COOPER LIGHTING - SURE-LITES
LPX SERIES
P o l y c a r b o n a t e
A C O n l y
S e l f - P o w e r e d
E X I T L I G H T I N G
• Dual-voltage Input 120/277
VAC, 60Hz, isolation
transformer
• Injection molded
polycarbonate housing
• LED lamping
• Premium Nickel Cadmium
battery (Self Powered)
• Fully charged in 24 hours
(Self-Powered Exits)
• Ceiling, wall, or end
mountable
• Snap-fit canopy included
• Snap-out or snap-in chevron
directional indicators
• Knockout provided on
housing for surface
attachment
• Universal exits can be field
configured as single face or
double face
• Self-powered Exit features
line-latching, solid-state
voltage limited charger, solid-
state switching, brownout
circuit, low-voltage
disconnect, overload/short-
circuit protection, test switch/
power indicator light
• Self-Diagnostic Exits meet
Energy Star and UL Damp
Location
• Optional 2C (Two circuit,
FTBR) available in 120/277
VAC in standard and
emergency operation
(AC Only Exits)•
UL 924
Listed, Life Safety NFPA 101,
CSA Certified, NEC/OSHA,
most state and local codes,
suitable for floor proximity
installation
• Patent No. 5,735,498 and
5,678,336
642
COOPER LIGHTING
D E S C R I P T I O N
The LPX Series LED Exit is an
economical, yet attractive,
alternative to metal exits. Its
contemporary round corner
styling, designer white finish,
and consistent family
appearance enables it to blend
with any decor. The tough
injection molded polycarbonate
materials resist discoloration.
All components, including
canopy and chevron directional
indicators, are of snap-fit
construction to facilitate
installation. The under 5-minute
installation time of the LPX
Series Exit makes it the fastest
installed exit on the market
today. All LPX Series Exits are
available in universal
configurations.
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : L P X 7 0 R W H
LPX
Family
LPX=Polycarbonate
Exit
Series
6=AC only with LED
7=Self-Powered with
LED
Face Options
0=Universal
Battery
Blank=No Battery (LPX6)
Blank=Nickel Cadmium Battery (LPX7)
E n e r g y D a t a – S e l f - P o w e r e d E x i t s
LED Exits -Red Letters
LED Exits Green
LED Exits-Red Letters SD
Premium Deep Green
Premium Deep Green SD
E n e r g y D a t a – A C O n l y E x i t s
LED Exits -Red Letters
LED Exits -Green Letters
Premium Deep Green
®
D I M E N S I O N S
6" [152mm]
13" [330mm]
Letter
Housing
Colors
Finishes
R=Red
WH=White
G=Green
BK=Black
(White
Only)
DG=Premium
Deep
Green
Charge Mode (Fully Discharged Battery): Sealed Nickel Cadmium Battery
Input Power:
Input Current (Max.):
120V
277V
120V
277V
LED Exits
2.8W 2.9W
.03A
.02A
6.0W
6.4W
.09A
.04A
1.7W
1.7W
.03A
.01A
Premium
4.0W
4.0W
.08A
.04A
3.1W
3.0W
.08A
.04A
Input Power:
Input Current (Max.):
120V
277V
120V
277V
LED Exits
2.4W
2.5W
.03A
.02A
5.6W
5.9W
.08A
.04A
Premium
2.6W
2.6W
.08A
.04A
4 1/2"
[114mm]
3/4"
[19mm]
7 1/2"
[190mm]
2 1/8"
[54mm]
Options
Accessories
2C=Two Circuit
(Order Separately)
Option
CCX18PKWH=18"
(FTBR)
Pendant Kit, White
(LPX6 Only)
CCX18PKHTWH=18"
SD=Self
Hang True Pendant Kit,
Diagnostics
White
(Red and
CCX18PKBK=18"
Deep Green,
Pendant Kit, Black
White
CCX18PKHTBK=18"
Housing
Hang True Pendant Kit,
Only. LPX7
Black
Only)
WG10=Surface, Wire
Guard
WGS11=Ceiling, End
Wire Guard
VS1=Polycarbonate
Vandal Shield
VS1WP=Polycarbonate
Vandal Shield
Weather Proof
Power Factor:
T.H.D.:
120V
277V
120V
277V
> .81
> .77
< 32% < 46%
> .58
> .56
< 42% < 45%
>.63
>.64
<43%
<48%
> .41
> .41
< 48% < 49%
>.34
>.36
<63%
<67%
Power Factor:
T.H.D.:
120V
277V
120V
277V
> .78
> .73
< 33% < 48%
> .55
> .53
< 43% < 45%
> .28
> .28
< 51% < 53%
