Combustion Specifications
Jøtul F 500
1
Heat Output Range:
12,000 to 34,700 BTU/hr.
Max. Heat Output:
70,000 BTU/hr.
2
Heating Capacity:
Up to 2000 sq. ft.
2
Maximum Burn Time:
Up to 9 hours
3
EPA Efficiency:
HHV: 73.94%
4
CO Emissions:
112.22 g/hr
5
Pariculate Emissions:
3.2 g/hr
Fuel: Up to 24" Logs (609 mm)
.
1
Heat Output Range results are determined during specific
emissions tests established by the EPA.
The Maximum Heat Output value is representative of a more
frequent re-fueling cycle than specified in the EPA High Heat
Output test method.
2
Heating Capacity and Maximum Burn Time will vary depend-
ing on design of home, climate, wood type and operation
3
EPA Validated Efficiency:
High Heat Value and Low Heat Value are obtained per CSA
B415.1-10 test method. HHV calculation encompasses all
products of combustion, including H2O condensation. LHV
calculation includes H2O in its vapor state. Simply put, HHV
assumes all the water component is in a liquid state (con-
densed) at the end of combustion and that heat recovered
from condensation can be put to use.
Carbon Monoxide Emissions rate results from Test Method
4
CSA B415.1-10.
Particulate Emissions rate is obtained using EPA Test Method
5.
28-5H.
See Sect. 5.0 of this manual for important information
regarding the safe, proper, and most efficient operation
of your stove.
W h e n i n s t a l l i n g , o p e rat i n g a n d m a i nt a i n i n g yo u r
Jøtul F 500 woodstove, follow the guidelines presented in
these instructions, and make them available to anyone using or
servicing the stove.
Your city, town, county or province may require a building permit
to install a solid fuel burning appliance.
In the U.S., the National Fire Protection Association's Code,
NFPA 211, Standards for Chimneys, Fireplaces, Vents and Solid Fuel
Burning Appliances, or similar regulations, may apply to the
installation of a solid fuel burning appliance in your area.
In Canada, the guideline is established by the CSA Standard, CAN/
CSA-B365-M93, Installation Code for Solid-Fuel-Burning Appliances
and Equipment.
Always consult your local building inspector or authority having
jurisdiction to determine what regulations apply in your area.
Safety Notices
• BURN SOLID, NATURAL WOOD FUEL ONLY. DO NOT BURN ANY
OTHER FUEL.
• DO NOT USE CHEMICALS OR FLUIDS TO START A FIRE. DO NOT
BURN GARBAGE OR FLAMMABLE FUELS.
• DO NOT USE A GRATE OR ELEVATE THE FIRE. BUILD THE FIRE
DIRECTLY ON THE HEARTH.
LHV: 79.88%
• IF THIS ROOM HEATER IS NOT PROPERLY INSTALLED, A HOUSE
FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE
INSTRUCTIONS IN THIS MANUAL. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY
INJURY, OR LOSS OF LIFE.
• CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRIC-
TIONS AND INSTALLATION INSPECTION REQUIREMENTS IN
YOUR AREA.
• ANY EXISTING CHIMNEY SYSTEM MUST BE INSPECTED BEFORE
INSTALLATION OF THIS APPLIANCE.
• DO NOT CONNECT THIS STOVE TO ANY AIR DISTRIBUTION
DUCT OR SYSTEM.
• EXTREMELY HOT WHILE IN OPERATION! KEEP CHILDREN,
CLOTHING, AND FURNITURE AWAY. CONTACT WILL CAUSE SKIN
BURNS. USE A CHILD GUARD SCREEN TO PREVENT ACCIDENTAL
CONTACT BY SMALL CHILDREN.
• INSTALL SMOKE DETECTORS IN THE LIVING AREA AND BED-
ROOMS OF YOUR HOME. TEST THEM REGULARLY AND INSTALL
FRESH BATTERIES TWICE ANNUALLY.
WHEN INSTALLED IN THE SAME ROOM AS THE STOVE, A SMOKE
OR CARBON MONOXIDE DETECTOR SHOULD BE LOCATED AS
FAR FROM THE STOVE AS POSSIBLE TO PREVENT THE ALARM
SOUNDING WHEN ADDING FUEL.
• Avoid creating a low pressure condition in the room where
the stove is operating. Be aware that operation of an exhaust
fan or clothes dryer can create a low pressure area and conse-
quently promote flow reversal through the stove and chimney
system. In some cases, the optional Outside Air Kit #154335
can be used to alleviate this condition. The chimney and build-
ing, however, always work together as a system - provision of
outside air, directly or indirectly to an atmospherically vented
appliance will not guarantee proper chimney performance.
Consult your local Jøtul authorized dealer regarding specific
installation/performance issues.
• Jøtul strongly recommends that this stove be installed by
a professional solid fuel technician, or that you consult one
if you do the work yourself. Also, consult your insurance
company regarding any other specific requirements.
139681_R06 F 500 Oslo 1/20
3
