TVN 11 Quick Start Guide
Figure 1: Back panel connections (Example: TVN 1108S/TVN 1108 shown)
TVN 1108S
TVN 1108 (EMEA only)
1. Connect a microphone for bi-directional audio
(not recorded).
2. Connect up to four alarm inputs
3. Connect one alarm relay output.
4. Connect to a network.
5. Power switch (on/off).
6. Embedded PoE ports to connect IP cameras
(depending on model).
7. Connect to speakers for audio output.
Default IP address - 192.168.1.82
P/N 1073396-EN • REV A • ISS 16FEB18
8. Connect to a VGA monitor.
9. Connect to an HDTV. The HDMI connection
supports both digital audio and video.
10. Connect to an optional USB 2.0 device such as a
mouse, CD/DVD burner or HDD.
11. Connect to ground.
12. Connect a power cord to the recorder (included).
13. Connect to the 12 VDC PSU (included).
Download the latest recorder firmware and TruVision
Navigator software from www.interlogix.com or
www.firesecurityproducts.com
Advertisement
Table of Contents
Related Manuals for Interlogix TVN 11
Summary of Contents for Interlogix TVN 11
- Page 1 TVN 11 Quick Start Guide Figure 1: Back panel connections (Example: TVN 1108S/TVN 1108 shown) TVN 1108S TVN 1108 (EMEA only) 1. Connect a microphone for bi-directional audio 8. Connect to a VGA monitor. (not recorded). 9. Connect to an HDTV. The HDMI connection 2.
- Page 2 Reverse: In live view mode, use to play back the earliest video. In playback buttons mode, playback a camera in the reverse direction. Pause: In live view, freeze the last image of the live display for all active cameras displayed. In playback mode, stop playback. TVN 11 Quick Start Guide...
- Page 3 4. Audio On: Enable/disable audio output. with a motorized lens 5. Snapshot: Capture a snapshot of a video 11. Stream Information: Display the real-time frame image. rate, bit rate, resolution and video compression. 12. Close: Close the toolbar. TVN 11 Quick Start Guide...
-
Page 4: Package Contents
3. Connect the mouse to the USB port in the Package contents front panel. The TruVision NVR 11 (model TVN 11) is 4. Connect the power supply to the unit and turn on the power. shipped with the following items: 5. -
Page 5: Adding Ip Cameras
In the logon screen, enter the user ID and password. The recorder detects the camera and pushes its admin login and password to the camera. Install the recorder web plug-in to to see live camera images. TVN 11 Quick Start Guide... -
Page 6: Live View Mode
The main menu screen appears. Move the various toolbars and menus within mouse over a command icon in the menu the interface. toolbar and click to select it. Provides access to logout, reboot and shutdown options. TVN 11 Quick Start Guide... -
Page 7: Specifications
380 × 320 × 48 mm (15.0 × 12.6 × 1.9 in.) Weight (without HDD): 4-channel: TVN-1104cS-000 1300 g TVN-1104c-000 (EMEA 1000 g only) 8-channel: TVN-1108S-000 2400 g TVN-1108-000 2000 g 16-channel: TVN-1116S-000 2500 g TVN-1116-000 2000 g TVN 11 Quick Start Guide... -
Page 8: Legal And Regulatory Information
Ausrüstung zurück, oder entsorgen Sie das Produkt an den gekennzeichneten Sammelstellen. Weitere Interlogix is part of UTC Climate, Controls & Security, a unit of Informationen hierzu finden Sie auf der folgenden Website: United Technologies Corporation. All rights reserved www.recyclethis.info. - Page 9 й – например Cd за кадмий, Pb за олово или Hg за живак. За электронного оборудования (WEEE), помеченное этим правилното рециклиране трябва да върнете батерията на своя символом оборудование нельзя утилизировать как обычные доставчик или в специално определените пунктове за отходы на территории ЕС. Для надлежащей утилизации по TVN 11 Quick Start Guide...
- Page 10 (Cd), svinu (Pb) vastuvõtupunkti. Lisainformatsiooni saab Internetist aadressil: vai dzīvsudrabu (Hg). Pēc ekspluatācijas laika beigām baterijas vai www.recyclethis.info. akumulatori jānodod piegādātājam vai specializētā bateriju TVN 11 Quick Start Guide...
- Page 11 продукту. На этом символе могут присутствовать буквы, которые означают, что батарея собержит кадмий (Cd), свинец (Pb) или ртуть (Hg). Для надлежащей утилизации по окончании срока эксплуатации пользователь должен возвратить батареи локальному поставщику или сдать в специальный пункт TVN 11 Quick Start Guide...
