Warm air gas furnace upflow/horizontal left air discharge direct vent & non-direct vent
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in
manuals, be alert to the potential for personal injury or death.
Unit Dimensions ..........................................................2
Parts Arrangement.......................................................3
Gas Furnace ................................................................4
Shipping and Packing List ...........................................4
Safety Information .......................................................5
General ........................................................................6
Combustion, Dilution & Ventilation Air .........................7
Installation .................................................................10
Filters .........................................................................13
Duct System ..............................................................13
As with any mechanical equipment, personal injury can
result from contact with sharp sheet metal edges. Be
careful when you handle this equipment.
Manufactured By
Allied Air Enterprises LLC
A Lennox International, Inc. Company
215 Metropolitan Drive
West Columbia, SC 29170
507281-06
INSTALLATION INSTRUCTIONS
A95UH2E & 95G2UHE
Warm Air Gas Furnace
Upflow/Horizontal Left Air Discharge
Direct Vent & Non-Direct Vent
This manual must be left with the homeowner for future reference.

Table of Contents

CAUTION
Save these instructions for future reference
Venting Practices .......................................................16
Condensate Piping ....................................................34
Gas Piping .................................................................38
Electrical ....................................................................41
Unit Start-Up ..............................................................50
Other Unit Adjustments..............................................52
Blower Performance ..................................................53
Service.......................................................................55
Planned Service ........................................................57
Repair Parts List ........................................................57
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional installer (or
equivalent), service agency or the gas supplier.
Issue 1724
WARNING
*507281-06*
*507281-06*
Page 1 of 58
