INSTALLATION INSTRUCTIONS
A98USMV
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to
the potential for personal injury or death.
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional installer (or
equivalent), service agency or the gas supplier.
NOTICE
A thermostat is not included and must be ordered
separately.
•
A Comfort Sync
®
communicating applications.
•
In non-communicating applications, a traditional
non-communication thermostat may be used.
In all cases, setup is critical to ensure proper system
operation.
Field wiring for both communicating and non-
communicating applications is illustrated in these
instructions.
Manufactured By
Allied Air Enterprises LLC
A Lennox International, Inc. Company
215 Metropolitan Drive
West Columbia, SC 29170
508364-01
This manual must be left with the homeowner for future reference.
WARNING
thermostat must be used in
Warm Air Gas Furnace
Upflow/Horizontal Left/Right
Air Discharge Direct Vent

Table of Contents

Gas Furnace ................................................................4
Shipping and Packing List ...........................................4
Safety Information .......................................................4
General ........................................................................6
Installation ...................................................................6
Filters .........................................................................10
Duct System ..............................................................10
Venting Practices .......................................................12
Gas Piping .................................................................27
Electrical ....................................................................30
Blower Performance ..................................................45
Gas Valve Operation .................................................50
Unit Start-Up ..............................................................50
Other Unit Adjustments..............................................54
Heating Sequence of Operation ................................55
Service.......................................................................56
Integrated Control Diagnostic Codes.........................58
Repair Parts List ........................................................65
As with any mechanical equipment, personal injury can
result from contact with sharp sheet metal edges. Be
careful when you handle this equipment.
*P508364-01*
Issue 2346
CAUTION
(P) 508364-01
Page 1 of 74
