COOPER LIGHTING - SURE-LITES
RKRC SERIES
L E D L i t e S t i x ™
E x i t R e t r o f i t K i t
E X I T L I G H T I N G
RKRI SERIES
L E D L i t e S t i x ™
E x i t R e t r o f i t K i t
E X I T L I G H T I N G
670
COOPER LIGHTING
D E S C R I P T I O N
™
The Sure-Lites LED LITE STIX
Retrofit Kit for Exits offers the latest
technology in exit lighting available
today. The Patent Pending design of
the LED LITE STIX
™
provides superior
illumination of exit lettering at a
fraction of the costs associated with
typical incandescent lamps. Each kit is
provided with two lamps which come
in two different base styles to suit
nearly every application. Installation
is easy since the lamps simply screw
into the existing incandescent lamp
sockets. The long life characteristic of
the LEDs is protected by an integral
MOV (Metal Oxide Varistor) surge
protection device which is designed
to protect the lamp in the event of an
electrical surge. Practically any stencil
face incandescent exit fixture can be
retrofitted with the Sure-Lites LED
LITE STIX
™
LED Retrofit Kit for Exits,
yielding significant energy savings
and eliminating the lamp
maintenance associated with
incandescent lamps. The kit is
suitable for use with either single or
double face exit fixtures.
• No special provisions required for
installation:
1. Disconnect AC power and open
exit fixture
2. Remove existing AC
incandescent lamps
3. Screw-in LED LITE STIX™
4. Close exit fixture and reconnect
AC power
• Damp Location Listed
• UL 924 Classified for Sure-Lites
Exits, Life Safety NFPA 101, CSA
Certified, NEC/OSHA, Most state
and local codes
• Suitable for use with single- or
double-face exit fixtures
• Eliminates lamp replacement costs
and maintenance labor
• Trilingual instructions included
(English, Spanish, and French)
• Diffuser can also be used to convert
green exits to red
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : R K R C
RK
Family
Lamp Color
Base Style
R=Red
C=Candelabra
RK=LED LITE
STIX
™
LED
I=Intermediate
Retrofit Kit
®
D I M E N S I O N S
LED
5 1/2" max.
(140mm)
3/4"
(19mm)
Candelabra Base
• 120 VAC, 60 Hz input voltage
• Long-life, high-output LEDs
• Consumes less than 1 watt per lamp (2W per
kit)
• MOV (Metal Oxide Varistor) surge protected
• Patent pending
• LEDs (Light Emitting Diodes) are encapsulated
in a standard T-6 1/2 glass lamp envelope
• Super-clear glass and super-bright LEDs
combine for optimum light output
• Available in two base styles: candelabra and
intermediate
• Simple screw-in installation - no special
adapters or messy rewiring
• Direct replacement for up to 20W
incandescent lamps
• Two lamps provided per kit
Accessories (order separately)
RKLR=Diffuser - Red - 13" x 9"
5 1/2" max.
(140mm)
3/4"
(19mm)
Intermediate Base
E n e r g y D a t a
RKRC, RKRI (per 2-lamp kit)
Input Power:
120V = 2.0W
Input Current (Max.):
120V = .09A
Power Factor:
120V = >.19
T.H.D.:
120V = <19%
