Pyle PLTV71 User Manual

Motorized 7”in -dash lcd color tv
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRINTED IN KOREA

Advertisement

Table of Contents
loading

Related Manuals for Pyle PLTV71

Summary of Contents for Pyle PLTV71

  • Page 1 PRINTED IN KOREA...

  • Page 2: Specification

    General Power Requirement Consumption Operating Temperature Audio Input Sensitivity Audio Output Voltage Video Input Signal Video Output Signal Speaker Dimensions Weight Monitor Section Screen Size LCD Type Drive System Number of Pixels Effective Pixels Back Lighting Color System FM Transmitter Frequency Specifications are subject to change without notice.
  • Page 3 CONNECTING TO CD CHANGER and AV SOURCES...

  • Page 4: Basic Connections

    V-OUT (YELLOW) PRE- (RED) (WHITE) V4-IN (YELLOW) 1. Do not connect the BATTERY wire (yellow color wire) to ignition or NOTE the ACC wire (red color wire) to Battery. The battery can be discharged. 2. Do not connect the PARKING BRAKE wire (brown color wire) to the battery or the ACC.

  • Page 5: Installation

    PRECAUTIONS Choose the mounting location carefully so that the unit will not interfere with the normal driving functions of the driver. Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight or hot air from the heater, or where it would be subject to dust, dirt or excessive vibration.

  • Page 6: Warning Screen

    WARNING SCREEN The monitor shows following warning picture when the parking brake is not set or when driving to prevent traffic accident that may be caused while watching the screen. The monitor shows the warning picture only and does not show any other pictures, but you can enjoy the sound and you can also adjust the sound volume.
  • Page 7 AV INPUT ON THE FRONT OF THE UNIT (3.5ø MONO) (3.5ø STEREO) 1.Connect a AV source output to AV input on the front of the unit. 2.Press the MODE button to select AV1 mode. NOTE 3.5 o AV Input on the front of the unit is connected with AV1 Input on the rear the unit. If the AV sources are connected both Input terminals, the 3.5 o AV Input has priority in working.
  • Page 8 DIRECT CD CHANGER CONTROL On the CD changer mode, you can directly control CD changer functions just by pressing the buttons on the remote contoller for our monitor unit. STOP ■ button : to make the playing of the disc stop. PAUSE button : to stop the playing of the disc .

  • Page 9: Intro Scan

    INTRO SCAN 1. Press the SEARCH UP/DOWN button to select INTRO SCAN. 2. Press the TILT UP/DOWN button on the remote controller to select the item. Each time you press the TILT UP/DOWN button, the item switches as follows. OFF <-> ONE <-> ALL ALL: The first 10 seconds of each track of all the discs will be played in succession..

  • Page 10: Track Number

    CD STATUS This is to show the current CD status such as DISC CHECK, SEEK ,PLAY and PAUSE. PLAY TIME This shows playing time of the disc being played. DISK NUMBER 1. Press the SEARCH UP/DOWN button to select DISC NUMBER. 2.

  • Page 11: Cd Changer Control

    When a CD /VCD changer is connected to this unit, the AV4 mode changes to CDC/VCD mode and CD CHANGER menu is displayed on the screen when AV4 mode is selected, 1. Press the MODE button to select the CD/VCD CHANGER (AV4) mode. Each time you press this button, the mode changes as follows.
  • Page 12 DIMMER This is to adjust the background illumination of the screen subject to the brightness of the outside. 1. Press the MENU button until PICTURE menu is selected. 2. Press the SEARCH UP/DOWN button to select DIMMER. 3. Press the VOLUME ◀ or ▶ button to select STANDARD/MILD/USER. Each time the VOLUME ◀...

  • Page 13: Picture Menu

    CONTRAST 1.Press the MENU button until following PICTURE menu is selected. 2.Press the SEARCH UP/DOWN button to select CONTRAST. 3.Press the VOLUME ◀ button for less contrast. Press the VOLUME ▶ button for stronger contrast. BRIGHTNESS 1.Press the MENU button until PICTURE menu is selected. 2.Press the SEARCH UP/DOWN button to select BRIGHT.

  • Page 14: Selecting Aspect Ratio

    SELECTING ASPECT RATIO 1. Press the MENU button until CONTROL menu is selected. 2. Press the SEARCH UP/DOWN button to select SCREEN. 3. Press the VOLUME ◀ or ▶ button to select the desired aspect ratio. Each time you press this button, the aspect ratio changes as follows. NORMAL <->...

  • Page 15: Back View Camera

    Connect video output of the Back View Camera to video 2 input of this unit, and then select CAMERA IN ON on the CONTROL menu. SETTING THE CAMERA IN 1. Press the MENU button until CONTROL menu is selected. 2. Press the SEARCH UP/DOWN button to select CAMERA IN. 3.

  • Page 16: Control Menu

    Connect AV output of the NAVIGATION system to AV3 input of this unit and then select NAVI IN ON on the CONTROL menu. SETTING THE NAVIGATION SYSTEM 1. Press the MENU button until CONTROL menu is selected. 2. Press the SEARCH UP/DOWN button to select NAVI IN. 3.

  • Page 17: Manual Memory

    MANUAL MEMORY 1.Press the SEARCH UP/DOWN button to select SKIP on TUNING menu. 2.Press the VOLUME ◀ or ▶ button to select SKIP ON/OFF. ON: The channel No is skipped OFF: The chnnel No is stored. FINE TUNING 1.Press the SEARCH UP/DOWN button to select FINE on TUNING menu. 2.Press the VOLUME ◀...

  • Page 18: Watching The Tv

    The monitor only shows the warning picture while driving to prevent traffic accident that may be caused when watching the screen. To watch TV, park the vehicle in a safe location and set the parking brake. If the parking brake is not set, the monitor does not shows the picture. but you can only enjoy the sound and you can also adjust the sound volume.

  • Page 19: Adjusting The Monitor Position

    ADJUSTING THE MONITOR POSITION ADJUSTING THE TILT POSITION 1. Press the MENU button to select FUNCTION menu 2. Press the SEARCH UP/DOWN button to select TILT. 3. Press the VOLUME ◀ button when MOVE FORWARD is selected. Each time you press the VOLUME ◀ button, the monitor will slant backward one step each.
  • Page 20 TURNING BUILT IN SPEAKER ON/OFF This is to listen the sound of AV sources with built in speaker or the car speakers when the audio output (PRE-OUT) of this unit is connected to the audio input of the car radio. 1.

  • Page 21: Selecting The Function

    TURNING FM TRANSMITTER ON/OFF This is to listen the sound of AV sources connected to this unit with the car speakers. Set the FM frequency of the built in FM transmitter at a FM frequency not using for FM stations. And then, set the FM frequency of the car radio at the same frequency of the FM transmitter.

  • Page 22: Selecting The Menu

    You can select the menu to make this unit or AV sources connected to this unit work in best conditions. POWER POWER MENU AS/ATM MUTE MODE NAVI DISC TRACK TRACK DISC ASPECT OPEN/CLOSE SELECTING THE MENU 1. Press the MENU button to select the desired menu. Each time the MENU button is pressed, the menu is selected as follows.

  • Page 23: Selecting Mode

    SELECTING MODE Press the MODE button to select the mode. Each time you press the MODE button, the mode changes as follows. 1.When a CD/VCD changer is not connected to this unit TV -> AV1 -> AV2 -> AV3 -> AV4 2.When a CD/VCD changer is connected to this unit TV ->...

  • Page 24: Selecting The Aspect Ratio

    SELECTING THE ASPECT RATIO Each time you press the A (ASPECT) button on the remote controller, the picture mode switches between Normal, Full, Zoom and Wide mode. NOTE You can also select the aspect ratio at SCREEN on CONTROL menu. For more information, see page 19.

  • Page 25: Adjusting Volume

    ADJUSTING THE LEFT/RIGHT VIEWING POSITION The monitor’ s left/right position can be adjusted easily by hand-operating as the picture below. ADJUSTING VOLUME Press the VOLUME < or > button to adjust the volume level of the built in speaker. NOTE 1.The volume adjustment dose not work while the FM TRANSMITTER is on.
  • Page 26 ADJUSTING THE TILT POSITION The TILT position can be adjusted in 5 steps by pressing the TILT UP/DOWN button on the monitor unit. Each time you press the TILT UP button, the monitor slants backward one step.Each time you press the TILT DOWN button, the monitor slants forward one step.

  • Page 27: Basic Operation

    POWER ON Press the POWER button to turn the power on. The sound works, but the monitor will not open. POWER OFF 1. Press the POWER button again to turn the power off. 2. If you turn the power off by pressing the POWER button when the monitor opens, the monitor will not close.

  • Page 28: Replacing Battery

    REPLACING BATTERY Replacing battery Applicable battery : Use two “AAA” sized dry batteries. 1. Opening the battery cover. Push and slide the cover in the arrow direction, and the cover will be removed. 2.Replacing the battery. Remove the old batteries. Insert new ones matching the (+) and (-) polarities as shown in the diagram inside the unit.

  • Page 29: Remote Controller

    REMOTE CONTROLLER ① POWER POWER ⑪ MENU ③ AS/ATM MODE ② NAVI ⑧ DISC TRACK TRACK DISC ⑩ OPEN/CLOSE ASPECT ① ① POWER ON/OFF BUTTON ⑥ ② ② .MODE SELECTION BUTTON ③ ③ AS/ATM BUTTON ⑤ ④ ④ SOUND MUTE BUTTON ④...
  • Page 30 MONITOR ⑥ ① 1.POWER ON/OFF BUTTON 2.MODE SELECTION BUTTON 3.CD MENU SELECTION BUTTON (BAND) 4.CD PAUSE BUTTON(AS/ATM) 5.VOLUME BUTTON 6.SEARCH BUTTON 7.TILT BUTTON 8.AUDIO MUTE BUTTON 9.MONITOR OPEN/CLOSE BUTTON 10.MENU SELECTION BUTTON 11.RESET HOLE 12.AUDIO INPUT 13.VIDEO INPUT ⑥ ② ③ ④...

  • Page 31: Fuse Replacement

    CAUTION The exclamation point within an equilateral triangle and “ “ CAUTION” ” are intended to alert the user to the presence of important operating instructions. Failure to heed the instructions can result in injury or material damage. Operation of some of the functions of this unit is very complex. Because of this, it was deemed necessary to place these functions into a special SETUP screen.
  • Page 32 CAUTION The exclamation point within an equilateral triangle and “ “ CAUTION” ” are intended to alert the user to the presence of important operating instructions. Failure to heed the instructions can result in injury or material damage. DO NOT RAISE THE VOLUME EXCESSIVELY Keep the volume at a level, where you can still hear outside noises while driving .
  • Page 33 WARNING The exclamation point within an equilateral triangle and “ “ WARNING” ” are intended to alert the user to the presence of important operating instructions. Failure to heed the instruction will result in severe injury or death. DO NOT WATCH VIDEO WHILE DRIVING Watching the video may distract the driver from looking ahead of the vehicle and cause an accident.
  • Page 34 CAUTION : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user ’ ’ s authority to operate the equipment.
  • Page 35 MOTORIZED 7 ” ” IN -DASH LCD COLOR TV MODEL: PLTV71...
