TruVision DVR 60 Quick Start Guide
Content
Package contents 1
Installation environment 1
Setting up the TVR 60 1
Connecting the devices 2
Turning on and off the TVR 60 2
Operating the TVR 60 3
DDNS settings 5
Live mode 5
Quick Archive 5
Playing back exported DVR format files 6
PTZ mode 6
Logging on 6
Overview of the main menu 7
Setting up IP cameras 7
Setting up alarms 8
Connecting a keypad 8
Viewing an alarm event list 8
Contact information 9

Package contents

The TruVision DVR 60 (model TVR 60) is shipped with
the following items:
• IR (infrared) remote control
• Two AAA batteries for the remote control
• AC power cord (US, Europe, UK)
• USB mouse
• DVR
• TruVision DVR 60 Quick Start Guide
• TruVision DVR 60 User Manual (on CD)

Installation environment

Refer to the user manual for detailed information, but
observe these important requirements:
• Place the TVR 60 in a secure location.
• Ensure that the TVR 60 is in a well-ventilated area.
• Do not expose the unit to rain or moisture.
© 2011 UTC Fire & Security Company. All rights reserved.

Setting up the TVR 60

The TVR 60 has an express installation wizard that lets
you easily configure basic DVR settings when first used.
It configures all cameras simultaneously. The
configuration can then be customized as required.
By default, the Setup Wizard initiates once the DVR has
loaded. The Setup Wizard walks you through some of
the more important settings of your DVR. If you do not
wish to use the Setup Wizard at this time, click the
Cancel button. You may also choose to use the Setup
Wizard at a later time by leaving the "Start Wizard when
DVR starts?" checkbox checked.
Any changes you make to a setup configuration screen
are saved when you exit the screen and return to the
main eZ Setup screen.
Recommended steps for setting up the TVR 60:
1. Connect all the devices required to the back panel of
the TVR 60. See Figure 1 on page 2.
2. Set up the TVR 60 with basic settings using the
Setup Wizard.
3. Install the and configure the analog and/or IP
cameras.
4. Configure the system for motion alarms and other
alarm types, as required.
5. Configure the recording, network, HDD and user
settings, as required.
6. Install and configure the keypad.
To quickly put the TVR 60 into operation using Setup
Wizard:
1. Turn on the unit using the power switch on the back
panel. After the boot up screen, the TVR 60 displays
video images on-screen.
2. Select the preferred language for the system.
3. In the eZ Setup screen, click the
User Permission screen enter the default user ID
and password.
P/N 1069896B-EN • REV 2.0 • ISS 10MAY11
Next button. In the
