E-Code Displayed Alarm
4404 Engine Knock 1
4415 Engine Knock 1
4417 Engine Knock 1
4502 Engine Ignition Coil
#1
4503 Engine Ignition Coil
#1
4504 Engine Ignition Coil
#1
4507 Engine Ignition Coil
#1
4602 Engine Ignition Coil
#2
4603 Engine Ignition Coil
#2
4604 Engine Ignition Coil
#2
4607 Engine Ignition Coil
#2
4702 Engine Ignition Coil
#3
4703 Engine Ignition Coil
#3
4704 Engine Ignition Coil
#3
4707 Engine Ignition Coil
#3
4802 Engine Ignition Coil
#4
4803 Engine Ignition Coil
#4
4804 Engine Ignition Coil
#4
4807 Engine Ignition Coil
#4
4900 Engine Fuel Valve
1 Position
4901 Engine Fuel Valve
1 Position
4902 Engine Fuel Valve
1 Position
4903 Engine Fuel Valve
1 Position
Technical Manual Power Zone 410 Controller
Alarm/Warning Description
Engine Knock Sensor Fault—Voltage below normal range; shorted to low
A
source; open circuit.
W Engine Knock Sensor—Data valid but above normal operating range; least
severe level.
W Engine Knock Sensor—Data valid but below normal operating range; least
severe level.
A Ignition Coil 1 Fault—Data erratic, intermittent, or incorrect.
A Ignition Coil 1 Fault—Voltage above normal range; shorted to high source.
A Ignition Coil 1 Fault—Voltage below normal range; shorted to low source; open
circuit.
A Ignition Coil 1 Fault—Mechanical system not responding correctly.
A Ignition Coil 2 Fault—Data erratic, intermittent, or incorrect.
A Ignition Coil 2 Fault—Voltage above normal range; shorted to high source.
Ignition Coil 2 Fault—Voltage below normal range; shorted to low source; open
A
circuit.
Ignition Coil 2 Fault—Mechanical system not responding correctly.
A
A Ignition Coil 3 Fault—Data erratic, intermittent, or incorrect.
A Ignition Coil 3 Fault—Voltage above normal range; shorted to high source.
A Ignition Coil 3 Fault—Voltage below normal range; shorted to low source; open
circuit.
A Ignition Coil 3 Fault—Mechanical system not responding correctly.
A Ignition Coil 4 Fault—Data erratic, intermittent, or incorrect.
A Ignition Coil 4 Fault—Voltage above normal range; shorted to high source.
A Ignition Coil 4 Fault—Voltage below normal range; shorted to low source; open
circuit.
Ignition Coil 4 Fault—Mechanical system not responding correctly.
A
Fuel Mixer—Data valid but above normal operating range; high severe level.
A
A Fuel Mixer—Data valid but below normal operating range; high severe level.
A Fuel Mixer—Data erratic, intermittent, or incorrect.
A Fuel Mixer—Voltage above normal range; shorted to high source.
Internal Alarms/Warnings
