To setup the GXP2130, ollow the steps below:
1. Connect the handset and main phone case with the phone cord.
2. Connect the LAN port o the phone to the RJ-45 socket o a hub/switch or a
router (LAN side o the router) using the Ethernet cable.
3. Connect the 12V DC output plug to the power jack on the phone; plug the power
adapter into an electrical outlet.
4. The LCD will display provisioning or rmware upgrade inormation. Beore con-
tinuing, please wait or the date/time display to show up.
5. Using the phone embedded web server or keypad conguration menu, you can
urther congure the phone using either a static IP or DHCP.
Tips For Using the Keypad:
Line keys
Soft keys
Menu/OK Key
Volume
Speaker
Send
Standard Keypad
1. To access the MENU, press the round MENU button.
2. Navigate the menu by using the UP/DOWN and LEFT/RIGHT buttons.
3. Press the round MENU button to conrm a menu selection.
4. The phone automatically exits MENU mode with an incoming call, the phone
goes o-hook or the MENU mode is let idle or 60 seconds.
5
Message Waiting
Indicator
Message
Contacts
Hold
Navigation keys
Transfer
Conference
Headset
Mute
Multi-Purpose keys

PHONE CONFIGURATION:

Confgure the GXP2130 using Web Browser:
1. Ensure your phone is powered up and connected to the Internet.
2. Press the UP button to see the IP address.
3. Type the phone's IP address in your PC browser.
4. The deault administrator username and password are "admin"; the deault end-
user username is "user" and the password is "123".
Confgure the GXP2130 using the Keypad:
1. Make sure the phone is idle.
2. Press the MENU button to access the keypad MENU to congure the phone.
3. Select MENU-> Phone-> SIP-> Account to congure settings or SIP Proxy,
Outbound Proxy, SIP User ID, SIP Auth ID and SIP Password.
4. Follow MENU options to congure the basic eatures o the phone. For
example: the IP address i using a static IP. For details, please check GXP2130
User Manual.
5. Please contact your ITSP (Internet Telephony Service Provider) or additional
settings that may be necessary to congure the phone.
Note: For the detailed user manual, please download rom:
http://www.grandstream.com/support
This product is covered by one or more o the U.S. patents (and any oreign patent
counterparts thereto) identied at www.cmspatents.com.
