- Page 1 DMX129DAB DMX129BT MONITOR WITH RECEIVER INSTRUCTION MANUAL • Updated information (the latest Instruction Manual, etc.) is available from <https://www.kenwood.com/cs/ce/>. Model name indication position See “Removing the trim plate” (P.21) Trim plate © 2023 JVCKENWOOD Corporation B5K-1096_ref_E_En_03 3-12, Moriyacho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, Japan...
-
Page 2: Table Of Contents
Contents Before use Before use ................. 2 How to read this manual How to read this manual ................... 2 • The panels shown in this guide are examples used to Precautions ........................ 2 provide clear explanations of the operations. For this Getting Started ............... -
Page 3: Getting Started
Getting Started [Reverse with ATT (-20dB)] Turn the ignition key of your car to ACC. The unit is turned on, please read the warning and When the gear is shifted to the reverse (R) press “Agree” to enter the screen. position, the volume of the device is adjusted. -
Page 4: Basics
Basics Basics Ñ Turning off the power Functions of the Buttons on the Front Panel Press and hold the <8MENU> button. Ñ Adjusting the volume Press the <+> or <–> button. 1 Remote Sensor • Receives the remote control signal. 2 8MENU •... -
Page 5: Home Screen Descriptions
HOME screen appears. 1 Clock display Touch to displays the Clock screen. 2 Switches to the digital radio broadcast.* (P.6) * DMX129DAB only 3 Switches to the radio broadcast. (P.7) 4 [USB] Plays files on a USB device. (P.8) [iPhone] Plays an iPhone. -
Page 6: Digital Radio
Digital Radio (DMX129DAB) Digital Radio (DMX129DAB) Digital Radio Basic Operation Digital Radio Setup Press the <8MENU> button. Touch [ ]. Touch [Digital Radio]. Set each item as follows. Ñ Source control screen [Service List] Displays the Service List screen. • [ ] : Touch and then touch [Yes] to find the latest 1 Displays the information of the current service: service list. -
Page 7: Radio
Radio Radio Radio Basic Operation Radio Setup Press the <8MENU> button. Touch [ ]. Touch [Radio]. Set each item as follows. Ñ Source control screen [Auto Store] Automatically searches and stores the 6 stations with 1 Displays the information of the current station: the strongest signals for the selected band. -
Page 8: Usb
Ñ For Video playback Preparation When the operation buttons are not displayed Ñ Connecting a USB device on the screen, touch the display. Remove the cap of the USB terminal. Connect the USB device with the USB cable. The unit reads the device and playback starts. Ñ... -
Page 9: Iphone
iPhone iPhone Preparation Playback operations Ñ Control the music you are listening to on Ñ Connecting iPhone the source control screen. • For details about connecting iPhone, see page 23 . Remove the cap of the USB terminal. Connect the iPhone. The unit reads the device and playback starts. -
Page 10: Mirroring
Mirroring Mirroring Ñ To disconnect the Android smartphone Preparation Press the <8MENU> button. You can display and control the App on the unit while your smartphone is connected to the USB Touch a source other than [Mirroring]. terminal. Detach the Android smartphone ✎... -
Page 11: External Components
External Components External Components Using external audio/video players Rear view camera To use a rear view camera, the REVERSE lead Ñ Starting playback connection is required. For connecting a rear view camera. (P.22) Connect an external component to the AV-IN input terminal. -
Page 12: Learning Function Of Steering Remote
External Components Ñ To adjust the parking guidelines Learning function of steering remote ✎ NOTE • Install the rear view camera in the appropriate This function is available only when your vehicle position according to the instruction manual is equipped with the electrical steering remote supplied with the rear view camera. -
Page 13: Bluetooth
Bluetooth units. Delete unnecessary registration. (P.13) Turn on the Bluetooth function on your smartphone/cell-phone. Search the unit (”DMX129DAB”/”DMX129BT”) from your smartphone/cell-phone. If a PIN code is required, enter the PIN code (“0000”). • appears when the Bluetooth smartphone is connected. -
Page 14: Receive A Phone Call
Bluetooth Receive a phone call Make a phone call Touch [Û]. Press the <8MENU> button. Touch [TEL]. See the table below for each operation method. • [Ý] : Reject an incoming call. Ñ Operations during a call Call by entering a phone number 1) Enter a phone number with number keys. -
Page 15: Playing Bluetooth Audio Device
Bluetooth Call by voice 1 Displays the information of the current file. You can make a voice call using the voice 2 Playing time/File number recognition function of the Bluetooth smartphone. Play time bar : For confirmation of current playing 1) Touch [ ... -
Page 16: Controlling Audio
Controlling Audio Controlling Audio Equalizer Control You can adjust various settings such as audio balance or subwoofer level. Press the <AUD> button. Press the <AUD> button. Touch [Equalizer]. See the below for each operation method. Set each item as follows. Controlling General Audio 1 You can select frequency bar and adjust its level. -
Page 17: Speaker / Xover Setup
Controlling Audio Speaker / X’over setup Listening Position DTA Press the <AUD> button. Press the <AUD> button. Touch [Speaker / X’over]. Touch [Position DTA]. Touch the speaker to set up. Touch [Delay]. Touch [T] or [U] to adjust the delay time of the selected speaker. -
Page 18: Remote Control
Remote control Ñ Basic Operation This unit can be operated using the remote control KCA-RCDV340 (optional accessory). • Aim the remote control directly at the remote sensor on the faceplate. CAUTION • DO NOT expose the remote sensor to bright light •... -
Page 19: Installation
Installation Installation Before Installation • Connect the speaker wires correctly to the terminals to which they correspond. The unit may be Before installation of this unit, please note the damaged or fail to work if you share the ¤ wires or following precautions. -
Page 20: Installing The Unit
Installation Ñ Supplied accessories for installation Installing the unit Ñ Non-Japanese cars (3 m) (2 m) Bend the tabs of the mounting sleeve with a screwdriver or similar utensil and attach it in place. Ñ Installation procedure NOTE 1) To prevent a short circuit, remove the key from •... - Page 21 Installation Ñ Microphone unit Ñ Removing the unit 1) Check the installation position of the microphone 1) Remove the trim plate by referring to step 1 in (accessory 4). “Removing the trim plate”. 2) Clean the installation surface. 2) Insert the extraction key (accessory 2) deeply into 3) Remove the separator of the microphone the slot as shown.
- Page 22 AV-IN audio input (Left; White, Right; Red) AV-IN visual input (Yellow) CAM IN VIDEO OUT VIDEO IN USB maximum power supply current : Visual Output (Yellow) DC 5 V = 1.5 A Sold separately Rear view camera input (Yellow) DMX129DAB only...
- Page 23 • In case the car does not have an ignition wire, use a commercially available interface. M4x6 REAR OUT FRONT OUT AV IN CAM IN VIDEO OUT VIDEO IN USB maximum power supply current : DC 5 V = 1.5 A Sold separately DMX129DAB only English |...
-
Page 24: About This Unit
About this Unit About this Unit Ñ Acceptable Video files More information Video Video codec Audio codec Ñ Usable USB device format MPEG-1 MPEG-1 MPEG Audio Layer 2 This unit can play MPEG1/ MPEG2/ MPEG4/H.264/ (.mpg, .mpeg) MKV/ MP3/WMA/ AAC/ WAV/ FLAC/ OGG files stored in a USB mass storage class device. -
Page 25: Troubleshooting
About this Unit Ñ AV-IN Troubleshooting No picture appears on the screen. What appears to be trouble is not always serious. • Turn on the video component if it is not on. Check the following points before calling a service •... -
Page 26: Specifications
Pixel Arrangement : AVRCP (V1.5) (Audio/Video Remote Control Profile) : RGB striped arrangement : PBAP (Phonebook Access Profile) Back Lighting : LED Ñ DAB section (DMX129DAB) Ñ USB interface section Frequency Range BAND III: 174.928 – 239.200 (MHz) USB Standard Sensitivity : USB 2.0 High Speed... - Page 27 : 178 × 100 × 75 mm (w/o sleeve) Ñ Audio section Weight Maximum Power (Front & Rear) DMX129DAB: 1.3 kg : 45 W × 4 DMX129BT: 1.2 kg (Including Sleeve and Trim plate) Full Bandwidth Power (Front & Rear) Full Bandwidth Power (at less than 1% THD) : 16 W ×...
-
Page 28: Copyrights
