Vulcan-Hart C24GA10 Specifications

SPECIFICATIONS:
Two compartment gas convection steamer on cabinet base,
Vulcan-Hart Model No. (C24GA6) (C24GA10). 304 series stain-
less steel exterior. Two stainless steel cooking compartments
with coved interior corners. SuperHeated steam delivered from
the 125,000 BTU/hr. high output stainless steel steam generator
with staged water fill and 2 inch clean out port. Separate 60
minute timer with constant steam feature for each compartment.
Heavy duty doors and door latch mechanisms. Stainless steel
water resistant cabinet base. 6" adjustable stainless steel legs
3
with flanged feet. / " rear gas connection and gas pressure
4
regulator. Requires 120/60/1 power supply, 2.0 amps maximum
draw, with 6 foot power cord and 3 prong plug. Split water line
connection. Treated and untreated water connections. 1
drain connection.
Exterior dimensions:
6 pan: 24"w x 35.4"d x 63.7"h on 6" legs.
10 pan: 24"w x 35.4"d x 73.4"h on 6" legs.
CSA design certified. Certified to NSF Standard #4.
SPECIFY TYPE OF GAS WHEN ORDERING.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32620 (8-06)
1
/ " NPT
2
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL C24GA SERIES
GAS CONVECTION STEAMER ON CABINET BASE
C24GA6 6 pan capacity
C24GA10 10 pan capacity
STANDARD FEATURES
304 series stainless steel exterior.
Two stainless steel cooking compartments with coved interior
corners.
125,000 BTU/hr. stainless steel steam generator with
SuperHeated steam delivery system, staged water fill and
2" clean out port.
Separate 60 minute timer with constant steam feature for
each compartment.
Heavy duty doors and door latch mechanisms.
Stainless steel water resistant cabinet base.
6" adjustable stainless steel legs with flanged feet.
3 / " rear gas connection and gas pressure regulator.
4
Elevation from sea level to 8,999 feet standard.
Requires 120/60/1 power supply, 2.0 amps maximum draw.
Split water line connection. Treated and untreated water
1
connections. 1 / " NPT drain connection.
2
One year limited parts and labor warranty.
OPTIONS
Second year extended limited parts and labor warranty
contract.
Steamer Security Package, includes controls protected by
lockable cover, perforated flue cover, security fasteners &
tack-welds.
ACCESSORIES
12" x 20" stainless steel pans:
- 1" deep (solid)(perforated) Qty.___.
1
- 2 / " deep (solid)(perforated) Qty.___.
2
- 4" deep (solid)(perforated) Qty.___.
Stainless steel pan cover. Qty.___.
Removable sliding self. Qty.___.
Water treatment system.
C.S.I. Section 11420
