Cooper Lighting Sure-Lites GFR Specification

SPECIFICATION FEATURES
GFR
Electrical
- 6V or 12V DC Input Voltage
GFR
Construction
- Matches RG1 Series emergency
lighting units
- 20-gauge die-stamped steel
housing with white baked
enamel finish
- Housing adjusts in plaster frame
1 3/8" to accommodate different
ceiling thicknes
- Bar hangers included for fast,
easy installation
- Gimbal trim ring has white paint
finish
- Lamp adjusts 40° from vertical
with 358° rotation
ORDERING INFORMATION
G F R S e r i e s
C a a t o l g N . o F n i s i h L
GFR2703 White Trim Incandescent Sealed Beam
GFR2716 White Trim Halogen Sealed Beam
Alternate Lamps: Consult Cooper Lighting Representative
Other Finishes Available: Cooper Lighting Representative
COOPER LIGHTING - SURE-LITES
GFR
Code Compliance
- CSA Certified
- UL Listed
- UL Damp Location Listed
- Life Safety NFPA 101
GFR
Warranty
- Unit: 1-year
a m p T y p e V l o s t
6
12
Specifications and Dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
GFR
Lamp Data
- 6 Volt Incandescent Sealed Beam
- 12 Volt Incandescent Sealed
Beam
- Consult factory for other lamp
types (See Technical Information
Section)
Isofootcandle
W t a s t L a m p N . o D a i g a r m N . o
8 029-03 3
8 029-16 6
®
Type
Date
GFR SERIES
ROUND SPECIALTY
REMOTES
CSA Certified
Emergency Lighting
E N E R G Y D AT A
Power Consumption is equal
to lamp wattage.
ADX081164
05/19/2008 2:56:13 PM
