RTS CSI-200 User Instructions

Coaxial system interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
U
I
SER
NSTRUCTIONS
M
CSI-200
ODEL
C
S
I
OAXIAL
YSTEM
NTERFACE
9350-7676-000 Rev B, 5/2001

Advertisement

Table of Contents
loading

Related Manuals for RTS CSI-200

Summary of Contents for RTS CSI-200

  • Page 1 NSTRUCTIONS CSI-200 ODEL OAXIAL YSTEM NTERFACE 9350-7676-000 Rev B, 5/2001...

  • Page 2: Proprietary Notice

    The sole obligation of Telex during the warranty period is to provide, without charge, parts and labor necessary to remedy covered defects appearing in products returned prepaid to Telex. This warranty does not cover any defect,...

  • Page 3: Return Shipping Instructions

    If a repair is necessary, contact the dealer where this unit was purchased. If repair through the dealer is not possible, obtain a RETURN AUTHORIZATION from: Customer Service Department Telex Communications, Inc. Telephone: (800) 828-6107 Fax: (800) 323-0498 DO NOT RETURN ANY EQUIPMENT DIRECTLY TO THE FACTORY WITHOUT FIRST OBTAINING A RETURN AUTHORIZATION.
  • Page 4 End-User License Agreement for Telex® Software IMPORTANT - Please read this document carefully before using this product. THIS DOCUMENT STATES THE TERMS AND CONDITIONS UPON WHICH TELEX COMMUNICATIONS, INC. (the “COMPANY”) OFFERS TO LICENSE THE INSTALLED SOFTWARE OR PROGRAM (the “SOFT- WARE”) FOR USE WITH THE PRODUCT IN WHICH IT WAS INSTALLED.

  • Page 5: Table Of Contents

    Keypanel to CSI-200 Connections ........
  • Page 6 This page left blank intentionally.
  • Page 7 Figure 1.2 CSI-200 rear panel......... . 1-2 Figure 1.3 Single channel CSI-200 configuration....... . 1-3 Figure 2.1 MCP1 dual rack mount kit.
  • Page 8 This page left blank intentionally.

  • Page 9: Introduction

    CSI-200 is quick and simplified with no user settings. Channel cabling and power connections are all that is needed to set up the interface. Each CSI-200 will monitor its interface lines to automatically determine the type of equipment to which it is attached. Each of the two channels of the CSI-200 are independent and may operate in either the keypanel or matrix modes.

  • Page 10: Rear Panel Features

    There are three typical configurations when using the CSI-200: 1. Matrix to Keypanel One CSI-200 is located at a matrix and the other CSI-200 at a keypanel. Each CSI-200 is cabled to their respective matrix or keypanel via a standard CAT V cable. A dual-gender 9-pin port for both channels is provided at the rear of the CSI-200 to accommodate connection to either matrix or keypanel.

  • Page 11: Matrix To Two Keypanels, Three Csi-200S

    3. Matrix to Two Keypanels, Three CSI-200s With three CSI-200s, one CSI-200 is located at the matrix and the other two CSI-200s at their respective keypanels. The maximum distance between the two keypanels is extended to 2,000 feet plus the usual CAT V cabling configuration separation distance. This assumes that the matrix is located at the center of the configuration.
  • Page 12 This page left blank intentionally. C S I - 2 0 0 U s e r I n s t r u c t i o n s...

  • Page 13: Installation

    Note Mounting the CSI-200 The CSI-200 can be mounted using a wide variety of MCP mounting kits. Remember to leave adequate room behind the unit for cable access. There are no special ventilation requirements. Some of the possible configurations are: Dual Rack Mount (Figure 2.1)

  • Page 14: Figure 2.1 Mcp1 Dual Rack Mount Kit

    MCP1 dual rack mount kit. Figure 2.1 MCP2 single rack mount kit. Figure 2.2 Figure 2.3 MCP3 console mount kit. MCP4 tandem mount kit Figure 2.4 C S I - 2 0 0 U s e r M a n u a l...

  • Page 15: Matrix To Csi-200 Connections

    Note Figure 2.5 9-pin intercom cable wiring diagram. When connecting a CSI-200 to a matrix, treat the CSI-200 as if it were a keypanel. When Note connecting a CSI-200 to a keypanel, treat the CSI-200 as the matrix. Keypanel to CSI-200 Connections The CSI-200 requires a standard RTS 9-pin D-Sub intercom cable.

  • Page 16: Csi-200 To Csi-200 Connections

    BNC connectors on each end. The use of Belden 8281 or equivalent is recommended. Refer to Figure 2.6 for an example of the cable. To connect the CSI-200 located at the matrix end of the link to the CSI-200 located at the keypanel end on the link do the following: Plug one end of the cable into the appropriate coax connector on the rear panel of the CSI- 200 attached to the matrix.

  • Page 17: Specifications

    Audio Performance SNR @ 8 dBu (A-weighted)..>70 dB THD+N @ 8 dBu (un-weighted)..<0.1% Ports Keypanel/Matrix: Coax I/F: Power Line Voltage: Frequency: Consumption: Physical...

  • Page 18: Operating Conditions

    Operating Conditions Temperature: Humidity: Storage Conditions Temperature: Humidity: Agency Approvals UL, CSA, CE, C-Tick C S I - 2 0 0 U s e r M a n u a l -4°F to 122°F (-20°C to 50°C) 0 to 95%, non-condensing -40°F to 185°F (-40°C to 85°C) 0 to 95%, non-condensing...
