Cooper Lighting Sure-Lites NCB Specification

DESCRIPTION
The NCB Series is a premium grade emergency lighting system with all
metal construction that combines functional styling and power performance
capability. These units contain serviceable nickel cadmium batteries and
feature advanced solid-state circuitry.
SPECIFICATION FEATURES
Electronic
- Dual Voltage Input 120/277
VAC, 60 Hz
- Line-latching
- Solid-state Switching
- Low-Voltage Disconnect
- Brownout Circuit
- Overload/Short Circuit
Protection
- Test Switch/Power
- Indicator Light
Housing Construction
- 18-Gauge Die-Formed
Steel Housing
- 18-Gauge Die-Formed
Steel Cover
ELECTRICAL RATINGS
R a t e d W a t t a g e
Model DC Voltage 1 1/2 Hours
NCB1290 12 90
1
NCB12180 12 180
1
NCB12225 12 225
1
ORDERING INFORMATION
S A M P L E N U M B E R : N C B 4 5 V T D M
NCB
Options (add as suffix)
Model Number
MH=Metal Heads
NCB45
A=Ammeter
NCB90
TDM=Time Delay Monitor
NCB110
V=Voltmeter
1 Alternate Lamps: Consult Cooper Lighting Representative.
2
Order separately. Not available for NCB12225.
*
0, 1, 3 and 4 Heads also available. Specify after catalog
number ).
(i.e. NCB12180408
Specifications and Dimensions subject to change without notice.
COOPER LIGHTING - SURE-LITES
Housing Construction Cont.
- Knockout, Conduit or
Cord Set
- Key-hole Mounting Slots
- Corrosion Resistant
White Enamel Finish
Battery
- Serviceable Wet Cell
Nickel Cadmium
- Full Recharge Time:
NCB1290: 24 hrs. (max.)
NCB12180, NCB12225:
48 hrs. (max.)
- Polarized Battery Terminals
5 3/4"
[146mm]
6 1/4"
[159mm]
17 1/4"
[438mm]
11 1/2"
[292mm]
2" [51mm]
2 1/2"
[64mm]
to 87 1/2% of Rated D.C. Voltage
2 Hours 3 Hours 4 Hours
67 45 33
135 90 67
168 112 84
Accessories (order separately)
Cord Set
CSK120 =Cord Set (120 VAC)
CSK277 =Cord Set (277 VAC)
Mounting Kit
3MSWH=Mounting Shelf
3BRWH=Mounting Brackets (3-White Finish)
Protective Housing
WG3 =Wire Guard (not applicable for NCB12225)
VS2=Polycarbonate Vandal Shield
VS2WP=Polycarbonate Vandal Shield - Weatherproof
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
Code Compliance
- UL 924 Listed
- Life Safety NFPA 101
- NEC/OSHA
- Most State and Local Codes
Warranty
- Unit: 1-year
- Battery: 15-year pro-rata
Head/Lamp Data
- Two Heads Standard
- Glare-Free Lens
- Fully Adjustable
- Remote Capability
- High Impact - Thermoplastic
- Matches Housing Finish
6" [152mm] 6" [152mm]
8" [203mm]
17"* [432mm]
*NCB12225 - 24" [610mm] wide
L a m p I n f o r m a t i o n
Type Wattage Number
9 29-86
Incandescent
9 29-86
Incandescent
9 29-86
Incandescent
(not applicable for NCB12225) (White Finish)
®
Type
Date
NCB
SERIES
12-VOLT
SERVICEABLE WET CELL
NICKEL CADMIUM BATTERY
Emergency Lighting
ENERGY DATA
NCB1290
Input Current (Max.):
120V= .84A
277V= .37A
NCB-12180
Input Current (Max.):
120V= .72A
277V= .30A
NCB12225
Input Current (Max.):
120V= .1.28A
277V= .55A
ADX081386
