- Page 1 EX4600 Quick Start Published RELEASE 2023-11-06...
-
Page 2: Table Of Contents
Table of Contents Step 1: Begin Meet the EX4600 | 1 Install the EX4600 | 2 What’s in the Box? | 2 What Else Do I Need? | 3 Rack It | 3 Power On | 4 Step 2: Up and Running... -
Page 3: Step 1: Begin
EX4600. We’ve simplified and shortened the installation and configuration steps, and included how-to videos. You’ll learn how to install an AC-powered EX4600, power it up, and configure basic settings. NOTE: Are you interested in getting hands-on experience with the topics and operations covered... -
Page 4: Install The Ex4600
• Two expansion slots for optional expansion modules The EX4600 is available in AC-powered or DC-powered models with air-flow in or air-flow out cooling. You can install the switch in a two-post or four-post rack. In this guide, we show you how to install an AC-powered EX4600 in a four-post rack. -
Page 5: What Else Do I Need
What Else Do I Need? • Someone to help you secure the switch to the rack • A number two Phillips (+) screwdriver • Eight rack mount screws • Cage nuts and washers, if your rack requires them • Grounding lug and attached cable •... -
Page 6: Power On
9. Double-check that the mounting brackets on each side of the rack are level. Power On Now that you’ve installed your EX4600 in the rack, you’re ready to connect it to power. 1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other end to one of the ESD grounding points on the chassis. - Page 7 8. If the AC power source outlet has a power switch, turn it on. The EX4600 powers up as soon as you connect it to power; there is no power switch. When the AC and DC LEDs on each power supply are solid green, the EX4600 is ready to use.
-
Page 8: Step 2: Up And Running
Plug and Play | 6 Customize the Basic Configuration | 6 Now that the EX4600 is powered on, let’s do some initial configuration to get it up and running on the network. It’s simple to provision and manage the EX4600 using the CLI. - Page 9 • Data—8 • Parity—None • Stop Bits—1 • DCD State—Disregard Connect the console (CON) port on the switch’s management panel to a laptop or desktop PC using the RJ-45 cable and RJ-45 to DB-9 adapter (not provided). NOTE: If your laptop or desktop PC doesn't have a serial port, use a serial-to-USB adapter (not provided).
- Page 10 [edit] root@# set system services telnet NOTE: When Telnet is enabled, you cannot log in to the EX4600 through Telnet using root credentials. Root login is allowed only for SSH access. 12. Commit the configuration. Your changes become the active configuration for the switch.
-
Page 11: Step 3: Keep Going
What’s Next? | 9 General Information | 10 Learn With Videos | 11 Congratulations! Now that you’ve done the initial configuration, your EX4600 switch is ready to use. Here are some things you can do next: What’s Next? If you want to... -
Page 12: General Information
(Continued) If you want to Then See, automate, and protect your network with Juniper Visit the Security Design Center Security Get hands-on experience with the procedures covered Visit Juniper Networks Virtual Labs and reserve your in this guide free sandbox. You’ll find the Junos Day One Experience sandbox in the stand alone category. -
Page 13: Learn With Videos
Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice.
