1.0

INTRODUCTION

This document illustrates operating instructions for Danfoss' Multi-FF series Multiplate quick disconnect coupling. This user
manual also provides guidance about preventive maintenance of Multiplate coupling and steps for servicing in case of
malfunction.
2.0

SAFETY INSTRUCTIONS

It is recommended to wear hand-gloves while making connection or disconnection of Danfoss' Multi-FF device.
•
Hold top plate / movable plate on hose lines or on to a surface perpendicular to handle strips, to avoid nger
•
entrapment during engagement with xed plate.
Once two plates / sub-systems are engaged, remove your hand off the plate and only rotate the handle. Do not put
•
hand/fingers in between 2 plates.
Ensure that ngers are not entrapped in between bottom/ xed plate and handle of the device during operation
•
Ensure absence of pressure inside the Multi-FF before initiatingdisconnection of system or carrying out any
•
maintenance work.
3.0

OPERATING CONDITIONS

This section covers general operating conditions to obtain long life of multiplate coupling without unpredicted failure.
It is advisable to use multi plate coupling under same operation conditions.
The allowed operating temperature lies between -20°C to 100°C. This is operating temperature of multiplate coupling
assembly and subjected to change based on seal material con guration of Coupling half. The permitted storage
temperature lies between +10°C and +35°C.
The maximum operating relative air humidity should not exceed 75%. Similarly, it should not exceed 60% for storage.
Dust & vibration free environment will ensure correct functionality of multiplate coupling.
Maximum operating pressure for multiplate coupling is as follow. These are tested at 1:4 times operating pressure and it
is advisable that system pressure for continuous service shall not exceed maximum operating pressure recommended
below.
N o. o f
M u l t i - F F Par t
co u p l i n g
n u m b e r p o r t s
4MFC-10CUP15LS11 4
4MFCE1-12CUP15L 4
4MFC-12CUP15L 4
4MFC-1015L 4
4MFCE1-1015L 4
6MFC-1015L 6
3
Co u p l i n g M a x . o p e r a t i n g
b o d y s i z e p r e s s u r e
ISO 10 250 bar
ISO 12 350 bar
ISO 12 350 bar
ISO 10 350 bar
ISO 10 350 bar
ISO 10 350 bar
