Model C24EA6
SPECIFICATIONS
Two compartment electric convection steamer on cabinet
base, Vulcan-Hart Model No. (C24EA6-BSC) (C24EA10-BSC).
Stainless steel exterior. Two stainless steel cooking com-
part ments with coved interior corners. Stainless steel steam
generator with staged water fill and Smart Drain System (timed
drain) with PowerFlush. Separate 60 minute timer with constant
steam feature for each compartment. Heavy duty doors and
door latch mechanisms. Stainless steel water resistant cabinet
base with stainless steel enclosed bottom. 6" adjustable
stainless steel legs with flanged feet. Shipped for 208/60-50/3
electrical service. Can be field converted to 208/60-50/1 and
240/60-50/3 and 240/60-50/1. Split water line connection.
Treated and untreated water connections. 1
connection.
Exterior Dimensions:
6 pan: 24"w x 35.4"d x 58.5"h on 6" legs.
10 pan: 24"w x 35.4"d x 67.9"h on 6" legs.
UL listed. Classified by UL to NSF Std. #4.
P.O. Box 696 Louisville, KY 40201
■
F-35471 (04/10)
S T E A M
C24EA FLOOR SERIES
ELECTRIC CONVECTION STEAMER
⁄ " NPT drain
1
2
a division of ITW Food Equipment Group LLC
Toll-free: 1-800-814-2028
■
Item #
ON CABINET BASE
C24EA6-BSC 6 pan capacity basic controls
C24EA6-DLX 6 pan capacity professional controls
C24EA10-BSC 10 pan capacity basic controls
C24EA10-DLX 10 pan capacity professional controls
STANDARD FEATURES
Stainless steel exterior.
■
Two stainless steel cooking compartments with coved
■
interior corners.
Stainless steel steam generator with staged water fill, and
■
Smart Drain System (timed drain) with PowerFlush.
Separate 60 minute timer with constant steam feature for
■
each compartment.
Heavy duty doors and door latch mechanisms.
■
Stainless steel water resistant cabinet base with enclosed
■
bottom.
6" adjustable stainless steel legs with flanged feet.
■
Shipped for 208/60-50/3 electrical service. Can be field
■
converted to 208/60-50/1 and 240/60-50/3 and
240/60-50/1.
Split water line connection. Treated and untreated water
■
connections. 1 ⁄ " NPT drain connection.
1
2
One year limited parts and labor warranty.
■
OPTIONS
Professional Control Package includes:
- Superheated Steam System
480 volt, 50/60 Hz, 3 phase (Professional Control Package
only).
Steamer Security Package, includes controls protected by
lockable cover, perforated flue cover, security fasteners &
tack-welds.
Second year extended limited parts and labor warranty
contract.
ACCESSORIES (Packaged & Sold Separately)
12" x 20" stainless steel pans:
- 1" deep (solid)(perforated) Qty.____.
- 2 ⁄ " deep (solid)(perforated) Qty.____.
1
2
- 4" deep (solid)(perforated) Qty.____.
Stainless steel pan cover. Qty.____.
Removable sliding shelf. Qty.____.
Water treatment system.
Local: 502-778-2791 Quote & Order Fax: 1-800-444-0602
■ ■
C.S.I. Section 11420
