page 44: Steering

    ENGINE OPERATION ENOF00891-0 ENOM00920-0 6. Steering ENOW00870-0 ENOF00893-0 WARNING ENOM00050-0 7. Trim angle Sudden steering may cause passenger(s) to be thrown overboard or falling down. ENOW00043-A Tiller handle type WARNING Right turn Move the tiller handle to the left  Adjust the trim angle when the engine is stopped.
  • Page 45 ENGINE OPERATION ate the switch during cruising, or control of boat may be lost. The trim angle of the outboard motor can be adjusted to suit the transom angle of the hull, and load conditions. Choose an appropriate trim angle that will allow the anti-ventilation plate to run parallel to the ENOF00053-0 water surface during operation.

  • Page 46: Tilt Up And Tilt Down

    ENGINE OPERATION Trim angle adjustment (Manual tilt 4. Change the trim lock pin position as type) following picture. The transom angle adjustment 1. Stop the engine. 2. Shift into neutral. 3. Raise the outboard motor to the tilt up position. 4.
  • Page 47 ENGINE OPERATION ENOW00056-A WARNING When tilting up outboard motor with fuel joint for over a few minutes, be sure to dis- connect fuel hose, or fuel may leak, poten- tially catching fire. ENOW00057-0 CAUTION Do not tilt up outboard motor while engine ENOF01216-0 operates, or no cooling water may be fed, leading to engine seizure due to overheat-...
  • Page 48 ENGINE OPERATION ENOM00069-A The outboard motor can also be tilted up Power Tilt type and down using the switch provided under Tilt up the bottom cowl. 1. Operate the Power Tilt switch and tilt the outboard motor up. 2. Lock the tilt with the Tilt stopper after the outboard motor has been tilted up Tilt down 1.

  • Page 49: Shallow Water Operation

    ENGINE OPERATION through water inlet and sub-water inlet, potentially leading to engine overheating. ENOF01144-0 1. Water inlet 2. Sub-water inlet ENOF00326-0 Manual tilt type 1. Power 1. Shallow water running position: 2. Manual Put the reverse lock lever in the tilt up position, and tilt up the outboard motor ENOM00068-A to put the outboard motor in the shal-...
  • Page 50 ENGINE OPERATION ENOF00059-0 1. Reverse lock lever 2. Tilt up position 3. Tilt down position ENOM00069-A Power Tilt type 1. Operate the Power Tilt switch and tilt the outboard motor up into desired shallow water running position. ENOF00343-A ENOF00067-0...

  • Page 51: Removing And Carrying The Outboard Motor

    REMOVING AND CARRYING THE OUTBOARD MOTOR ENOM00070-A 1. Removing the outboard motor ENOW00890-0 WARNING Before installing the outboard motor on the boat, hang the outboard motor with the hoist or equivalent device by attaching the engine hanger to the outboard. Use the hoist with allowable load is 150 kg (330 lbs) or above.

  • Page 52: Traillering

    REMOVING AND CARRYING THE OUTBOARD MOTOR  Do not carry or store outboard motor in then the port side faces down as shown any of positions described below. in the drawing above.  Elevate power unit 2 inches to 4 inches if Otherwise, engine damage or property damage could result from leaking oil.
  • Page 53 REMOVING AND CARRYING THE OUTBOARD MOTOR ENOW00071-0 CAUTION The tilt support device supplied on your outboard motor is not intended for towing. It is intended to support the outboard motor while the boat is docked, beached, etc. When transporting a boat on a trailer with the outboard motor still attached, discon- nect the fuel line from the outboard motor beforehand and keep the outboard motor...

  • Page 54: Adjustment

    ADJUSTMENT ENOM00073-0 Friction adjustment of the throttle grip can 1. Steering friction be made with the throttle adjustment screw. Tiller handle type ENOW00074-A WARNING Do not overtighten the steering friction lever it could result in difficulty of move- ment resulting in the loss of control caus- ing an accident and could lead to severe ENOF00330-0 injury.

  • Page 55: Trim Tab Adjustment

    ADJUSTMENT Side mount type the anti-ventilation plate.  If the boat veers toward the left direct the trim tab towards A (left from rear of boat).  If the boat veers toward the right direct the trim tab towards B (right from rear of boat).

  • Page 56: Inspection And Maintenance

    INSPECTION AND MAINTENANCE ENOM00077-0 Care of your outboard motor To keep your outboard motor in the best operating condition, it is very important that you perform daily and periodic main- tenance as suggested in the maintenance schedules that follow. ENOW00077-0 CAUTION ...

  • Page 57: Daily Inspection

    INSPECTION AND MAINTENANCE ENOM00322-1 1. Daily Inspection Perform the following checks before and ENOW00078-0 after use. WARNING Do not use outboard motor if any abnor- mality is found during pre-operation check or it could result in severe damage to the motor or severe personal injury.
  • Page 58 INSPECTION AND MAINTENANCE Item Points to Check Remedy Steering • Check the operation of the steering handle. Repair Devices • Check if the anode is securely installed. Repair if necessary Other parts • Check the anode for corrosion and deformation. Replace ENOM00081-A Oil level checking...
  • Page 59 INSPECTION AND MAINTENANCE  Wipe off engine oil well immediately if ENOW00920-0 spilled and dispose of it in accordance CAUTION with local fire prevention and environ- ment protection regulations. When washing the outboard motor, be  Do not replenish engine oil over upper careful not to spray the water inside of the limit.
  • Page 60 INSPECTION AND MAINTENANCE 3. Connect a water hose. Turn on the ENOW00036-A water and adjust the flow. CAUTION 4. Put the shift lever in the neutral position When the engine is started in the test tank, and start the engine. to avoid over heating and water pump Continue flushing the outboard motor damage, be sure the water level is at least...
  • Page 61 INSPECTION AND MAINTENANCE fuse will likely blow again. If the fuse continues to blow, request an authorized BRP dealer to inspect the out- board motor. 1. Stop the engine and disconnect the battery cable from the battery negative (-) terminal.

  • Page 62: Periodic Inspection

    INSPECTION AND MAINTENANCE ENOM00090-B 2. Periodic Inspection It is important to inspect and maintain your outboard motor regularly. At each interval on the chart below, be sure to perform the indicated servicing. Maintenance intervals should be determined according to the number of hours or number of months, whichever comes first.
  • Page 63 INSPECTION AND MAINTENANCE Inspection intervals First 20 Every 50 Every 100 Every 200 Description Inspection procedure Remarks hours or 1 hours or 3 hours or 6 hours or 1 month months months year Check for bent blades, damage, wear. Propeller ...
  • Page 64 INSPECTION AND MAINTENANCE ENOW00933-0 rect torque as soon as possible with a torque-wrench. CAUTION 7. Reset the engine in a vertical position. Engine oil mixed with dust or water will 8. Repeat 3 to 7 procedures two or three dramatically shorten the life of the engine. times to drain the oil completely.
  • Page 65 INSPECTION AND MAINTENANCE ENON00920-0 ENOM00092-A Note Oil filter replacement ENOW00091-0 Use only recommended engine oil (See page 12) CAUTION You may be injured due to high engine temperatures if you fill engine oil just after stopping. Changing engine oil should be 10W−40 done after the engine has been cooled.
  • Page 66 INSPECTION AND MAINTENANCE  Contact authorized dealer for fuel sys- tem services. Services by unqualified person could lead to engine damage. Fuel filters are provided inside the fuel tank and engine. ENOF00094-0 ENOM00094-0 Fuel filter (for engine) 1. Oil filter wrench 1.
  • Page 67 INSPECTION AND MAINTENANCE ENOF01227-0 3. Insert the oil tube nozzle into the lower oil plug hole, and fill with gear oil by ENOF01226-A squeezing the oil tube until oil flows out 1. Fuel pick up 2. Filter of the upper plug hole and bubbles is disappeared to remove the air.
  • Page 68 INSPECTION AND MAINTENANCE ENOW00095-0 ENOM00086-A Propeller replacement CAUTION ENOW00084-0 Do not reuse oil plug gasket. Always use WARNING new gasket and tighten oil plug properly to prevent entry of water into lower unit.  Do not begin propeller removal and installation procedure with spark plug c a p s a t t a c h e d , s h i f t i n f o r w a rd o r reverse, main switch at other than...
  • Page 69 INSPECTION AND MAINTENANCE ENOW00086-0 2. Remove the split pin, propeller nut and CAUTION washer. 3. Remove the propeller and thrust  Do not install propeller without thrust holder. holder, or propeller boss could be dam- aged. 4. Apply water proof grease to the pro- ...
  • Page 70 INSPECTION AND MAINTENANCE 4. Remove the spark plugs by turning it the correct torque as soon as possible with a torque-wrench. counter-clockwise, using a 5/8" (16 mm) socket wrench and handle that is provided in tool bag. 5. Inspect the spark plug. Replace the spark plug if the electrodes are worn or i f t h e i n s u l a t o r s a re c r a c k e d o r chipped.
  • Page 71 INSPECTION AND MAINTENANCE ENOM00088-A Anode replacement A sacrificial anode protects the outboard motor from electrolytic corrosion. Anode is located on the gear case, cylinder etc.. When the anode is eroded more than 1/3 of origi- nal size, replace it. ENON00029-0 Notes ...
  • Page 72 INSPECTION AND MAINTENANCE ENOM00089-B 1. Oil cap Power Tilt oil checking 2. Oil level Recommended oil ENOW00088-0 Use an automatic transmission fluid or WARNING equivalent.  Be sure that outboard motor is secured Recommended oils are as shown below. to transom or service stand, or acciden- ATF Dexron III tal drop or fall of outboard motor could lead to severe personal injury.
  • Page 73 INSPECTION AND MAINTENANCE ENOM00960-0 Grease point Apply water proof grease to the parts shown below. ENOF01232-0 *1 : Need disassembling the hook lever to apply grease.

  • Page 74: Off-Season Storage

    INSPECTION AND MAINTENANCE ENOM00100-A 3. Drain all fuel from the fuel hoses, fuel 3. Off-season storage pump and carburetor (See page 75), and clean these parts. ENOW00934-0 Keep in mind that if gasoline is kept in the carburetor for a long time, gum and WARNING varnish will develop, causing the float ...
  • Page 75 INSPECTION AND MAINTENANCE ENOW00066-0 1. Before adding fuel stabilizer additive, drain the carburetor (See page 75). CAUTION 2. Follow the instructions on the label Do not carry or store outboard motor in when adding the fuel stabilizer additive. any of positions described below. 3.

  • Page 76: Pre-Season Check

    INSPECTION AND MAINTENANCE ENOM00102-0 Battery 1. Disconnect the fuel hose from the out- ENOW00931-A board motor. WARNING 2. Remove the top cowl. 3. Place an approved fuel container  Place the battery away from any source under the drain screw and use a funnel of fire, sparks and open flames such as burners or welding equipment.

  • Page 77: Submerged Outboard Motor

    INSPECTION AND MAINTENANCE sures to be taken for a submerged out- Specific Gravity Terminal Voltage Charge Condition at 20° board motor, if you can not take it your 1.210 11.7 1/2 charged dealer right away. 1.250 3/4 charged 1. Wash the outboard motor with fresh 1.280 13.2 Fully charged...

  • Page 78: Striking Underwater Object

    INSPECTION AND MAINTENANCE ENOM00107-A 7. Striking underwater object ENOW00935-0 CAUTION Striking the sea bottom or an underwater object may severely damage the outboard motor. 1. Stop the engine immediately. 2. Check the control system, gear case, boat transom etc. 3. Return to the nearest habor slowly and carefully.
  • Page 79 TROUBLESHOOTING ENOM00326-0 If you encounter a problem, consult the check list below to determine the cause and to take the proper action. An authorized dealer will always be happy to provide any assistance and information. Possible cause   Empty fuel tank ...
  • Page 80 TROUBLESHOOTING Possible cause      Low compression  Carbon deposits in the combustion chamber   Incorrect valve clearance  Low oil pressure/level     Incorrect adjustment of throttle link  Insufficient cooling water flow, clogged or defective pump ...
  • Page 81 TOOL KIT AND SPARE PARTS ENOM00327-0 The following a list of the tools and spare parts provided with the motor. Items Quantity Remark Tool bag Pliers Socket wrench 10 × 13 mm Service tools Socket wrench 16 mm Socket wrench handle Screwdrivers Cross-and straight-point Screwdriver handle...
  • Page 82 PROPELLER TABLE ENOM00329-0 Use a genuine propeller. A propeller must be selected so that the engine rpm measured at wide open throttle while cruising is within the recommended range. 15: 5000–6000 rpm 20: 5400–6100 rpm Propeller Size (Blades × diameter × pitch) Propeller Mark inch...
  • Page 83 Product other than those contained in this limited warranty and, if made, shall not be enforceable against BRP. BRP reserves the right to modify this warranty at any time, being understood that such modifi- cation will not alter the warranty conditions applicable to the Products sold while this warranty is in effect.
  • Page 84 Please see your Authorized Evinrude Outboard Engine Dealer for emission- related service. In cases where the delivery date is not established to BRP’s satisfaction, the date of sale will be used to de- termine the warranty start date.
  • Page 85 Evinrude products in the country in which the sale occurs. If further assistance is required, please contact BRP US Inc. / Outboard Engines Division, After Sales Sup- port, P.O Box 597, Sturtevant, WI 53177, or the affiliate of BRP where the Product was registered for war- ranty.
  • Page 86 2015 Evinrude 4-Stroke outboard. In California, new outboard engines must be designed, built, and equipped to meet the State’s stringent anti-smog standards. BRP must warrant the emission control system on your outboard for the periods of time listed below provided there has...
  • Page 87 As the outboard owner, you are responsible for the performance of the required maintenance listed in your Operator’s Guide. BRP recommends that you retain all receipts covering maintenance on your outboard, but BRP cannot deny warranty solely for the lack of receipts or your failure to ensure the performance of all scheduled maintenance.
  • Page 88 This warranty coverage is available only if each of the following conditions has been fulfilled: a. Evinrude outboard engines must be purchased as new and unused by its first owner from a BRP distribu- tor / dealer authorized to distribute Evinrude products in the country in which the sale occurred (hereinafter “Distributor / Dealer”),...
  • Page 89 Distributor / Dealer, under the conditions described above. BRP’s responsibility is limited to making the required repairs or replacements of parts. No claim of breach of warranty shall be cause for cancellation or rescission of the sale of Product to Owner.
  • Page 90 RIGHTS, AND YOU MAY ALSO HAVE OTHER LEGAL RIGHTS WHICH MAY VARY FROM COUNTRY TO COUNTRY, OR PROVINCE TO PROVINCE. Neither the Distributor any BRP Distributor / Dealer nor any other person has been authorized to make any affirmation, representation or warranty regarding Product other than those contained in this limited warranty and, if made, shall not be enforceable against BRP.
  • Page 91 / dealer at the time of sale, whether or not shipped with Product, bear the standard BRP limited warranty for Evinrude/ Johnson Genuine Parts and accessories. See your authorized distributor / dealer for a full copy of such lim- ited warranty.
  • Page 92 This warranty coverage is available only if each of the following conditions has been fulfilled: a. The Evinrude outboard engines must be purchased as new and unused by its first owner from a BRP distributor / dealer authorized to distribute Evinrude products in the country in which the sale occurred (“Dis- tributor /Dealer”),...
  • Page 93 In the event of a controversy or dispute in connection with this BRP limited warranty, BRP recommends that you first try to resolve the issue at the authorized BRP distributorship / dealership level by discussing the is- sue with Distributor’s / Dealer’s service manager or owner;...
  • Page 94 Readiness Test The Operator’s Readiness Test..1. Did you read this Guide from front cover to rear cover? 2. Are you ready to take responsibility for the safe operation of your boat and out- board? 3. Do you understand all the safety precautions and instructions contained in this Guide? 4.
  • Page 95 Yes. In order to maintain contact with you or the new Evinrude 4-Stroke owner, BRP requests you complete the form outlining Change of Address / Change of Ownership. This will ensure you or the new owner is made aware of any product announcements and keep the warranty coverage up-to-date.
  • Page 97 This notification is necessary for your own safety even after expiration of the original warranty, since BRP will be in a position to contact you if correction to your outboard is required. Outside the U.S. and Canada, this card should be sent to the Bombardier Recreational Products division where the outboard was regis- tered.
  • Page 99 Confirmation of Receipt Your Dealer Name: Address: Upon delivery of your new Evinrude /Johnson Your Dealer will take receipt of the form for outboard, complete and sign the form below. their records. Receipt Name: Address: Owner of Model No: Serial No: (To be completed by customer or selling Dealer The Dealer named on this document has instructed me on the operation, maintenance, safety features and warranty policy, all of which I understand...
  • Page 100 M E M O M E M O...
  • Page 101 M E M O...
  • Page 102 M E M O...
  • Page 104 003-11127-0 1412NB Printed in Japan...
