59 Notch, spool
60 Groove, spool
61 Oil passage
62 Lubrication nipple, pole-mounted
pruner
63 Screw, gear lubrication

Safety features

29 Safety switch
A
The switch lock must be unlocked
in order to switch on the device.
30 Start switch
The device switches off immedia-
tely once the start switch is relea-
sed.
19 Carrying harness
Ensures the load is evenly spread
across the shoulders, back, hips
and thighs.

Function Description

The device is powered by an electric
motor. The device is equipped with a
hedge trimming attachment (with safety
cutter bars), a pole-mounted pruning
attachment (with blade and saw chain)
and a lawn trimming attachment (with
thread spool or 3-tooth blade). The device
can only be operated whilst the safety
switch is pressed to protect the user.
Please refer to the descriptions below for
information on how the operating elements
work.

Technical Data

Cordless Multi-Tool .......... PGKGA 40-Li B2
Motor voltage U .......... 40 V
Current strength I ............................ 16 A
Motor idle speed n
(2 x 20 V)
.................7500 rpm
0
Protection type.................................IPX0
Weight, motor unit ........................2.3 kg
Weight (operationally ready)
Pole-mounted pruner ............ ca. 4.5 kg
Hedge trimmer .................... ca. 5.0 kg
Trimmer .............................. ca. 4.3 kg
Brush cutter ......................... ca. 4.3 kg
Hedge trimmer
Cutting length ......................... 410 mm
Max. recommended
branch thickness ....................... 15 mm
Idle speed (without load) n
Cuts/min ....................................2400
Vibration on handgrip
(a ) ..............3.690 m/s
h
Vibration on round handle
(a ) ............. 4.320 m/s
h
Sound pressure level
(L ) .....................89.9 dB; K
pA
Sound power level (L
measured .... 100.9 dB, K
guaranteed .......................... 106 dB
Pole-mounted pruner
Blade .... Trilink 8" - M1430833-1041TL
Blade length .....................8"/195 mm
Cutting length ..................ca. 180 mm
Sprocket teeth ................................5
Chain ................ Trilink 8" - CL14333TL
Chain thickness ..................... 1.1 mm
Chain speed v
0
Oil tank volume ........ 160 cm
Vibration on handgrip
(a ) ..............3.690 m/s
h
Vibration on round handle
(a ) ............. 4.320 m/s
h
Sound pressure level
) .................... 90.5 dB; K
(L
pA
Sound power level (L
measured ..... 101.5 dB, K
guaranteed .......................... 106 dB
Trimmer
Cutting diameter,
spool ........................30 cm / 300 mm
String thickness ........................ 2.4 mm
GB
....1200 rpm
0
2 ; K= 1.5 m/s
2 ; K= 1.5 m/s
= 3 dB
pA
)
WA
= 1.97 dB
WA
...............max. 10 m/s
/ 160 ml
3
2 ; K= 1.5 m/s
; K= 1.5 m/s
2
= 3 dB
pA
)
WA
= 2.38 dB
WA
MT
2
2
2
2
45
