85663-A (ENGLISH - UK)
PBH05 SAFETY HARNESS
FULL-BODY HARNESS
EN - Instruction Manual
Do not throw instructions away.
Read and understand instructions before
using this equipment.
Contents
2
4
4
5
5
Lifespan and Quality
6
Specifications and Materials
7
7
7
8
11
12
14
15
Risk Statement
This harness is designed to protect against
falls from height when the approved fall arrest
anchorage points are used. In addition, certain
variants with side D-rings are designed to
prevent falls from height when used as detailed
in this manual.
