lock (47) together releases
the device quickly from the
harness in a dangerous situ-
ation.
1. Wear the carrying harness (19) like a
backpack. The clip must be situated on
the chest.
2. Adjust the strap length so that the body
protection (20) is level with the hip.
3. Open the quick-release lock (47).
4. Push open the snap hook.
5. Attach the snap hook to the eyelet (6)
on the tube shaft of the device.
6. Clip the quick-release lock (47) back
together with the device.
Place the body protection (20) on
your hip between your body and
the device.
While wearing the carrying harness,
ensure that the pad is placed on your
shoulders to increase comfort.

Sliding the carrying eye

Select the appropriate position for the car-
rying harness eyelet according to whether
you are using a spool/3-toothed blade or
pruner/hedge trimmer.
You can slide the carrying eye (
better distribute the weight of the device.
1. Loosen the screw (48) on the eyelet
(6) for the carrying harness, using the
hexagon socket wrench (21) from the
storage ( 31).
A
2. Slide the eyelet (6) to the appropriate
position.
3. Tighten the screw (48) again.
For the trimmer/3-tooth blade operation:
Without touching it by hand, the device
attached to the harness should

allow the spool to rest lightly on the
ground

balance the blade approximately 20
cm above the ground.
1. Loosen the screw (48) on the carrying
harness eye with the hexagon socket
wrench (21) and tighten it slightly.
2. Depending on the cutting tool, balance
the tool according to the criteria men-
tioned above by moving the eyelet (6)
along the tube shaft (4).
3. Tighten the screw (48) when the device
is in the desired position.
1. Remove the rechargeable batteries.
2. Place the device on the ground in a
6) to
A
stable position.
3. Block the mounting spindle (52) using
the hexagon socket wrench (22) as de-
picted.
4. Place the 3-toothed blade onto the
mounting spindle (52). The blade can
be used on both sides.
5. Fasten the blade using the thinner was-
her (53), conical spring washer (54)
and nut (55).
Note the left-hand thread!
Insert the nut (55) into the conical
Assemble the 3-tooth
blade
Whenever you use the
3-tooth blade, the protective
cover without extension must
be used. (See Chapter: "Re-
moving/mounting the protec-
tive cover extension")
