Protect
All Lock
Custom Lock
Advanced
User Apps Installation
Application Lock
Enable USB Drive
Delay Time
Reset
Setup
Setup
App Icon Layout
PIP
PIP Enable
PIP Source
PIP Position
PIP Size
Tile Matrix
Tile Matrix
H Monitors
V Monitors
Position
Tile Comp
Human Sensing*
1
Human Sensing
Auto Off
Disable
Custom
Locks all buttons.
All buttons are locked except for those that can be individually unlocked for custom settings.
See
page 38
and
page
39.
Sets whether or not to allow installation of apk application files.
NOTE:
•
3rd party applications of this type are not guaranteed to work and are outside the scope of
support and warranty.
•
Always verify the authenticity and safety of an application before installation.
Some applications may affect the operation of other applications and of this monitor.
Virus infections or, data corruption, falsification, or theft is possible.
Sets whether or not to lock the use of the following applications.
Enables or disables the availability of some of the monitor's pre-installed applications. When enabled, all
the following applications are locked and cannot be used:
• Updater
• Web Browser
Sets whether or not to allow the use of a USB flash drive.
Delays the monitor from turning on for the amount of time set when the POWER ON button is pressed.
The delay can be set between 0 and 50 seconds.
Resets all security menu settings back to factory setting, except for [Delay Time] and [Security Settings].
Sets the icons of the applications to be arranged on the home screen.
TIP:
This function is released when turning off the main power switch.
Displays a sub-screen inside a main screen.
TIP:
•
PIP is only available for use in the Android source for its main screen.
•
This function is available only when [Screen Rotation] is set to [Landscape].
Selects the input signal of the sub-screen: [HDMI1]/[HDMI2]/[HDMI3]/[USB-C].
Selects the position of the sub-screen: [Top-Left]/[Top-Right]/[Bottom-Left]/[Bottom-Right].
Selects the size of the sub-screen: [Small]/[Medium]/[Large].
TIP:
This function is not available when the HOME screen is shown.
Allows one image to be expanded and shown over multiple screens (up to 25) through a distribution
amplifier.
Number of monitors arranged horizontally.
Number of monitors arranged vertically.
Sets the section of the tiled image to view on the current monitor.
Adjusts the image to compensate for the gap between monitors.
Automatically adjusts the backlight and volume levels based on whether or not a human presence is
detected in front of the monitor.
TIP:
Human sensing is automatically disabled if [Auto Input Change] is set while [Human Sensing] is
active.
[Power Save] is disabled when [Auto Off] or [Custom] is selected in [Human Sensing].
The monitor's backlight automatically turns off, and the volume mutes when no human presence is
detected during the period set at [Waiting Time].
When a person is near the monitor again, the monitor will automatically return to normal mode.
Human sensing function is off.
The monitor's input signal, backlight and volume levels automatically shift to the setting at [Input Select],
[BackLight] and [Volume] when no human presence is detected during the period set at [Waiting Time].
When a person is near the monitor again, the monitor will automatically return the backlight and volume to
normal levels and reproduce the input signal selected for [Input Select].
English−61
