Stamina Airgometer 1100 Owner's Manual
  1. Manuals
  2. Brands
  3. Stamina Manuals
  4. Exercise Bike
  5. Airgometer 1100
  6. Owner's manual
Stamina Airgometer 1100 Owner's Manual

Stamina Airgometer 1100 Owner's Manual

Hide thumbs Also See for Airgometer 1100:
Table of Contents

Advertisement

Quick Links

Download this manual
Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 300 lbs.
This Product is Distributed Exclusively by
2040 N. Alliance, Springfield, MO 65803
www.staminaproducts.com
Customer Care
1 (800) 375-7520
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: 15-1100A
STAMINA PRODUCTS
MADE IN CHINA
©
2016 Stamina Products, Inc.
2017, 04

Advertisement

Table of Contents
loading

Related Manuals for Stamina Airgometer 1100

Summary of Contents for Stamina Airgometer 1100

  • Page 1 CAUTION: Weight on this product should not exceed 300 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N. Alliance, Springfield, MO 65803 Customer Care © 2016 Stamina Products, Inc. 1 (800) 375-7520 2017, 04 www.staminaproducts.com...

  • Page 2: Table Of Contents

    7. Remain seated while pedaling the Airgometer 1100. Failure to do so could result in serious injury. 8. It is recommended that you place this exercise equipment on an equipment mat. 9. Set up and operate the Airgometer 1100 on a solid level surface. Do not position the Airgometer 1100 on loose rugs or uneven surfaces.
  • Page 3 1 (800) 375-7520 customer.care@staminaproducts.com Hi! From all of us here at Stamina Products, thank you for your purchase. We know that you have big fitness goals in mind and we are here to help you along. Call us, email us, or send us a message on Facebook. Be sure to contact us if you have any questions on your new product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the Airgometer 1100. Although Stamina constructs its products with We take great pride in producing this quality the finest materials and uses the highest standards product and hope it will provide many hours of...

  • Page 5: Equipment Warning, Caution & Notice Labels

    EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the Airgometer 1100. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels. Label is larger than actual size WARNING LABEL(99)

  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 3 Connect the CONNECTION WIRE(38) to the SENSOR WIRE(39). Slide the METER POST(5) onto the MAIN FRAME(1) and secure with BUTTON HEAD BOLTS(M8x1.25x15mm)(87), WASHERS(M8)(96), ARC WASHERS(M8)(97), and LOCK WASHERS(M8)(98). STEP 4 Attach the WATER BOTTLE HOLDER(78) to the METER POST(5) with ROUND HEAD SCREWS (M5x15mm)(85).
  • Page 9 ASSEMBLY INSTRUCTIONS WARNING: The SMALL CRANKS(44) require a special tool to remove once assembled. Read all of the following ASSEMBLY INSTRUCTIONS before attaching the SMALL CRANK(44). NOTE: 1. Align the ARROW MARK on the SMALL CRANK(44) with the WHITE MARK on the AXLE(9) when installing the two SMALL CRANKS(44) onto the AXLE(9).
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 6 Bolt the HANDLEBAR SHAFTS(69) to the MAIN FRAME(1) on both sides and securely tighten. STEP 7 Slide the WASHER(ø16.2xø22x1.5mm)(60) onto the HANDLEBAR SHAFT(69). Slide the RIGHT HANDLEBAR(7) onto the HANDLEBAR SHAFT(69) in approximately the center of the sliding range. Place the PLASTIC WASHER(ø10xø18x2mm)(58) on the SHAFT on the lower end of the RIGHT HANDLEBAR(7).
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 8 There is an “L” mark on the bottom side of the LEFT REST PEDAL(62), and an “R” mark on the bottom side of the RIGHT REST PEDAL(63). Attach the RIGHT REST PEDAL(63) to the HANDLEBAR SHAFT(69) in the RIGHT HANDLEBAR(7) with WAVY WASHER(ø17xø22x0.4mm)(49), WASHER(ø10xø25.4x2mm)(61), and the SHAFT BOLT(65).
  • Page 12 ASSEMBLY INSTRUCTIONS STEP 10 Attach the SEAT(70) to the SEAT POST(4) with NYLOCK NUTS(M8x1.25)(92) and WASHERS(M8)(96). Insert the SEAT POST(4) into the MAIN FRAME(1) and secure with the ADJUSTMENT KNOB(72). NOTE: The pin of the ADJUSTMENT KNOB(72) must be inserted into one of the adjustment holes in the SEAT POST(4) and the ADJUSTMENT KNOB(72) must be screwed in tight to ensure that the SEAT POST(4) will fit securely in the MAIN FRAME(1).

  • Page 13: Set Up Instructions

    The Airgometer 1100 is approximately 48 inches long x 24.6 inches wide x 52 inches tall. An area 4 feet wide x 6 feet long is required for safe operation of the Airgometer 1100.

  • Page 14: Operational Instructions

    OPERATIONAL INSTRUCTIONS SEAT HEIGHT ADJUSTMENT Proper seat height is important for efficient exercise. To determine proper seat height, sit on the Airgometer 1100 and center the ball of your foot on the pedal in the down position. Your leg should be slightly bent and relaxed as shown.
  • Page 15 OPERATIONAL INSTRUCTIONS USING THE FITNESS METER POWER ON: Pedal movement or press the MODE button. POWER OFF: Automatically shuts off after four minutes of inactivity. FUNCTION BUTTONS: MODE : Press and release to select functions for display or to preset target values. SET : Press to set target values for TIME, DISTANCE , and CALORIE.

  • Page 16: Storage

    1. To store the Airgometer 1100, simply keep it in a clean dry place. 2. The Airgometer 1100 is approximately 48 inches long x 24.6 inches wide x 52 inches tall. These dimensions may vary. Please measure your Airgometer 1100 if exact dimensions are needed.

  • Page 17: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 18: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your...

  • Page 19: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customer.care@staminaproducts.com, or call us at 1-800-375-7520.

  • Page 20: Product Parts Drawing

    PRODUCT PARTS DRAWING FRONT BACK...

  • Page 21: Parts List

    PARTS LIST PART# PART NAME Main Frame Rear Stabilizer Front Stabilizer Seat Post Meter Post Left Handlebar Right Handlebar Linkage Pulley and Axle Bearing (6003z) Inner C Ring (35mm) Spacer Washer (ø17 x ø22 x 0.5mm) C Ring (17mm) V-Ribbed Belt Idler Wheel Idler Wheel Spacer Large Washer (ø16 x ø32 x 0.5mm)
  • Page 22 PARTS LIST PART# PART NAME Handlebar Bushing Washer (ø16.2 x ø22 x 1.5mm) Washer (ø10 x ø25.4 x 2mm) Left Rest Pedal Right Rest Pedal Pedal Cover Shaft Bolt Foam Grip Round Plug (25.4mm) Oval Plug (20mm x 40mm) Handlebar Shaft Seat Sleeve Adjustment Knob...

  • Page 23: Fax/Mail Ordering Form

    P.O. Box 1071 Springfield, MO. 65801-1071 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...

This manual is also suitable for:

15-1100a

Table of Contents
