FREEZER - FRIDGE JLFCB5518X
USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for John Lewis JLFCB5518X

Summary of Contents for John Lewis JLFCB5518X

  • Page 1 FREEZER - FRIDGE JLFCB5518X USER MANUAL...
  • Page 2 EN FIRE Warning; Risk of fire / flammable materials EN -2-...

  • Page 3: Table Of Contents

    INdEx BEFORE USING THE APPLIANCE ............4 General warnings ..................... 4 Old and out-of-order fridges or freezer ............. 8 Safety warnings ....................8 Installing and operating your fridge freezer ............9 Before Using your Fridge ................10 Electrical information (For UK type plug) ............10 Dimensions .....................

  • Page 4: Before Using The Appliance

    PART - 1. BEFORE USING THE APPLIANCE General warnings Please read the instruction manual carefully before installing and using your appliance. We are not responsible for the damage occurred due to misuse. Follow all instructions on your appliance and instruction manual, and keep this manual in a safe place to resolve the problems that may occur in the future.
  • Page 5 during transportation and installation to prevent the cooler elements from being damaged. R600a is an environmentally friendly and natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
  • Page 6 of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. • Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
  • Page 7 the freezing of fresh food. • If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance. Service • To repair the appliance contact the Authorised Service Centre. Use original spare parts only.

  • Page 8: Old And Out-Of-Order Fridges Or Freezer

    Old and out-of-order fridges or freezer • If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore, take care not to harm environment when you are discarding your old fridges.

  • Page 9: Installing And Operating Your Fridge Freezer

    • Do not place glass bottles or cans in the ice-making compartment as they will burst when the contents freeze. • Do not place explosive or flammable material in your fridge. Place drinks with high alcohol content vertically in the fridge compartment and make sure their tops are tightly closed.

  • Page 10: Before Using Your Fridge

    • Before using your fridge freezer, wipe all parts with a solution of warm water and a teaspoon of sodium bicarbonate. Then, rinse with clean water and dry. Return all parts to the fridge freezer after cleaning. • Install the two plastic distance guides (the parts on the black vanes -condenser- at the rear) by turning it 90°...

  • Page 11: Dimensions

    dimensions Overall dimensions Overall space required in use 1860 1179 the height, width and depth of the appliance including the handle, the height, width and depth of the plus the space necessary for free appliance without the handle circulation of the cooling air, plus *including the height of the top hinge the space necessary to allow (10 mm)

  • Page 12: The Various Function And Possibilities

    PART - 2. THE VARIOUS FUNCTION ANd POSSIBILITIES Information about New Generation Cooling Technology Fridges with new-generation cooling technology have a different operating system to static fridges. Other (static) fridges may experience a build up of ice in the freezer compartment due to door openings and humidity in the food.

  • Page 13: Display And Control Panel

    display and Control Panel Using the Control Panel 1. Enables the setting of the freezer. 2. Enables the setting of the cooler. 3. Freezer set value screen. 4. Cooler set value screen. 5. Economy mode symbol. 6. Super freeze symbol. 7.

  • Page 14: Door Open Alarm Function

    Notes: • The maximum amount of fresh food (in kilograms) that can be frozen within 24 hours is shown on the appliance label. • For optimal appliance performance in maximum freezer capacity, activate super freeze mode 3 hours before you put fresh food into the freezer. Super freeze mode will automatically cancel after 24 hours, depending on the environmental temperature or when the freezer sensor reaches a sufficiently low temperature.

  • Page 15: Accessories

    Climate class Meaning Ambient Temperature This refrigerating appliance is intended to be used at Tropical ambient temperatures ranging from 16 °C to 43 °C. This refrigerating appliance is intended to be used at Subtropical ambient temperatures ranging from 16 °C to 38 °C. This refrigerating appliance is intended to be used at Temperate ambient temperatures ranging from 16 °C to 32 °C.

  • Page 16: Extra Chill Drawer

    Extra Chill drawer (In some models) Ideal to preserve the taste and texture of fresh cuts and cheese. The pull out drawer assures an environment with a lower temperature compared to the rest of the fridge, thanks to the active circulation of cold air.

  • Page 17: Arranging Food In The Appliance

    PART - 3. ARRANGING FOOd IN THE APPLIANCE Refrigerator compartment • Fresh food compartment is the one marked (on the rating plate) with • To reduce humidity and avoid the consequent formation of frost, always store liquids in sealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of the evaporating liquid and, in time, your appliance will require more frequent defrosting.

  • Page 18: Freezer Compartment

    Food Maximum storage time How and where to store Eggs 1 month On the designated egg shelf Cooked food 2 Days All shelves Freezer compartment • Freezer compartment is the one marked with • The freezer is used for storing frozen food, freezing fresh food, and making ice cubes. •...
  • Page 19 • Food in liquid form should be frozen in plastic cups and other food should be frozen in plastic folios or bags. The table below is a quick guide to show you the most efficient way to store the major food groups in your freezer compartment.
  • Page 20 Maximum storage time Vegetables and Fruits Preparation (months) Cut the stem, cut into two pieces, remove the Pepper 8 - 10 core and boil in water Spinach Wash and boil in water 6 - 9 Remove the leaves, cut the heart into pieces Cauliflower and leave it in water with a little lemon juice 10 - 12...

  • Page 21: Cleaning And Maintenance

    PART - 4. CLEANING ANd MAINTENANCE Disconnect the unit from the power supply before cleaning. Do not wash your appliance by pouring water on it. Do not use abrasive products, detergents or soaps for cleaning the appliance. After washing, rinse with clean water and dry carefully. When you have finished cleaning, reconnect the plug to the mains supply with dry hands.

  • Page 22: Defrosting

    defrosting Your refrigerator performs automatic defrosting. The water formed as a result of defrosting passes through the water collection spout, flows into the vaporisation container behind your refrigerator and evaporates there. • Make sure you have disconnected the plug of your refrigerator before cleaning the vaporisation container.

  • Page 23: Before Calling Your After Sales Service

    PART - 6. BEFORE CALLING YOUR AFTER SALES SERVICE Errors Your fridge will warn you if the temperatures for the cooler and freezer are at improper levels or if a problem occurs with the appliance. Warning codes are displayed in the freezer and cooler indicators.
  • Page 24 If you are experiencing a problem with your refrigerator, please check the following before contacting the after-sales service. Your refrigerator does not operate Check if: • Your fridge is plugged in and switched on • The fuse has blown • Is the temperature adjustment right? •...
  • Page 25 The doors are not opening or closing properly Check if: • There is food or packaging preventing the door from closing • The door compartments, shelves and drawers are placed properly • The door gaskets are broken or torn • Your fridge is level. The edges of the fridge in contact with the door joint are warm Especially during summer (warm weather), the surfaces in contact with the door joint may become warmer during operation of the compressor.

  • Page 26: Hints For Energy Saving

    Hints for Energy Saving 1. Install the appliance in a cool, well-ventilated room, but not in direct sunlight and not near a heat source (such as a radiator or oven) otherwise an insulating plate should be used. 2. Allow warm food and drinks to cool before placing them inside the appliance. 3.

  • Page 27: The Parts Of The Appliance And The Compartments

    THE PARTS OF THE APPLIANCE ANd THE PART - 7. COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. A) Refrigerator compartment 7) Freezer baskets B) Freezer compartment 8) Levelling feet 1) Thermostat box / Interior display 9) Ice box tray...

  • Page 28: Technical Data

    PART - 8. TECHNICAL dATA The technical information is situated in the rating plate on the internal side of the appliance and on the energy label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance.
  • Page 29 52387153 John Lew s Partnersh p 171 V ctor a Street London SW1E 5NN johnlew s.com Please reta n these nstruct ons for future reference...
