SRX4100 Services Gateway Hardware Guide

Modified: 2019-03-20

Summary of Contents for Juniper SRX4100

Page 2 END USER LICENSE AGREEMENT The Juniper Networks product that is the subject of this technical documentation consists of (or is intended for use with) Juniper Networks software. Use of such software is subject to the terms and conditions of the End User License Agreement (“EULA”) posted at https://support.juniper.net/support/eula/.
Page 3 SRX4100 Services Gateway Overview ........17...
Page 4 Unpacking and Mounting the SRX4100 ........41...
Page 5 Components ........... . . 65 Returning the SRX4100 Chassis or Components ......65 Contacting Customer Support .
Page 6 SRX4100 Services Gateway Hardware Guide DC Power Wiring Sequence Warning ........95 DC Power Wiring Terminations Warning .
Page 7 Overview ............17 Figure 1: SRX4100 Services Gateway Front Panel ......19 Figure 2: SRX4100 Services Gateway Front Panel LEDs .
Page 9 Table 3: SRX4100 Services Gateway Components on the Front Panel ..19 Table 4: SRX4100 Services Gateway Front Panel LEDs ..... 20 Table 5: Management Port LEDs .
Page 11 ® To obtain the most current version of all Juniper Networks technical documentation, see the product documentation page on the Juniper Networks website at https://www.juniper.net/documentation/ If the information in the latest release notes differs from the information in the documentation, follow the product Release Notes.
Page 12 SRX4100 Services Gateway Hardware Guide Merging a Full Example To merge a full example, follow these steps: From the HTML or PDF version of the manual, copy a configuration example into a text file, save the file with a name, and copy the file to a directory on your routing platform.
Page 13 Alerts you to the risk of personal injury from a laser. Indicates helpful information. Best practice Alerts you to a recommended use or implementation. Table 2 on page xiv defines the text and syntax conventions used in this guide. Copyright © 2019, Juniper Networks, Inc. xiii...
Page 14 SRX4100 Services Gateway Hardware Guide Table 2: Text and Syntax Conventions Convention Description Examples Bold text like this Represents text that you type. To enter configuration mode, type the configure command: user@host> configure Fixed-width text like this Represents output that appears on the user@host>...
Page 15 Requesting Technical Support Technical product support is available through the Juniper Networks Technical Assistance Center (JTAC). If you are a customer with an active Juniper Care or Partner Support Services support contract, or are covered under warranty, and need post-sales technical support, you can access our tools and resources online or open a case with JTAC.
Page 16 SRX4100 Services Gateway Hardware Guide Self-Help Online Tools and Resources For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features: Find CSC offerings: https://www.juniper.net/customers/support/...
Page 17 SRX4100 (AC) — SRX4100 Services Gateway with dual AC power supplies SRX4100 (DC) — SRX4100 Services Gateway with dual DC power supplies The SRX4100 Services Gateway comes with 64 GB of DDR4 memory and two 240-GB solid-state drives (SSDs) in a redundant array of independent disks (RAID). Both disks are configured as a RAID-1 mirror (data is concurrently written to both SSDs).
Page 18 Field-Replaceable Units in SRX4100 Services Gateways Field-replaceable units (FRUs) are components that you can replace at your site. The FRUs on the SRX4100 Services Gateway are hot-removable and hot-insertable. You can remove and replace them without powering off the services gateway. The services...
Page 19 SRX4100 Services Gateway. Figure 1: SRX4100 Services Gateway Front Panel Table 3 on page 19 lists the components on the front panel of the services gateway. Table 3: SRX4100 Services Gateway Components on the Front Panel Number Component Description Management port Gigabit Ethernet port to connect to the device over the network.
Page 20 SRX4100 Services Gateway Hardware Guide Figure 2: SRX4100 Services Gateway Front Panel LEDs Power Status Table 4: SRX4100 Services Gateway Front Panel LEDs Description Power Solid green—receiving power Status Solid green—operating normally Solid red—critical alarm Hardware component failure Software module failure Fan failure (atleast one) Blinking red—noncritical alarm...
Page 21 Solid green—There is link activity. left) Off—There is no link established. Speed/Activity Solid amber—10 G/1 G link is established. (LED on the Blinking amber—There is activity on the 10 G/1 G link. right) Off—There is no link established. Copyright © 2019, Juniper Networks, Inc.
Page 22 SRX4100 Services Gateway Hardware Guide SRX4100 Services Gateway Back Panel Figure 5 on page 22 shows the back panel of the SRX4100 Services Gateway, and Table 8 on page 22 lists and describes the back panel components. Figure 5: SRX4100 Services Gateway Back Panel...
Page 23 DC Power Supply Specifications for SRX4100 Services Gateways on page 28 SRX4100 Power Supply The SRX4100 Services Gateway is shipped with two AC or two DC power supply units preinstalled in the rear panel. Each power supply provides power to all components in the services gateway.
Page 24 SRX4100 Services Gateway Hardware Guide redistributes the electrical load without interruption. Each power supply is cooled by its own internal cooling system. AC Power Supply on page 24 DC Power Supply on page 25 AC Power Supply Each AC power supply weighs approximately 2.3 lb and consists of one AC appliance inlet, a fan, and LEDs for monitoring the status of the power supply.
Page 25 (FRU) when the second power supply is installed and running. You can install a replacement power supply without powering off the services gateway. The DC power supply gives an output of 650 W. Figure 9 on page 26 shows the DC power supply. Copyright © 2019, Juniper Networks, Inc.
Page 26 SRX4100 Services Gateway Hardware Guide Figure 9: DC Power Supply The DC power supply requires a dedicated circuit breaker rated for 20 A (–48 VDC) minimum, or as required by local code. Figure 10 on page 26 shows the location of the LEDs on a DC power supply. Each DC power supply faceplate contains three LEDs that indicate the status of the power supplies.
Page 27 Power Requirement ) * 3.41 Note: 1 W = 3.41 BTU/Hour AC Power Cord Specifications for the SRX4100 Services Gateway A detachable AC power cord is supplied with the AC power supplies. The coupler is type C13 as described by International Electrotechnical Commission (IEC) standard 60320.
Page 28 The AC power cord for the services gateway is intended for use with the services gateway only and not for any other use. DC Power Supply Specifications for SRX4100 Services Gateways Table 13 on page 28 lists the power supply specifications for a DC power supply.
Page 31 Table 14 on page 31 provides a checklist of tasks you need to perform when preparing a site for installing the SRX4100 Services Gateway. Table 14: Site Preparation Checklist for SRX4100 Services Gateway Installation Performed Item or Task Additional Information...
Page 32 SRX4100 Services Gateway Hardware Guide Table 14: Site Preparation Checklist for SRX4100 Services Gateway Installation (continued) Performed Item or Task Additional Information Date Notes Verify that environmental factors “SRX4100 Services such as temperature and humidity Gateway Environmental do not exceed device tolerances.
Page 33 Chapter 2: Site Planning, Preparation, and Specifications Clearance Requirements for Airflow and Hardware Maintenance for SRX4100 Services Gateways on page 35 SRX4100 Services Gateway Rack Requirements on page 36 Cabinet Requirements for SRX4100 Services Gateways on page 37 General Site Installation Guidelines...
Page 34 The addition of primary protectors is not sufficient protection to connect these interfaces metallically to OSP wiring. SRX4100 Services Gateway Physical Specifications The SRX4100 Services Gateway chassis is a rigid sheet metal structure that houses all the components. Table 17 on page 35 lists the physical specifications of the SRX4100 Services Gateway chassis.
Page 35 Services gateway with 2 DC power supplies: 28.8 lb (13.06 kg) AC power supply: 2.3 lb (1.04 kg) DC power supply: 2.2 lb (0.99 kg) You can mount the SRX4100 Services Gateway on a standard 19-in. four-post rack or in a standard 19-in. enclosed cabinet. See Also...
Page 36 See Also SRX4100 Cooling System on page 22 SRX4100 Services Gateway Rack Requirements The SRX4100 Services Gateway is designed to be installed on four-post racks. Table 19 on page 36 provides the rack requirements and specifications for the services gateway.
Page 37 Installing the SRX4100 Services Gateway in a Rack on page 43 Cabinet Requirements for SRX4100 Services Gateways You can install the SRX4100 Services Gateway in a 19 in. (48.7 cm) cabinet. Table 20 on page 37 provides the cabinet requirements and specifications.
Page 38 SRX4100 Transceiver Specifications and Pinouts Pluggable Transceivers Supported on SRX4100 Services Gateways on page 38 SFP+ Direct Attach Copper Cables for SRX4100 Services Gateways on page 39 Management Port Connector Pinout Information for an SRX4100 Services Gateway on page 39...
Page 39 23 ft (7 m), making them ideal for highly cost-effective networking connectivity within a rack and between adjacent racks. The SRX4100 Services Gateway supports the following 1 m and 3 m long DAC cables: SRX-SFP-10GE-DAC-1M...
Page 40 Termination network Termination network Console Port Connector Pinout Information for an SRX4100 Services Gateway The console port is an RS-232 serial interface that uses an RJ-45 connector to connect to a console management device. The default baud rate for the console port is 9600 baud.
Page 41 “Unpacking the SRX4100 Services Gateway” on page Install power supplies if they are not preinstalled. See: Installing an AC Power Supply in an SRX4100 Services Gateway on page 57 Installing a DC Power Supply in an SRX4100 Services Gateway on page 59 Mount the services gateway as described in “Installing the SRX4100 Services Gateway...
Page 42 Save the shipping carton and packing materials in case you need to move or ship the services gateway at a later time. Verifying Parts Received with the SRX4100 Services Gateway A packing list is included in each shipment. Check the parts in the shipment against the items on the packing list.
Page 43 DB-9 to RJ-45 cable RJ-45 cables Installing the SRX4100 Services Gateway in a Rack You can mount the services gateway on four posts in a 19-in. rack or cabinet by using the rack-mount kit shipped with the device. (The remainder of this topic uses rack to mean rack or cabinet.)
Page 44 SRX4100 Services Gateway Hardware Guide NOTE: Installing the device in a rack requires two people: one person lifts the device while the other secures it to the rack. If you are installing multiple devices in one rack, install the lowest one first and proceed upward in the rack.
Page 45 Connecting the SRX4100 to Power Connecting the SRX4100 Services Gateway Grounding Cable on page 45 Connecting AC Power to an SRX4100 Services Gateway on page 47 Connecting DC Power to an SRX4100 Services Gateway on page 48 Connecting the SRX4100 Services Gateway Grounding Cable...
Page 46 SRX4100 Services Gateway Hardware Guide Ensure that you have the following parts and tools available: Electrostatic discharge (ESD) grounding wrist strap Phillips (+) screwdriver, number 2 14 AWG single-strand wire grounding cable Grounding lug (ring-type, vinyl-insulated TV14-6R lug, or equivalent)
Page 47 Connecting AC Power to an SRX4100 Services Gateway Ensure that you have a power cord appropriate for your geographical location available to connect AC power to an SRX4100 Services Gateway. Before you begin connecting AC power: Ensure that you have taken the necessary precautions to prevent electrostatic discharge (ESD) damage.
Page 48 (!) LED is lit amber, remove power from the power supply, and replace the power supply (see “Removing an AC Power Supply from an SRX4100 Services Gateway” on page 56). Do not remove the power supply until you have a replacement power supply ready.
Page 49 Remove the screws on the terminals using the screwdriver. Secure each positive (+) DC source power cable lug to a RTN (return) terminal. Secure each negative (–) DC source power cable lug to a -48V (input) terminal. Figure 19: Connecting DC Power Copyright © 2019, Juniper Networks, Inc.
Page 50 SRX4100 Power Supply on page 23 Documentation Connecting the SRX4100 Services Gateway to a Management Console Use the CONSOLE port on the services gateway to connect to a management console. The CONSOLE port accepts a cable that has an RJ-45 connector.
Page 51 Chapter 3: Initial Installation and Configuration Viewing Factory-Default Settings on page 51 Configuring the SRX4100 Services Gateway on page 52 SRX4100 Services Gateway Software Configuration Overview The services gateway is shipped with Junos OS preinstalled and ready to be configured when the services gateway is powered on.
Page 52 SRX4100 Services Gateway Hardware Guide Configuring the SRX4100 Services Gateway This procedure explains how you can create an initial configuration using CLI commands to connect the services gateway to the network. NOTE: Before you can use J-Web to configure your services gateway, you must access the CLI to configure the root authentication.
Page 53 You can ignore this alert and proceed to access the services gateway. The J-Web login page is displayed. This indicates that you have successfully completed the initial configuration and that your services gateway is ready for use. Copyright © 2019, Juniper Networks, Inc.
Page 54 SRX4100 Services Gateway Hardware Guide NOTE: To access the J-Web interface, your management device requires one of the following supported browsers: Microsoft Internet Explorer version 9.0 or 10.0 Mozilla Firefox version 38 (or later) Log in as root and proceed with configuring the settings based on your requirements.
Page 55 Related Troubleshooting Resources for the SRX4100 Services Gateway on page 61 Documentation Monitoring Chassis Alarms on a SRX4100 Services Gateway on page 61 Maintaining the SRX4100 Power System Replacing an AC Power Supply on the SRX4100 on page 55 Replacing a DC Power Supply on the SRX4100 on page 57...
Page 56 Antistatic bag or an antistatic mat Replacement power supply Removing an AC Power Supply from an SRX4100 Services Gateway on page 56 Installing an AC Power Supply in an SRX4100 Services Gateway on page 57 Removing an AC Power Supply from an SRX4100 Services Gateway...
Page 57 Figure 21: Installing an AC Power Supply See Also Connecting AC Power to an SRX4100 Services Gateway on page 47 Replacing a DC Power Supply on the SRX4100 The power supplies are hot-removable and hot-insertable field-replaceable units (FRUs) installed in the rear panel of the services gateway. You can remove and replace them without powering off the services gateway or disrupting services gateway functions.
Page 58 Antistatic bag or an antistatic mat Replacement power supply Removing a DC Power Supply from an SRX4100 Services Gateway on page 58 Installing a DC Power Supply in an SRX4100 Services Gateway on page 59 Removing a DC Power Supply from an SRX4100 Services Gateway...
Page 59 You will hear a distinct click when the power supply is fully seated in the chassis. Figure 23: Installing a DC Power Supply See Also Connecting DC Power to an SRX4100 Services Gateway on page 48 Copyright © 2019, Juniper Networks, Inc.
Page 60 SRX4100 Services Gateway Hardware Guide Maintaining the SRX4100 Cooling System Replacing the SRX4100 Services Gateway Fan Tray on page 60 Replacing the SRX4100 Services Gateway Fan Tray To replace the fan tray: Identify the physical location of the faulty fan tray on the rear panel of the chassis.
Page 61 Troubleshooting Resources for the SRX4100 Services Gateway on page 61 Monitoring Chassis Alarms on a SRX4100 Services Gateway on page 61 Using the RESET Button on the SRX4100 Services Gateway on page 62 Troubleshooting Resources for the SRX4100 Services Gateway...
Page 62 Using the RESET Button on the SRX4100 Services Gateway If a configuration fails or denies management access to the services gateway, you can use the RESET button to restore the services gateway to the factory-default configuration.
Page 63 To return the function of the RESET button to its default behavior, remove the statement from the services gateway configuration. config-button Related SRX4100 Services Gateway Front Panel on page 19 Documentation Copyright © 2019, Juniper Networks, Inc.
Page 65 Contacting Customer Support Once you have located the serial numbers of the device or component, you can return the device or component for repair or replacement. For this, you need to contact Juniper Networks Technical Assistance Center (JTAC). You can contact JTAC 24 hours a day, 7 days a week, using any of the following methods: On the Web: Using the Service Request Manager link at https://support.juniper.net/support/...
Page 66 Returning a SRX4100 Services Gateway or Component to Juniper Networks To return a services gateway or component to Juniper Networks for repair or replacement, follow this procedure: Determine the part number and serial number of the services gateway or component.
Page 67 Listing the SRX4100 Services Gateway Component Details with the CLI Before contacting Juniper Networks to request a Return Materials Authorization (RMA), you must find the serial number on the SRX4100 Services Gateway or component. To list all the SRX4100 Services Gateway components and their serial numbers, enter the following CLI command: user@host>...
Page 68 Phillips (+) screwdriver, number 2 Packing the SRX4100 Services Gateway for Shipment on page 68 Packing the SRX4100 Services Gateway Components for Shipment on page 69 Packing the SRX4100 Services Gateway for Shipment To pack the services gateway for shipment:...
Page 69 Securely tape the box closed. Write the Return Materials Authorization (RMA) number on the exterior of the box to ensure proper tracking. Packing the SRX4100 Services Gateway Components for Shipment Follow these guidelines for packing and shipping individual components of the services gateway:...
Page 71 DC Power Wiring Terminations Warning on page 96 Action to Take After an Electrical Accident on page 98 Agency Approvals on page 98 Acoustic Noise Compliance Statements on page 99 EMC Requirements on page 99 Copyright © 2019, Juniper Networks, Inc.
Page 72 SRX4100 Services Gateway Hardware Guide General Safety Guidelines and Warnings The following guidelines help ensure your safety and protect the device from damage. The list of guidelines might not address all potentially hazardous situations in your working environment, so be alert and exercise good judgment at all times.
Page 73 Avant de travailler sur un équipement, soyez conscient des dangers posés par les circuits électriques et familiarisez-vous avec les procédures couramment utilisées pour éviter les accidents. Copyright © 2019, Juniper Networks, Inc.
Page 74 SRX4100 Services Gateway Hardware Guide Warnung Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu einer Körperverletzung führen könnte. Bevor Sie mit der Arbeit an irgendeinem Gerät beginnen, seien Sie sich der mit elektrischen Stromkreisen verbundenen Gefahren und der Standardpraktiken zur Vermeidung von Unfällen bewußt.
Page 75 Ett område med begränsat tillträde får endast tillträdas av servicepersonal med ett speciellt verktyg, lås och nyckel, eller annan säkerhetsanordning, och kontrolleras av den auktoritet som ansvarar för området. Related Qualified Personnel Warning on page 76 Documentation Copyright © 2019, Juniper Networks, Inc.
Page 76 SRX4100 Services Gateway Hardware Guide Qualified Personnel Warning WARNING: Only trained and qualified personnel should install or replace the device. Waarschuwing Installatie en reparaties mogen uitsluitend door getraind en bevoegd personeel uitgevoerd worden. Varoitus Ainoastaan koulutettu ja pätevä henkilökunta saa asentaa tai vaihtaa tämän laitteen.
Page 77 ANSI/TIA/EIA-568 cables such as Category 5e and Category 6 can get electrostatically charged. To dissipate this charge, always ground the cables to a suitable and safe earth ground before connecting them to the system. Copyright © 2019, Juniper Networks, Inc.
Page 78 To keep warranties effective, do not use a dry chemical fire extinguisher to control a fire at or near a Juniper Networks device. If a dry chemical fire extinguisher is used, the unit is no longer eligible for coverage under a service agreement.
Page 79 Chapter 7: Safety and Compliance Information Laser and LED Safety Guidelines and Warnings Juniper Networks devices are equipped with laser transmitters, which are considered a Class 1 Laser Product by the U.S. Food and Drug Administration and are evaluated as a Class 1 Laser Product per EN 60825-1 requirements.
Page 80 SRX4100 Services Gateway Hardware Guide Varning! Laserprodukt av klass 1. Class 1 LED Product Warning WARNING: Class 1 LED product. Waarschuwing Klasse 1 LED-product. Varoitus Luokan 1 valodiodituote. Attention Alarme de produit LED Class I. Warnung Class 1 LED-Produktwarnung. Avvertenza Avvertenza prodotto LED di Classe 1.
Page 81 Varning! Osynlig strålning kan avges från en portöppning utan ansluten fiberkabel och du bör därför undvika att bli utsatt för strålning genom att inte stirra in i oskyddade öppningar. Copyright © 2019, Juniper Networks, Inc.
Page 82 SRX4100 Services Gateway Hardware Guide Maintenance and Operational Safety Guidelines and Warnings While performing the maintenance activities for devices, observe the following guidelines and warnings: Battery Handling Warning on page 82 Jewelry Removal Warning on page 83 Lightning Activity Warning on page 84...
Page 83 (inclusi anelli, collane, braccialetti ed orologi). Gli oggetti metallici si riscaldano quando sono collegati tra punti di alimentazione e massa: possono causare ustioni gravi oppure il metallo può saldarsi ai terminali. Copyright © 2019, Juniper Networks, Inc.
Page 84 SRX4100 Services Gateway Hardware Guide Advarsel Fjern alle smykker (inkludert ringer, halskjeder og klokker) før du skal arbeide på utstyr som er koblet til kraftledninger. Metallgjenstander som er koblet til kraftledninger og jord blir svært varme og kan forårsake alvorlige brannskader eller smelte fast til polene.
Page 85 6 in. (15.2 cm) of clearance around the ventilation openings. Waarschuwing Om te voorkomen dat welke switch van de Juniper Networks router dan ook oververhit raakt, dient u deze niet te bedienen op een plaats waar de maximale aanbevolen omgevingstemperatuur van 40°...
Page 86 15,2 cm à volta das aberturas de ventilação. ¡Atención! Para impedir que un encaminador de la serie Juniper Networks switch se recaliente, no lo haga funcionar en un área en la que se supere la temperatura ambiente máxima recomendada de 40°...
Page 87 Attention Cet équipement doit être relié à la terre. S'assurer que l'appareil hôte est relié à la terre lors de l'utilisation normale. Warnung Dieses Gerät muß geerdet werden. Stellen Sie sicher, daß das Host-Gerät während des normalen Betriebs an Erde gelegt ist. Copyright © 2019, Juniper Networks, Inc.
Page 88 SRX4100 Services Gateway Hardware Guide Avvertenza Questa apparecchiatura deve essere collegata a massa. Accertarsi che il dispositivo host sia collegato alla massa di terra durante il normale utilizzo. Advarsel Dette utstyret skal jordes. Forviss deg om vertsterminalen er jordet ved normalt bruk.
Page 89 CA; scollegare l'alimentazione all'interruttore automatico sulle unità CC. Advarsel Før det utføres arbeid på kabinettet eller det arbeides i nærheten av strømforsyningsenheter, skal strømledningen trekkes ut p vekselstrømsenheter og strømmen kobles fra ved strømbryteren på likestrømsenheter. Copyright © 2019, Juniper Networks, Inc.
Page 90 SRX4100 Services Gateway Hardware Guide Aviso Antes de trabalhar num chassis, ou antes de trabalhar perto de unidades de fornecimento de energia, desligue o cabo de alimentação nas unidades de corrente alternada; desligue a corrente no disjuntor nas unidades de corrente contínua.
Page 91 The socket outlet must be near the AC-powered device and be easily accessible. For devices that have more than one power supply connection, you must ensure that all power connections are fully disconnected so that power to the device is completely Copyright © 2019, Juniper Networks, Inc.
Page 92 SRX4100 Services Gateway Hardware Guide removed to prevent electric shock. To disconnect power, unplug all power cords (one for each power supply). Power Cable Warning (Japanese) WARNING: The attached power cable is only for this product. Do not use the cable for another product.
Page 93 Klebeband in der AUS-Stellung fest. Avvertenza Prima di svolgere una qualsiasi delle procedure seguenti, verificare che il circuito CC non sia alimentato. Per verificare che tutta l'alimentazione sia scollegata (OFF), individuare l'interruttore automatico sul quadro Copyright © 2019, Juniper Networks, Inc.
Page 94 SRX4100 Services Gateway Hardware Guide strumenti che alimenta il circuito CC, mettere l'interruttore in posizione OFF e fissarlo con nastro adesivo in tale posizione. Advarsel Før noen av disse prosedyrene utføres, kontroller at strømmen er frakoblet likestrømkretsen. Sørg for at all strøm er slått AV. Dette gjøres ved å...
Page 95 Warnung Die Stromzufuhr ist nur mit geeigneten Ringösen an das DC Netzteil anzuschliessen. Die richtige Anschlusssequenz ist: Erdanschluss zu Erdanschluss, +RTN zu +RTN und dann -48V zu -48V. Die richtige Sequenz zum Abtrennen der Stromversorgung ist -48V zu -48V, +RTN zu +RTN und Copyright © 2019, Juniper Networks, Inc.
Page 96 SRX4100 Services Gateway Hardware Guide dann Erdanschluss zu Erdanschluss. Es ist zu beachten dass der Erdanschluss immer zuerst angeschlossen und als letztes abgetrennt wird. Avvertenza Mostra la morsettiera dell alimentatore CC. Cablare l'alimentatore CC usando i connettori adatti all'estremità del cablaggio, come illustrato. La corretta sequenza di cablaggio è...
Page 97 Varning! När flertrådiga ledningar krävs måste godkända ledningskontakter användas, t.ex. kabelsko av sluten eller öppen typ med uppåtvänd tapp. Storleken på dessa kontakter måste vara avpassad till ledningarna och måste kunna hålla både isoleringen och ledaren fastklämda. Copyright © 2019, Juniper Networks, Inc.
Page 98 SRX4100 Services Gateway Hardware Guide Action to Take After an Electrical Accident If an electrical accident results in an injury, take the following actions in this order: Use caution. Be aware of potentially hazardous conditions that could cause further injury.
Page 99 Related EMC Requirements on page 99 Documentation EMC Requirements Canada This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. Copyright © 2019, Juniper Networks, Inc.
Page 100 SRX4100 Services Gateway Hardware Guide European Community This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Israel The preceding translates as follows: This product is Class A.
