Proline Prosonic Flow G 300 HART Table of contents Table of contents About this document ....6 Mounting ......21 Document function .
Page 4 13.2 Measuring and test equipment ... 158 10.7.1 Write protection via access code . . . 13.3 Endress+Hauser services ....158 Endress+Hauser...
Page 5 14.2 Spare parts ......159 14.3 Endress+Hauser services ....159 14.4 Return .
Page 6: About This Document
About this document Proline Prosonic Flow G 300 HART About this document Document function These Operating Instructions contain all the information required in the various life cycle phases of the device: from product identification, incoming acceptance and storage, to installation, connection, operation and commissioning, through to troubleshooting, maintenance and disposal.
Page 7: Tool Symbols
Proline Prosonic Flow G 300 HART About this document Symbol Meaning Light emitting diode is on. Light emitting diode is flashing. 1.2.4 Tool symbols Symbol Meaning Flat-blade screwdriver Allen key Open-ended wrench 1.2.5 Symbols for certain types of information Symbol...
Page 8: Documentation
For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. 1.3.1 Document function...
Page 9: Safety Instructions
Proline Prosonic Flow G 300 HART Safety Instructions Safety Instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11: Security
Proline Prosonic Flow G 300 HART Safety Instructions IT security Our warranty is valid only if the product is installed and used as described in the Operating Instructions. The product is equipped with security mechanisms to protect it against any inadvertent changes to the settings.
Page 12: Access Via Web Server
Safety Instructions Proline Prosonic Flow G 300 HART • User-specific access code Protect write access to the device parameters via the local display, web browser or operating tool (e.g. FieldCare, DeviceCare). Access authorization is clearly regulated through the use of a user-specific access code.
Page 13: Access Via Service Interface (Cdi-Rj45)
Proline Prosonic Flow G 300 HART Safety Instructions 2.7.4 Access via service interface (CDI-RJ45) The device can be connected to a network via the service interface (CDI-RJ45). Device- specific functions guarantee the secure operation of the device in a network.
Page 14: Product Description
Product description Proline Prosonic Flow G 300 HART Product description The device consists of a transmitter and a sensor. The device is available as a compact version: The transmitter and sensor form a mechanical unit. Product design N ic te r e rg ö...
Page 15: Identification
Is the envelope present with accompanying documents? • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • The Technical Documentation is available via the Internet or via the Endress+Hauser Operations app: Product identification→  16.
Page 16: Transmitter Nameplate
• The "Additional standard documentation on the device" and "Supplementary device- dependent documentation" sections • The Device Viewer: Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations app: Enter the serial number from the nameplate or scan the DataMatrix code on the nameplate. 4.2.1 Transmitter nameplate...
Page 17: Sensor Nameplate
Proline Prosonic Flow G 300 HART Incoming acceptance and product identification 4.2.2 Sensor nameplate Order code: Ser. no.: Ext. ord. cd.: Date: A0029204  3 Example of sensor nameplate Name of sensor Manufacturer address/certificate holder Order code Serial number (Ser. no.) Extended order code (Ext.
Page 18: Symbols On The Device
Incoming acceptance and product identification Proline Prosonic Flow G 300 HART 4.2.3 Symbols on the device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Please consult the documentation for the measuring device to discover the type of potential danger and measures to avoid it.
Page 19: Storage And Transport
Proline Prosonic Flow G 300 HART Storage and transport Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.
Page 20: Measuring Devices With Lifting Lugs
Storage and transport Proline Prosonic Flow G 300 HART 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device.
Page 21: Mounting
Proline Prosonic Flow G 300 HART Mounting Mounting Mounting requirements 6.1.1 Mounting position Mounting location A0015543 Orientation The direction of the arrow on the sensor helps you to install the sensor according to the flow direction (direction of medium flow through the piping).
Page 22 Mounting Proline Prosonic Flow G 300 HART –5° 0° +5° –5° 0° +5° A0037650 Inlet and outlet runs If possible, install the sensors upstream of assemblies such as valves, T-pieces, elbows, and pumps. If this is not possible, the specified measurement accuracy of the measuring device is achieved by observing the specified minimum inlet and outlet runs with optimum sensor configuration.
Page 23: Environmental And Process Requirements
Proline Prosonic Flow G 300 HART Mounting 6.1.2 Environmental and process requirements Ambient temperature range Measuring device • Standard:–40 to +60 °C (–40 to +140 °F) • Optional order code for "Test, certificate", option JP: –50 to +60 °C (–58 to +140 °F) Readability of the local display –20 to +60 °C (–4 to +140 °F)
Page 24: Special Mounting Instructions
Mounting Proline Prosonic Flow G 300 HART Thermal insulation For optimum measurement performance, make sure that no heat transfer (heat loss or heat supply) can take place at the sensor. This can be ensured by installing thermal insulation. The formation of condensation in the measuring device can also be limited in this way.
Page 25 Proline Prosonic Flow G 300 HART Mounting RUPTURE DISK 12.5bar+/-25%@20°C A0037501 Rupture disk label Weather protection cover 280 (11.0) 255 (10.0) 146 (5.75) 134 (5.3) 12 (0.47) 30 (1.18) A0029553  8 Engineering unit mm (in) Cover lock NOTICE Order code "Housing", option L "Cast, stainless": The covers of the transmitter housing are provided with a borehole to lock the cover.
Page 26: Mounting The Measuring Device
Mounting Proline Prosonic Flow G 300 HART SW 2.5 5 (0.2) min. 15 (0.6) A0029800 Cover borehole for the securing screw Securing screw to lock the cover Mounting the measuring device 6.2.1 Required tools For sensor For flanges and other process connections: use a suitable mounting tool 6.2.2...
Page 27: Turning The Transmitter Housing
Proline Prosonic Flow G 300 HART Mounting 6.2.4 Turning the transmitter housing To provide easier access to the connection compartment or display module, the transmitter housing can be turned. – – 3 mm 4 mm 7 Nm (5.2 lbf ft) A0029993 ...
Page 28: Post-Mounting Check
Mounting Proline Prosonic Flow G 300 HART – – – 3 mm A0030035 1. Depending on the device version: Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover. 3. Turn the display module to the desired position: max. 8 × 45° in each direction.
Page 29: Electrical Connection
Proline Prosonic Flow G 300 HART Electrical connection Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage.
Page 30 Electrical connection Proline Prosonic Flow G 300 HART Double pulse output Standard installation cable is sufficient Relay output Standard installation cable is sufficient. Current input 0/4 to 20 mA Standard installation cable is sufficient Status input Standard installation cable is sufficient Cable diameter •...
Page 31 Proline Prosonic Flow G 300 HART Electrical connection Cable length Maximum 300 m (1 000 ft), maximum loop impedance 20 Ω Capacitance: core/shield Maximum 1 000 nF for Zone 1, Class I, Division 1 Maximum 24 µH/Ω for Zone 1, Class I, Division 1...
Page 32: Terminal Assignment
Electrical connection Proline Prosonic Flow G 300 HART 7.2.3 Terminal assignment Transmitter: supply voltage, input/outputs The terminal assignment of the inputs and outputs depends on the individual order version of the device. The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 33 Proline Prosonic Flow G 300 HART Electrical connection – – – 3 mm A0029813 1. Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover. 3. Squeeze the tabs of the display module holder together.
Page 34 Electrical connection Proline Prosonic Flow G 300 HART 22 mm 24 mm – A0029816 10. Connect the cable according to the terminal assignment.  Signal cable terminal assignment: The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 35: Connecting The Remote Display And Operating Module Dkx001
Proline Prosonic Flow G 300 HART Electrical connection 7.3.2 Connecting the remote display and operating module DKX001 The remote display and operating module DKX001 is available as an optional extra →  161. • The measuring device is always supplied with a dummy cover when the remote display and operating module DKX001 is ordered directly with the measuring device.
Page 36: Special Connection Instructions
Electrical connection Proline Prosonic Flow G 300 HART Special connection instructions 7.5.1 Connection examples Current output 4 to 20 mA HART 4...20 mA A0029055  12 Connection example for 4 to 20 mA HART current output (active) Automation system with current input (e.g. PLC) Ground cable shield at one end.
Page 37 Proline Prosonic Flow G 300 HART Electrical connection HART input 4...20 mA A0028763  14 Connection example for HART input with a common negative (passive) Automation system with HART output (e.g. PLC) Active barrier for power supply (e.g. RN221N) Ground cable shield at one end. The cable shield must be grounded at both ends to comply with EMC requirements;...
Page 38 Electrical connection Proline Prosonic Flow G 300 HART Pulse/frequency output 12345 A0028761  17 Connection example for pulse/frequency output (passive) Automation system with pulse/frequency input (e.g. PLC with 10 kΩ pull-up or pull-down resistor) Power supply Transmitter: observe input values →  171...
Page 39 Proline Prosonic Flow G 300 HART Electrical connection A0029279  20 Connection example for double pulse output (passive) Automation system with double pulse input (e.g. PLC with a 10 kΩ pull-up or pull-down resistor) Power supply Transmitter: observe input values →  172...
Page 40: Ensuring The Degree Of Protection
Electrical connection Proline Prosonic Flow G 300 HART Status input A0028764  23 Connection example for status input Automation system with status output (e.g. PLC) Power supply Transmitter Ensuring the degree of protection The measuring device fulfills all the requirements for the degree of protection IP66/67, Type 4X enclosure.
Page 41 Proline Prosonic Flow G 300 HART Electrical connection If supply voltage is present, do values appear on the display module?  Are dummy plugs inserted in unused cable entries and have transportation plugs been replaced  with dummy plugs? Endress+Hauser...
Page 42: Operation Options
Operation options Proline Prosonic Flow G 300 HART Operation options Overview of operation options A0034513 Local operation via display module Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370...
Page 43: Structure And Function Of The Operating Menu
Proline Prosonic Flow G 300 HART Operation options Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: see the "Description of Device Parameters" document supplied with the device...
Page 44: Operating Philosophy
Operation options Proline Prosonic Flow G 300 HART 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (e.g. operator, maintenance etc.). Each user role contains typical tasks within the device life cycle. Menu/parameter...
Page 45: Access To Operating Menu Via Local Display
Proline Prosonic Flow G 300 HART Operation options Access to operating menu via local display 8.3.1 Operational display X X X X X X X 1120.50 A0029346 Operational display Device tag →  79 Status area Display range for measured values (up to 4 lines) Operating elements →...
Page 46 Operation options Proline Prosonic Flow G 300 HART Sound velocity Pressure Energy flow Flow velocity Temperature Wobbe index Methane fraction Molar mass • Density • Reference density Dynamic viscosity Calorific value Signal to noise ratio Acceptance rate Asymmetry Turbulence Signal strength The number and display format of the measured variables can be configured via the Format display parameter (→...
Page 47 Proline Prosonic Flow G 300 HART Operation options Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 48: Navigation View
Operation options Proline Prosonic Flow G 300 HART 8.3.2 Navigation view In the submenu In the wizard /../Operation 0091-1 /../Curr. output 1 Access stat.disp Assign curr. Operator Volume flow Locking status Display A0013993-EN A0016327-EN Navigation view Navigation path to current position...
Page 49 Proline Prosonic Flow G 300 HART Operation options Setup Is displayed: • In the menu next to the "Setup" selection • At the left in the navigation path in the Setup menu Diagnosis Is displayed: • In the menu next to the "Diagnostics" selection •...
Page 50: Editing View
Operation options Proline Prosonic Flow G 300 HART 8.3.3 Editing view Numeric editor +0.000 Xx – A0034250  25 For entering values in parameters (e.g. limit values) Entry display area Input screen Confirm, delete or reject entry Operating elements Text editor...
Page 51 Proline Prosonic Flow G 300 HART Operation options Operating key Meaning Enter key • Pressing the key briefly confirms your selection. • Pressing the key for 2 s confirms your entry. Escape key combination (press keys simultaneously) Close the editing view without accepting a change.
Page 52: Operating Elements
Operation options Proline Prosonic Flow G 300 HART 8.3.4 Operating elements Operating key Meaning Minus key In menu, submenu Moves the selection bar upwards in a picklist In wizards Goes to previous parameter In the text and numeric editor Move the entry position to the left.
Page 53 Proline Prosonic Flow G 300 HART Operation options Calling up and closing the context menu The user is in the operational display. 1. Press the  and  keys for longer than 3 seconds.  The context menu opens. XXXXXXXXXX Setup Conf.backup...
Page 54: Navigating And Selecting From List
Operation options Proline Prosonic Flow G 300 HART 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 55: Calling Up Help Text
Proline Prosonic Flow G 300 HART Operation options The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter.
Page 56: User Roles And Related Access Authorization
Operation options Proline Prosonic Flow G 300 HART Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN For a description of the editing view - consisting of the text editor and numeric editor - with symbols →  50, for a description of the operating elements →  52 8.3.10...
Page 57: Enabling And Disabling The Keypad Lock
Proline Prosonic Flow G 300 HART Operation options 2. Enter the access code.  The -symbol in front of the parameters disappears; all previously write- protected parameters are now re-enabled. 8.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation.
Page 58: Requirements
Operation options Proline Prosonic Flow G 300 HART 8.4.2 Requirements Computer hardware Hardware Interface CDI-RJ45 WLAN Interface The computer must have a RJ45 The operating unit must have a WLAN interface. interface. Connection Standard Ethernet cable Connection via Wireless LAN.
Page 59: Connecting The Device
Proline Prosonic Flow G 300 HART Operation options Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON  For information on enabling the Web server →  63...
Page 60 Operation options Proline Prosonic Flow G 300 HART NOTICE Note the following to avoid a network conflict: ‣ Avoid accessing the measuring device simultaneously from the same mobile terminal via the service interface (CDI-RJ45) and the WLAN interface. ‣ Only activate one service interface (CDI-RJ45 or WLAN interface).
Page 61: Logging On
Proline Prosonic Flow G 300 HART Operation options 2. Enter the IP address of the web server in the address line of the web browser: 192.168.1.212  The login page appears. 2 3 4 Device name: Device tag: Signal Status:...
Page 62: User Interface
Operation options Proline Prosonic Flow G 300 HART 8.4.5 User interface A0029418 Function row Local display language Navigation area Header The following information appears in the header: • Device name • Device tag • Device status with status signal →  138 •...
Page 63: Disabling The Web Server
Proline Prosonic Flow G 300 HART Operation options Working area Depending on the selected function and the related submenus, various actions can be performed in this area: • Configuring parameters • Reading measured values • Calling up help text • Starting an upload/download 8.4.6...
Page 64: Access To The Operating Menu Via The Operating Tool
Operation options Proline Prosonic Flow G 300 HART Access to the operating menu via the operating tool The structure of the operating menu in the operating tools is the same as for operation via the local display. 8.5.1 Connecting the operating tool Via HART protocol This communication interface is available in device versions with a HART output.
Page 65 Proline Prosonic Flow G 300 HART Operation options A0028746  29 Options for remote operation via HART protocol (passive) Control system (e.g. PLC) Transmitter power supply unit, e.g. RN221N (with communication resistor) Connection for Commubox FXA195 and Field Communicator 475 Field Communicator 475 Computer with web browser (e.g.
Page 66 Operation options Proline Prosonic Flow G 300 HART Via WLAN interface The optional WLAN interface is available on the following device version: Order code for "Display; operation", option G "4-line, illuminated; touch control + WLAN" A0034570 Transmitter with integrated WLAN antenna...
Page 67: Field Xpert Sfx350, Sfx370
FieldCare Function range FDT-based (Field Device Technology) plant asset management tool from Endress+Hauser. It can configure all smart field units in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
Page 68 Operation options Proline Prosonic Flow G 300 HART Access is via: • HART protocol →  64 • CDI-RJ45 service interface →  65 • WLAN interface →  66 Typical functions: • Transmitter parameter configuration • Loading and saving of device data (upload/download) •...
Page 69: Devicecare
DeviceCare Function range Tool for connecting and configuring Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. Innovation brochure IN01047S Source for device description files →...
Page 70: Field Communicator 475
Operation options Proline Prosonic Flow G 300 HART 8.5.6 Field Communicator 475 Function scope Industrial handheld terminal from Emerson Process Management for remote configuration and measured value display via HART protocol. Source for device description files See information →  71 8.5.7...
Page 71: System Integration
Proline Prosonic Flow G 300 HART System integration System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.02.zz • On the title page of the manual • On the transmitter nameplate • Firmware version Diagnostics →...
Page 72 System integration Proline Prosonic Flow G 300 HART Dynamic variables Measured variables (HART device variables) Primary dynamic variable (PV) Volume flow Secondary dynamic variable (SV) Totalizer 1 Tertiary dynamic variable (TV) Totalizer 2 Quaternary dynamic variable (QV) Totalizer 3 The assignment of the measured variables to the dynamic variables can be modified and...
Page 73 Proline Prosonic Flow G 300 HART System integration Measured variables for SV, TV, QV (secondary, tertiary and quaternary dynamic variable) • Measured variables which are always available: • Volume flow • Mass flow • Flow velocity • Sound velocity • Electronics temperature •...
Page 74: Other Settings
System integration Proline Prosonic Flow G 300 HART Other settings Burst mode functionality in accordance with HART 7 Specification: Navigation "Expert" menu → Communication → HART output → Burst configuration → Burst configuration 1 to n ‣ Burst configuration 1 to n Burst mode 1 to n →...
Page 75 Proline Prosonic Flow G 300 HART System integration Parameter Description Selection / User entry Factory setting Burst variable 0 For HART command 9 and 33: select the • Not used Volume flow HART device variable or the process variable. • Volume flow •...
Page 76 System integration Proline Prosonic Flow G 300 HART Parameter Description Selection / User entry Factory setting Min. update period Enter the minimum time span between two Positive integer 1 000 ms burst commands of burst message X. Max. update period Enter the maximum time span between two...
Page 77: Commissioning
Proline Prosonic Flow G 300 HART Commissioning Commissioning 10.1 Post-mounting and post-connection check Before commissioning the device: ‣ Make sure that the post-installation and post-connection checks have been performed successfully. • Checklist for "Post-mounting" check→  28 • Checklist for "Post-connection check" →  40 10.2...
Page 78 Commissioning Proline Prosonic Flow G 300 HART X X X X X X X 20.50 Main menu Display language English Display/operat. Setup Main menu Display/operat. Setup Diagnostic / ../Setup Medium selection XXXXXXXXX XXXXXXXXX A0032222-EN  32 Navigation to "Setup" menu using the example of the local display The number of submenus and parameters can vary depending on the device version.
Page 79: Defining The Tag Name
Proline Prosonic Flow G 300 HART Commissioning ‣ Gas analysis →  99 ‣ Advanced setup →  101 10.4.1 Defining the tag name To enable fast identification of the measuring point within the system, you can enter a unique designation using the Device tag parameter and thus change the factory setting.
Page 80 Commissioning Proline Prosonic Flow G 300 HART Mass unit →  80 Velocity unit →  80 →  81 Temperature unit Pressure unit →  81 Density unit →  81 Energy unit →  81 →  81...
Page 81: Displaying The I/O Configuration
Proline Prosonic Flow G 300 HART Commissioning Parameter Description Selection Factory setting Temperature unit Select temperature unit. Unit choose list Country-specific: • °C Effect • °F The selected unit applies for: • Temperature • Maximum value • Minimum value Pressure unit Select process pressure unit.
Page 82: Configuring The Status Input
Commissioning Proline Prosonic Flow G 300 HART Parameter overview with brief description Parameter Description User interface / Selection / Factory setting User entry I/O module 1 to n terminal numbers Shows the terminal numbers used by the I/O • Not used – module.
Page 83: Configuring The Current Input
Proline Prosonic Flow G 300 HART Commissioning Parameter overview with brief description Parameter Description Selection / User interface / Factory setting User entry Assign status input Select function for the status input. • Off • Reset totalizer 1 • Reset totalizer 2 • Reset totalizer 3 •...
Page 84: Configuring The Current Output
Commissioning Proline Prosonic Flow G 300 HART Parameter overview with brief description Parameter Prerequisite Description User interface / Factory setting Selection / User entry Terminal number – Shows the terminal numbers • Not used – used by the current input • 24-25 (I/O 2) module.
Page 85 Proline Prosonic Flow G 300 HART Commissioning Damping current output →  86 Failure behavior current output →  86 →  86 Failure current Parameter overview with brief description Parameter Prerequisite Description User interface / Factory setting Selection / User entry Terminal number –...
Page 86 Commissioning Proline Prosonic Flow G 300 HART Parameter Prerequisite Description User interface / Factory setting Selection / User entry Upper range value output In Current span parameter Enter upper range value for Signed floating-point Depends on country (→  85), one of the the measured value range.
Page 87: Configuring The Pulse/Frequency
Proline Prosonic Flow G 300 HART Commissioning 10.4.7 Configuring the pulse/frequency/switch output The Pulse/frequency/switch output wizard guides you systematically through all the parameters that can be set for configuring the selected output type. Navigation "Setup" menu → Advanced setup → Pulse/frequency/switch output ‣...
Page 88: Pulse/Frequency/Switch Output
Commissioning Proline Prosonic Flow G 300 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Operating mode – Define the output as a pulse, • Pulse Pulse frequency or switch output. • Frequency • Switch Terminal number –...
Page 89 Proline Prosonic Flow G 300 HART Commissioning Assign frequency output →  89 Minimum frequency value →  90 →  90 Maximum frequency value Measuring value at minimum →  90 frequency Measuring value at maximum →  90...
Page 90 Commissioning Proline Prosonic Flow G 300 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry Minimum frequency value The Frequency option is Enter minimum frequency. 0.0 to 10 000.0 Hz 0.0 Hz selected in the Operating mode parameter (→  87)
Page 91: Pulse/Frequency/Switch Output
Proline Prosonic Flow G 300 HART Commissioning Configuring the switch output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  91 Terminal number →  91 Signal mode →  91 Switch output function →...
Page 92 Commissioning Proline Prosonic Flow G 300 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch output function The Switch option is selected Select function for switch • Off in the Operating mode output. • On parameter. • Diagnostic behavior •...
Page 93: Configuring The Relay Output
Proline Prosonic Flow G 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch-off value • The Switch option is Enter limit value for switch-off Signed floating-point Depends on country selected in the Operating point (process variable <...
Page 94: Terminal Number
Commissioning Proline Prosonic Flow G 300 HART Switch-on value →  95 Switch-on delay →  95 →  95 Failure mode Switch state →  95 Powerless relay status →  95 Parameter overview with brief description Parameter Prerequisite Description User interface / ...
Page 95: Configuring The Double Pulse Output
Proline Prosonic Flow G 300 HART Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Assign diagnostic behavior In the Relay output function The output is switched on • Alarm Alarm parameter, the Diagnostic (closed, conductive), if there is •...
Page 96: 10.4.10 Configuring The Local Display
Commissioning Proline Prosonic Flow G 300 HART Pulse width →  96 Failure mode →  96 →  96 Invert output signal Parameter overview with brief description Parameter Description Selection / User interface / Factory setting User entry Signal mode Select the signal mode for the double pulse •...
Page 97 Proline Prosonic Flow G 300 HART Commissioning Value 2 display →  97 Value 3 display →  98 →  98 0% bargraph value 3 100% bargraph value 3 →  98 Value 4 display →  98 Parameter overview with brief description...
Page 98: 10.4.11 Configuring The Low Flow Cut Off
Commissioning Proline Prosonic Flow G 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Value 3 display A local display is provided. Select the measured value that For the picklist, see None is shown on the local display. Value 1 display parameter (→...
Page 99: 10.4.12 Gas Analysis Configuration
Proline Prosonic Flow G 300 HART Commissioning Navigation "Setup" menu → Low flow cut off ‣ Low flow cut off Assign process variable (1837) →  99 On value low flow cutoff (1805) →  99 →  99 Off value low flow cutoff (1804)
Page 100 Commissioning Proline Prosonic Flow G 300 HART Reference density →  100 Calorific value →  100 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Select gas type – Select measured gas type. • Single gas User-specific gas •...
Page 101: Advanced Settings
Proline Prosonic Flow G 300 HART Commissioning 10.5 Advanced settings The Advanced setup submenu with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 0104-1 Main menu Display language English Display/operat.
Page 102: Using The Parameter To Enter The Access Code
Commissioning Proline Prosonic Flow G 300 HART ‣ WLAN settings →  107 ‣ Configuration backup →  109 ‣ →  110 Administration 10.5.1 Using the parameter to enter the access code Navigation "Setup" menu → Advanced setup Parameter overview with brief description...
Page 103 Proline Prosonic Flow G 300 HART Commissioning Totalizer 1 to n operation mode →  103 Totalizer 1 to n failure behavior →  103 Parameter overview with brief description Parameter Prerequisite Description Selection Factory setting Assign process variable 1 to n –...
Page 104: Carrying Out Additional Display Configurations
Commissioning Proline Prosonic Flow G 300 HART 10.5.4 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣...
Page 105 Proline Prosonic Flow G 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 106 Commissioning Proline Prosonic Flow G 300 HART Parameter Prerequisite Description Selection / User Factory setting entry 100% bargraph value 3 A selection was made in the Enter 100 % value for bar Signed floating-point Value 3 display parameter. graph display. number Decimal places 3...
Page 107: Wlan Configuration
Proline Prosonic Flow G 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Separator A local display is provided. Select decimal separator for • . (point) . (point) displaying numerical values. • , (comma) Backlight One of the following Switch the local display •...
Page 108 Commissioning Proline Prosonic Flow G 300 HART Connection state →  109 Received signal strength →  109 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface WLAN – Switch WLAN on and off. • Disable Enable •...
Page 109: Configuration Management
Proline Prosonic Flow G 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Connection state – Displays the connection status. • Connected Not connected • Not connected Received signal strength – Shows the received signal • Low High strength.
Page 110: Using Parameters For Device Administration
Commissioning Proline Prosonic Flow G 300 HART Parameter Description User interface / Selection Factory setting Backup state Shows the current status of data saving or • None None restoring. • Backup in progress • Restoring in progress • Delete in progress • Compare in progress •...
Page 111 Proline Prosonic Flow G 300 HART Commissioning Using the parameter to define the access code Complete this wizard to specify an access code for the Maintenance role. Navigation "Setup" menu → Advanced setup → Administration → Define access code ‣...
Page 112: Simulation
Commissioning Proline Prosonic Flow G 300 HART Using the parameter to reset the device Navigation "Setup" menu → Advanced setup → Administration Parameter overview with brief description Parameter Description Selection Factory setting Device reset Reset the device configuration - either •...
Page 113 Proline Prosonic Flow G 300 HART Commissioning Switch output simulation 1 to n →  114 Switch state 1 to n →  114 →  114 Relay output 1 to n simulation Switch state 1 to n →  114 Pulse output simulation →...
Page 114 Commissioning Proline Prosonic Flow G 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Pulse output simulation 1 to n In the Operating mode Set and switch off the pulse • Off parameter, the Pulse option is output simulation. • Fixed value selected.
Page 115: Protecting Settings From Unauthorized Access
Proline Prosonic Flow G 300 HART Commissioning 10.7 Protecting settings from unauthorized access The following write protection options exist in order to protect the configuration of the measuring device from unintentional modification: • Protect access to parameters via access code →  115 •...
Page 116: Write Protection Via Write Protection
Via Web browser, FieldCare, DeviceCare (via CDI-RJ45 service interface), fieldbus You can only obtain a reset code from your local Endress+Hauser service organization. The code must be calculated explicitly for every device. 1. Note down the serial number of the device.
Page 117 Proline Prosonic Flow G 300 HART Commissioning A0029630 Setting the write protection (WP) switch on the main electronics module to the ON position enables hardware write protection.  In the Locking status parameter, the Hardware locked option is displayed →  118. In addition, on the local display the  symbol appears in front of the parameters in the header of the operational display and in the navigation view.
Page 118: Operation
Operation Proline Prosonic Flow G 300 HART Operation 11.1 Reading off the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access authorization displayed in the Access status parameter applies →...
Page 119: Process Variables
Proline Prosonic Flow G 300 HART Operation ‣ Input values →  122 ‣ →  123 Output values 11.4.1 Process variables The Process variables submenu contains all the parameters needed to display the current measured values for each process variable.
Page 120 Operation Proline Prosonic Flow G 300 HART Parameter overview with brief description Parameter Prerequisite Description User interface Volume flow – Displays the volume flow that is Signed floating-point currently measured. number Dependency The unit is taken from: Volume flow unit parameter (→  80) Mass flow –...
Page 121: System Values
Proline Prosonic Flow G 300 HART Operation Parameter Prerequisite Description User interface Corrected volume flow – Displays the corrected volume flow that Signed floating-point is currently measured. number Dependency The unit is taken from: Corrected volume flow unit parameter Methane fraction...
Page 122: Input Values" Submenu
Operation Proline Prosonic Flow G 300 HART Signal to noise ratio →  122 Turbulence →  122 Parameter overview with brief description Parameter Description User interface Signal strength Displays the current signal strength (0 to 100 dB). Signed floating-point number Assessment of the signal strength: •...
Page 123: Output Values
Proline Prosonic Flow G 300 HART Operation Parameter overview with brief description Parameter Description User interface Measured values 1 to n Displays the current input value. Signed floating-point number Dependency  The unit is taken from the Pressure unit parameter Measured current 1 to n Displays the current value of the current input.
Page 124 Operation Proline Prosonic Flow G 300 HART Navigation "Diagnostics" menu → Measured values → Output values → Value current output 1 to n ‣ Current output 1 to n Output current →  124 Measured current →  124 Parameter overview with brief description...
Page 125: Totalizer" Submenu
Proline Prosonic Flow G 300 HART Operation Navigation "Diagnostics" menu → Measured values → Output values → Relay output 1 to n ‣ Relay output 1 to n Switch state →  125 Switch cycles →  125 →  125 Max.
Page 126: Adapting The Measuring Device To The Process
Operation Proline Prosonic Flow G 300 HART Navigation "Diagnostics" menu → Measured values → Totalizer ‣ Totalizer Totalizer 1 to n value →  126 Totalizer 1 to n overflow →  126 Parameter overview with brief description Parameter Prerequisite...
Page 127: Function Scope Of "Control Totalizer" Parameter
Proline Prosonic Flow G 300 HART Operation Totalizer value 1 to n →  127 Reset all totalizers →  127 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Control Totalizer 1 to n A process variable is selected Control totalizer value.
Page 128: Function Range Of "Reset All Totalizers" Parameter
Operation Proline Prosonic Flow G 300 HART 11.6.2 Function range of "Reset all totalizers" parameter Options Description Cancel No action is executed and the user exits the parameter. Reset + totalize Resets all totalizers to 0 and restarts the totaling process. This deletes all the previously aggregated flow values.
Page 129: Pressure
Proline Prosonic Flow G 300 HART Operation Data logging →  130 Logging delay →  130 →  130 Data logging control Data logging status →  130 Entire logging duration →  130 Parameter overview with brief description...
Page 130 Operation Proline Prosonic Flow G 300 HART Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign channel 4 The Extended HistoROM Assign a process variable to For the picklist, see application package is logging channel. Assign channel 1 available. parameter (→...
Page 131: Diagnosis And Troubleshooting
Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting Diagnosis and troubleshooting 12.1 General troubleshooting For local display Error Possible causes Remedial action Local display is dark, but signal output is within The cable of the display module is not plugged in...
Page 132 Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART For access Fault Possible causes Remedial action Write access to parameters is not possible. Hardware write protection is enabled. Set the write protection switch on the main electronics module to the OFF position →...
Page 133 Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting Fault Possible causes Remedial action Operation with FieldCare or DeviceCare via Firewall of the PC or network is blocking Depending on the settings of the firewall used service interface CDI-RJ45 (port 8000) is not communication.
Page 134: Diagnostic Information Via Leds
Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART 12.2 Diagnostic information via LEDs 12.2.1 Transmitter Different LEDs in the transmitter provide information on the device status. 1 2 3 4 5 A0029629 Supply voltage Device status Not used Communication...
Page 135: Diagnostic Information On Local Display
Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display.
Page 136 Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 137: Calling Up Remedial Measures
Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage...
Page 138: Diagnostic Information In The Web Browser
Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART 12.4 Diagnostic information in the web browser 12.4.1 Diagnostic options Any faults detected by the measuring device are displayed in the Web browser on the home page once the user has logged on.
Page 139: Calling Up Remedy Information
Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting 12.4.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly. These measures are displayed in red along with the diagnostic event and the related diagnostic information.
Page 140: Diagnostic Options
Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART 12.5 Diagnostic information in FieldCare or DeviceCare 12.5.1 Diagnostic options Any faults detected by the measuring device are displayed on the home page of the operating tool once the connection has been established.
Page 141: Calling Up Remedy Information
Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting 12.5.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly: • On the home page Remedy information is displayed in a separate field below the diagnostics information.
Page 142: Adapting The Diagnostic Information
Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART 12.6 Adapting the diagnostic information 12.6.1 Adapting the diagnostic behavior Each item of diagnostic information is assigned a specific diagnostic behavior at the factory. The user can change this assignment for specific diagnostic information in the Diagnostic behavior submenu.
Page 143 Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting Symbol Meaning Maintenance required Maintenance is required. The measured value remains valid. A0013957 Has no effect on the condensed status. A0023076 Endress+Hauser...
Page 144: Overview Of Diagnostic Information
Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART 12.7 Overview of diagnostic information The amount of diagnostic information and the number of measured variables affected increase if the measuring device has one or more application packages. In the case of some items of diagnostic information, the status signal and the diagnostic behavior can be changed.
Page 145 Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Firmware incompatible 1. Check firmware version Alarm 2. Flash or replace electronic module Module incompatible 1.
Page 146 Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] I/O- 1 to n 1. Restart device Alarm communication failed 2. Check if failure recurs 3.
Page 147 Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Current input 1 to n Deactivate simulation Warning simulation active Current output 1 to n...
Page 148 Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Electronics temperature Increase ambient temperature Warning too low Process temperature too Reduce process temperature Warning...
Page 149: Pending Diagnostic Events
Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting 12.8 Pending diagnostic events The Diagnostics menu allows the user to view the current diagnostic event and the previous diagnostic event separately. To call up the measures to rectify a diagnostic event: •...
Page 150 Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN  37 Using the example of the local display To call up the measures to rectify a diagnostic event: •...
Page 151: 12.10 Event Logbook
Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting 12.10 Event logbook 12.10.1 Reading out the event logbook A chronological overview of the event messages that have occurred is provided in the Events list submenu. Navigation path Diagnostics menu → Event logbook submenu → Events list / ../Eventlist...
Page 152: 12.10.3 Overview Of Information Events
Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART 12.10.3 Overview of information events Unlike a diagnostic event, an information event is displayed in the event logbook only and not in the diagnostic list. Info number Info name I1000 --------(Device ok)
Page 153 Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting Info number Info name I1625 Write protection activated I1626 Write protection deactivated I1627 Web server: login successful I1628 Display: login successful I1629 CDI: login successful I1631 Web server access changed I1632...
Page 154: 12.11 Resetting The Measuring Device
Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART 12.11 Resetting the measuring device The entire device configuration or some of the configuration can be reset to a defined state with the Device reset parameter (→  112). 12.11.1 Function range of "Device reset" parameter...
Page 155: 12.12 Device Information
Proline Prosonic Flow G 300 HART Diagnosis and troubleshooting 12.12 Device information The Device information submenu contains all parameters that display different information for device identification. Navigation "Diagnostics" menu → Device information ‣ Device information Device tag →  155 Serial number →...
Page 156 Diagnosis and troubleshooting Proline Prosonic Flow G 300 HART Parameter Description User interface Factory setting Device name Shows the name of the transmitter. Prosonic Flow 300 –  The name can be found on the nameplate of the transmitter. Manufacturer Displays the manufacturer.
Page 157: 12.13 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: •...
Page 158: Maintenance
13.2 Measuring and test equipment Endress+Hauser offers a variety of measuring and testing equipment, such as Netilion or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services.
Page 159: Repair
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.
Page 160: Disposal
Repair Proline Prosonic Flow G 300 HART 14.5 Disposal If required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste.
Page 161: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 162: Communication-Specific Accessories
Accessories Proline Prosonic Flow G 300 HART 15.2 Communication-specific accessories Accessories Description Commubox FXA195 For intrinsically safe HART communication with FieldCare via the USB port HART  Technical Information TI00404F HART Loop Converter Is used to evaluate and convert dynamic HART process variables to analog current HMX50 signals or limit values.
Page 163: Service-Specific Accessories
• As a downloadable DVD for local PC installation. Netilion lloT Ecosystem: Unlock knowledge With the Netilion lloT Ecosystem, Endress+Hauser enables you to optimize your plant performance by digitizing workflows, creating knowledge and establishing new levels of collaboration. Building decades of expertise in process automation, Endress+Hauser provides the process industry with an lloT Ecosystem that allows data-driven insights.
Page 164: Technical Data
Technical data Proline Prosonic Flow G 300 HART Technical data 16.1 Application The measuring device is intended only for the flow measurement of gases. To ensure that the device remains in proper operating condition for its service life, use the measuring device only for media against which the process-wetted materials are sufficiently resistant.
Page 165: Input
Proline Prosonic Flow G 300 HART Technical data 16.3 Input Measured variable Direct measured variables • Flow velocity • Sound velocity • Process temperature (optional): based on Pt1000 Class A platinum resistor • Pressure (optional): based on pressure measuring cell for measuring absolute pressure Calculated measured variables •...
Page 166 Technical data Proline Prosonic Flow G 300 HART Flow characteristic values in US units Factory settings Nominal Low flow cut off Recommended flow Full scale value current output Pulse value diameter (v ~ 0.1 m/s) [in] [mm] [ft³/hr] [ft³/hr] [ft³/pulse] [ft³/hr]...
Page 167 Proline Prosonic Flow G 300 HART Technical data Current input 0/4 to 20 mA Current input 0/4 to 20 mA (active/passive) Current span • 4 to 20 mA (active) • 0/4 to 20 mA (passive) Resolution 1 µA Voltage drop Typically: 0.6 to 2 V for 3.6 to 22 mA (passive)
Page 168: Output
Technical data Proline Prosonic Flow G 300 HART 16.4 Output Output signal Current output 4 to 20 mA HART Order code "Output; input 1" (20): Option BA: current output 4 to 20 mA HART Signal mode Can be set to: •...
Page 169 Proline Prosonic Flow G 300 HART Technical data Load • 250 to 400 Ω (active) • 250 to 700 Ω (passive) Resolution 0.38 µA Damping Configurable: 0 to 999.9 s Assignable measured • Volume flow variables • Corrected volume flow •...
Page 170 Technical data Proline Prosonic Flow G 300 HART Damping Configurable: 0 to 999.9 s Assignable measured • Volume flow variables • Corrected volume flow • Mass flow • Energy flow • Sound velocity • Flow velocity • Electronics temperature • Methane fraction •...
Page 171 Proline Prosonic Flow G 300 HART Technical data Pulse/frequency/switch output Function Can be configured as pulse, frequency or switch output Version Open collector Can be set to: • Active • Passive  Ex-i, passive Maximum input values DC 30 V, 250 mA (passive) Open-circuit voltage DC 28.8 V (active)
Page 172 Technical data Proline Prosonic Flow G 300 HART Number of switching Unlimited cycles Assignable functions • Disable • On • Diagnostic behavior • Limit • Volume flow • Corrected volume flow • Mass flow • Energy flow • Flow velocity •...
Page 173 Proline Prosonic Flow G 300 HART Technical data Switching behavior Can be set to: • NO (normally open), factory setting • NC (normally closed) Maximum switching • DC 30 V, 0.1 A capacity (passive) • AC 30 V, 0.5 A Assignable functions •...
Page 174 Technical data Proline Prosonic Flow G 300 HART 0 to 20 mA Failure mode Choose from: • Maximum alarm: 22 mA • Definable value between: 0 to 20.5 mA Pulse/frequency/switch output Pulse output Fault mode Choose from: • Actual value •...
Page 175: Power Supply
Proline Prosonic Flow G 300 HART Technical data Light emitting diodes (LED) Status information Status indicated by various light emitting diodes The following information is displayed depending on the device version: • Supply voltage active • Data transmission active • Device alarm/error has occurred ...
Page 176: Performance Characteristics
Technical data Proline Prosonic Flow G 300 HART Power supply failure • Totalizers stop at the last value measured. • Depending on the device version, the configuration is retained in the device memory or in the pluggable data memory (HistoROM DAT).
Page 177 Proline Prosonic Flow G 300 HART Technical data Volume flow Standard • ±1.0 % o.r. for 3 to 40 m/s (9.84 to 131.2 ft/s) Order code for "Flow calibration", option A "1%" • ±2.0 % o.r. for 0.3 to 3 m/s (0.98 to 9.84 ft/s) Optional •...
Page 178 Technical data Proline Prosonic Flow G 300 HART Temperature Optional (order code for "Measuring tube; Transducer; Sensor version", option AB "316L; Titanium Gr. 2; temperature measurement integrated" or AC "316L; titanium gr. 2; integrated pressure + temperature measurement") ±0.35 °C ± 0.002 · T °C (±0.63 °F ± 0.0011 · (T – 32) °F) The additional measurement error caused by heat conduction is not taken into consideration here.
Page 179: Mounting
Proline Prosonic Flow G 300 HART Technical data Corrected volume flow • ±0.25 % o.r. for 3 to 40 m/s (9.84 to 131.2 ft/s) • ±0.45 % o.r. for 0.3 to 3 m/s (0.98 to 9.84 ft/s) Temperature ±0.175 °C ± 0.001 · T °C (±0.315 °F ± 0.00055 · (T – 32) °F) Pressure Optional (order code for "Measuring tube;...
Page 180 4 to 95%. Operating height According to EN 61010-1 • ≤ 2 000 m (6 562 ft) • > 2 000 m (6 562 ft) with additional overvoltage protection (e.g. Endress+Hauser HAW Series) Degree of protection Transmitter • IP66/67, Type 4X enclosure, suitable for pollution degree 4 •...
Page 181: Process
Proline Prosonic Flow G 300 HART Technical data 16.9 Process Medium temperature range Sensor • Without integrated pressure measuring cell: –50 to +150 °C (–58 to +302 °F) • With integrated pressure measuring cell: –50 to +100 °C (–58 to +212 °F)
Page 182: 16.10 Mechanical Construction
Technical data Proline Prosonic Flow G 300 HART for the controlled release of pressure in the neck of the measuring device. The measuring device with an installed rupture disk meets the dual seal requirements of ANSI/ ISA-12.27.01. Flow limit The diameter of the pipe and the flow rate determine the nominal diameter of the sensor.
Page 183 Proline Prosonic Flow G 300 HART Technical data Weight Weight specifications (exclusive of packaging material) including transmitter as per order code for "Housing", option A "Aluminum, coated". Different values due to different transmitter versions: • Transmitter version for the hazardous area (Order code for "Housing", option A "Aluminum, coated";...
Page 184 Technical data Proline Prosonic Flow G 300 HART Nominal diameter ASME [lbs] Pressure rating [mm] [in] Class 150 RF Sch.40 Class 300 RF Sch.40 Class 300 RF Sch.80 Class 600 RF Sch.80 Materials Transmitter housing Order code for "Housing": • Option A "Aluminum, coated": aluminum, AlSi10Mg, coated •...
Page 185 Proline Prosonic Flow G 300 HART Technical data Order code for "Housing", option L "Cast, stainless" The various cable entries are suitable for hazardous and non-hazardous areas. Cable entry/cable gland Material Cable gland M20 × 1.5 Stainless steel, 1.4404 (316L) Adapter for cable entry with female thread G ½"...
Page 186: 16.11 Display And User Interface
Technical data Proline Prosonic Flow G 300 HART Seal for pressure measuring cell Seal-free (self-sealing NPT thread with sealant) Accessories Protective cover Stainless steel, 1.4404 (316L) External WLAN antenna • Antenna: ASA plastic (acrylonitrile styrene acrylate) and nickel-plated brass • Adapter: Stainless steel and nickel-plated brass •...
Page 187 Proline Prosonic Flow G 300 HART Technical data Display elements • 4-line, illuminated, graphic display • White background lighting; switches to red in event of device errors • Format for displaying measured variables and status variables can be individually configured Operating elements •...
Page 188 Technical data Proline Prosonic Flow G 300 HART Connecting cable →  30 Dimensions Information about dimensions: "Mechanical construction" section of the "Technical Information" document. Remote operation →  64 Service interface →  65 Supported operating tools Different operating tools can be used for local or remote access to the measuring device.
Page 189 Proline Prosonic Flow G 300 HART Technical data menu is the same as for the local display. In addition to the measured values, status information on the device is displayed and can be used to monitor device health. Furthermore the device data can be managed and the network parameters can be configured.
Page 190: 16.12 Certificates And Approvals
Technical data Proline Prosonic Flow G 300 HART Data backup Automatic • The most important device data (sensor and transmitter) are automatically saved in the DAT modules • If the transmitter or measuring device is replaced: once the T-DAT containing the...
Page 191 The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. UKCA marking The device meets the legal requirements of the applicable UK regulations (Statutory Instruments).
Page 192 Technical data Proline Prosonic Flow G 300 HART Radio approval The measuring device has radio approval. For detailed information on the radio approval, see the Special Documentation →  195 Additional certification CRN approval Some device versions have CRN approval. A CRN-approved process connection with a CSA approval must be ordered for a CRN-approved device.
Page 193: 16.13 Application Packages
The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 194: 16.14 Accessories
For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. Standard documentation Brief Operating Instructions...
Page 195 Proline Prosonic Flow G 300 HART Technical data Technical Information Measuring device Documentation code Prosonic Flow G 300 TI01385D Description of Device Parameters Measuring device Documentation code Prosonic Flow 300 GP01130D Supplementary device- Safety Instructions dependent documentation Safety instructions for electrical equipment for hazardous areas.
Page 196 Technical data Proline Prosonic Flow G 300 HART Special documentation Contents Documentation code Information on the Pressure Equipment Directive SD01614D Remote display and operating module DKX001 SD01763D Radio approvals for WLAN interface for A309/A310 SD01793D display module Advanced gas analysis...
Page 197: Index
Proline Prosonic Flow G 300 HART Index Index Context menu Calling up ......52 Access authorization to parameters Closing .
Page 198 Index Proline Prosonic Flow G 300 HART Document Firmware Function ....... . 6 Release date .
Page 199 Proline Prosonic Flow G 300 HART Index Maintenance ......158 Maintenance tasks ......158 Onsite display Managing the device configuration .
Page 200 Index Proline Prosonic Flow G 300 HART Sensor adjustment (Submenu) ....102 Settings Setup (Menu) ......79 Adapting the measuring device to the process Simulation (Submenu) .
Page 201 Proline Prosonic Flow G 300 HART Index Events list ......151 Tools I/O configuration .
Page 202 *71633393* 71633393 www.addresses.endress.com...

Endress+Hauser Proline Prosonic Flow G 300 Operating Instructions Manual

Table of Contents

1 About this Document

4 Incoming Acceptance and Product

2 Safety Instructions

3 Product Description

Identification

5 Storage and Transport

6 Mounting

7 Electrical Connection

Operation Options

9 System Integration

10 Commissioning

Configuring the Pulse/Frequency/Switch Output

Parameter

Pulse/Frequency/Switch Output

Parameter Overview with Brief Description

Pulse/Frequency/Switch Output

To N

11 Operation

Process Variables

Input Values

Navigation

Output Values

12 Diagnosis and Troubleshooting

13 Maintenance

14 Repair

15 Accessories

16 Technical Data

Index

Quick Links

Chapters

Related Manuals for Endress+Hauser Proline Prosonic Flow G 300

Summary of Contents for Endress+Hauser Proline Prosonic Flow G 300
