PLTV65R
OWNER'S MANUAL
Mobile Audio/Video System
AM/FM/MPX/TV-Tuner
PLL Synthesizer Stereo Radio
Built In Amplifier
Vertical Adjustable And Horizontal Rotatable Panel
Automatically Memory Storing
TFT Monitor
Remote Control
Optional TV Tuner (Separate Box)
CD Changer Control
4 x 40 Watts
www.pyleaudio.com
Advertisement
Table of Contents
Related Manuals for Pyle PLTV65R
Summary of Contents for Pyle PLTV65R
- Page 1 PLTV65R OWNER'S MANUAL Mobile Audio/Video System AM/FM/MPX/TV-Tuner PLL Synthesizer Stereo Radio Built In Amplifier Vertical Adjustable And Horizontal Rotatable Panel Automatically Memory Storing TFT Monitor Remote Control Optional TV Tuner (Separate Box) CD Changer Control 4 x 40 Watts www.pyleaudio.com...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instruction Installation DIN Front-Mount (Method A) Installing the unit Removing the unit DIN Rear-Mount (Method B) Wiring Connection Operation Location and function of keys Switching on/off the unit Open/close the monitor and angle adjustment Remote sensor Liquid crystal display 6.5 inch TFT display Reset function Operating when the monitor not... -
Page 3: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION CAUTION: Please read and observe all warnings and instructions given in this owner's manual. Keep these instructions. Retain this booklet for future reference. Please read the following safety instructions carefully. 1.This set has been designed and manufactured to assure personal safety. -
Page 4: Installation
INSTALLATION Notes: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. -
Page 5: Removing The Unit
INSTALLATION Sleeve L Key Outer Trim Ring R Key Mount the sleeve by inserting the sleeve into the opening of the dashboard and bend open the tabs located around the sleeve with a screwdriver. Not all tabs will be able to make contact, so examine which ones will be most effective. -
Page 6: Din Rear-Mount (Method B)
INSTALLATION DIN REAR-MOUNT (Method B) Factory radio mounting bracket Car radio mounting bracket Screw After aligning the car radio mounting bracket with the factory radio mounting bracket, tighten the screws (5x5mm) at 2 places on each side. When fix the factory radio mounting bracket with the screws, use s standard-tipped screwdriver to open the tabs of the car radio... -
Page 7: Wiring Connection
ELECTRICAL CONNECTION ANTENNA CONNECTOR (BLACK) Rch RED AV2 IN Lch WHITE VIDEO YELLOW (GREY) Rch RED AV OUT Lch WHITE VIDEO YELLOW (OPTIONAL) EXTERNAL REMOTE CONTRL To the TV unit with the 13-pin din Jack (SEPARATE BOX) (OPTIONAL) IGNITION SWITCH (ACC+) MEMORY/ YELLOW BATTERY(B+) -
Page 8: Operation
OPERATION LOCATION AND FUNCTION OF KEYS Fig.A 25 27 Fig.B... - Page 9 OPERATION LOCATION AND FUNCTION OF KEYS 2. OPEN/CLOSE 3. MUTE 4. LCD 5. TFT Monitor 6. SEL 7. VOLUME 8. VOLUME 9. Reset 10. IR 11. BND 12. MODE 13. TUNING TUNING/TRACK (For CDC Version Only) 14. TUNING TUNING/TRACK (For CDC Version Only) 15.
-
Page 10: Switching On/Off The Unit
OPERATION SWITCHING ON/OFF THE UNIT Switch on the unit by pressing POWER button (1) on the front panel or POWER button (34) on the remote control. When system is on, press it again to turn the unit off. OPEN/CLOSE THE MONITOR AND ANGLE ADJUSTMENT Press OPEN/CLOSE button (2) on the front panel or point the remote control... -
Page 11: Remote Sensor
OPERATION REMOTE SENSOR There is a remote sensor IR (10) on the front panel. On the monitor, there is another remote sensor IR (26) to receive remote control signal. You can point the remote control handset to IR (10) (when the monitor doesn't stretch out) or IR (26) (when the monitor stretches out) and press function keys on the remote control to control the TV... -
Page 12: Adjusting The Loud
OPERATION Adjusting the loud In loud mode, use VOLUME / buttons (7&8) or VOL / buttons(47) to switch between loud on and off. When LOUD on, "LOUD" will show on the display (4). Directly press LOUD button (52) to reinforce the bass output. Press it again to release the function. -
Page 13: Automatic Memory Storing
OPERATION Retrieve a Preset Station Press any one of the buttons (15) on the front panel or (37) on remote control to retrieve a station which had been stored in the memory in advance the chosen number is shown on display. -
Page 14: Operating When The Monitor Stretching Out
OPERATION OPERATING WHEN THE MONITOR STRETCHING OUT When the monitor stretches out, the front panel of the unit is in state B (see Fig.B), you can operate the unit by using the current menu displayed on the 6.5 inch color TFT display (5). And if the unit is connected to other TV unit through the cable with the 13-pin din plug on each terminal, there have... -
Page 15: Menu Control Operation In Cdc Mode
OPERATION Then you can press VOL / buttons (48) to select hour or minute and press TUN/CH / buttons (47) to change the corresponding item. Menu Control operation in CDC mode Press MODE button (12) on front panel or MODE button (43) to select CDC mode. -
Page 16: Menu Control Operation
OPERATION display, you can press "1 "button then press "6" button to select 16 channel. Menu control operation In TV mode: Press MENU button (19) or (45). The menu will show on the display (5). (For the unit with NTSC system): COLOR BRIGHT CONTRAST... -
Page 17: Specification
SPECIFICATION GENERAL Power Supply Requirements Maximum Output Power Current Drain Monitor Screen Size Resolution TV Sensitivity RADIO Frequency Coverage 87.5 to 107.9 MHz Sensitivity (S/N=30dB) Image Rejection >45dB Stereo Separation >25dB Frequency Coverage 530 to 1720 kHz Sensitivity (S/N=20dB) 36 dBu Image Rejection 45 dB : DC 12 Volts, Negative Ground... -
Page 18: Mobile Tv Tuner Unit
MOBILE TV TUNER UNIT... -
Page 19: Control & Function Keys
CONTROL & FUNCTION KEYS This unit can't be used separately and it must be used with other special system with the 13 -pin cable. The unit is connected to another system through the 13-pin din socket (3). And the unit can receive TV signal through the antenna input jack (2). 1 POWER INDICATOR LIGHT When the unit is connected to the other system with the 13-pin din cable and the other system turns on, the power indicator light (1) will be illuminated red and the... - Page 20 www.pyleaudio.com 88-T1690-04...
