- Page 1 AIR CONDITIONER (MULTI TYPE) Owner’s Manual For wireless remote controller Indoor Unit For commercial use Model name: High-Wall Type MMK-UP0271HP-AE MMK-UP0301HP-AE MMK-UP0361HP-AE Owner’s Manual English 1130550206 1130550206_EN.indd 1 1130550206_EN.indd 1 2/11/2565 BE 15:49 2/11/2565 BE 15:49...
- Page 2 Owner’s Manual Thank you very much for purchasing TOSHIBA Air Conditioner. Please read this owner’s manual carefully before using your Air Conditioner. Be sure to obtain the “Owner’s manual” and “Installation manual” from constructor (or dealer). Request to constructor or dealer Please clearly explain the contents of the Owner’s manual and hand over it.
-
Page 3: Table Of Contents
Owner’s Manual Contents PRECAUTIONS FOR SAFETY ..............5 ACCESSORIES ................... 11 PARTS NAME ....................11 PARTS NAME OF REMOTE CONTROLLER ..........13 ADJUSTING CLOCK ................... 15 LIMITED OPERATION BY GROUP CONTROL .......... 16 HANDLING THE REMOTE CONTROLLER ..........17 HOW TO USE REMOTE CONTROLLER ............ 18 HINTS FOR ECONOMICAL OPERATION .......... - Page 4 Toshiba Carrier Corporation or, alternatively, he or she has been instructed in such matters by an individual or individuals who have been trained and is thus thoroughly acquainted with the knowledge related to this work.
- Page 5 Owner’s Manual Warning indications on the air conditioner unit WARNING WARNING ELECTRICAL SHOCK HAZARD ELECTRICAL SHOCK HAZARD Disconnect all remote Disconnect all remote electric power supplies before electric power supplies servicing. before servicing. WARNING WARNING Moving parts. Moving parts. Do not operate unit with grille Do not operate unit with grille removed.
-
Page 6: Precautions For Safety
Owner’s Manual PRECAUTIONS FOR SAFETY DANGER • Do not attempt to install this unit by yourself. This unit requires quali ed installer. • Do not attempt to repair the unit by yourself. This unit has no components which you can repair. •... - Page 7 Owner’s Manual • When the air conditioner must be transported by hand, carry it by two or more people. Installation • Only a quali ed installer (*1) or quali ed service person (*1) is allowed to carry out the electrical work of the air conditioner. Under no circumstances must this work be done by an unquali ed individual since failure to carry out the work properly may result in electric shocks and/or electrical leaks.
- Page 8 Owner’s Manual • Do not touch the aluminum n of the outdoor unit. You may injure yourself if you do so. If the n must be touched, do not touch it yourself but contact a quali ed installer (*1) or quali ed service person (*1). •...
- Page 9 Owner’s Manual • If there is a danger of the outdoor unit’s toppling over, do not approach the outdoor unit but set the circuit breaker to the OFF position, and contact a quali ed installer (*1) or a quali ed service person (*1) to have the improvements or re tting done.
- Page 10 Owner’s Manual • Do not leave ammable sprays or other ammable materials near the air conditioner, and do not spray ammable aerosol directly to the air conditioner. They may catch re. • Stop running the air conditioner and turn off the breaker before cleaning. Otherwise, injury may result as the fan is rotating at high speed inside the unit.
- Page 11 Owner’s Manual Information on the transportation, handling and storage of the carton Examples of indication on the carton Symbol Description Symbol Description Keep dry Do not drop Fragile Do not lay down Stacking height (8 cartons can be stacked Do not walk on this carton in this case) This side up Do not step...
-
Page 12: Accessories
Owner’s Manual ACCESSORIES Remote controller Remote controller holder Batteries (two) PARTS NAME Indoor unit TIMER SET MODE TIME SAVE VENT FILTER RESET TEST SWING/FIX UNIT LOUVER 5 6 7 8 9,10 Air inlet grille Horizontal airflow louver (back) Air filter Vertical airflow louver Room temperature sensor Display panel... - Page 13 Owner’s Manual Names and functions of CAUTION indicators and controls on Disagreement in operation mode indoor unit If you select AUTOMATIC OPERATION in a model with no auto-changeover (cooling/ heating) Display panel control setting or if you select HEAT in a Cool Only model, an alarm sound (pi, pi) from the air conditioner due to disagreement in operation mode.
-
Page 14: Parts Name Of Remote Controller
Owner’s Manual PARTS NAME OF REMOTE CONTROLLER Wireless remote controller and its You can also manually select the desired fan speed functions from among ve settings. (LOW , LOW , MED , HIGH (A receiving beep is heard.) Auto louver button (SWING) Press this button to swing the louver. - Page 15 Owner’s Manual Names and functions of P (PRESET) display indications on wireless remote Indicated when memorizing the preferred operation controller mode or when it has been memorized. Also, this icon is indicated when the memorized preferred operation is displayed. Display (COMFORT SLEEP) display All indications, except for clock time indication, are indicated by pressing the START/STOP...
-
Page 16: Adjusting Clock
Owner’s Manual Clock adjusting ADJUSTING CLOCK Setting the clock Before you start operating the air conditioner, set the clock of the remote controller using the procedures given in this section. The clock panel on the remote controller will indicate the time regardless of whether the air conditioner is in use or not. -
Page 17: Limited Operation By Group Control
Owner’s Manual LIMITED OPERATION BY GROUP CONTROL NOTE Group control: Operate air conditioners in more than one system in same time. Header indoor unit: The representative unit during group control. Receive commands from wired remote controller and transmit the commands to follower units. (Header indoor unit is indoor unit that receives START/STOP signal from the wireless remote control.) Follower indoor unit: Indoor units other than the Header unit are called follower unit. -
Page 18: Handling The Remote Controller
Owner’s Manual HANDLING THE REMOTE CONTROLLER Remote controller holder CAUTION Installing the remote controller holder The air conditioner will not operate if curtains, doors or other materials block the signals from Before you actually install the remote controller the remote controller to the indoor unit. holder on a wall or pillar, check whether the Prevent any liquid from falling into the remote remote controller signals can be received by the... -
Page 19: How To Use Remote Controller
Owner’s Manual HOW TO USE REMOTE CONTROLLER Cooling/heating/fan only operation Dry operation Start Start SWING SWING START/STOP button ( START/STOP button ( Press this button to start the air conditioner. Press this button to start the air conditioner. Mode select button (MODE) Mode select button (MODE) Select Dry Select Cool... - Page 20 Owner’s Manual Automatic operation Timer operation (auto changeover) Use the wired remote controller for timer setting if it is also in use. This function is available only for use in ON timer and OFF timer combination with a heat recovery model outdoor unit.
- Page 21 Owner’s Manual Once you select the timer operation mode, the ON timer OFF timer settings are saved in the remote controller. (Stop Operation Stop) Thereafter, the air conditioner will start operating You can use this setting to start the air conditioner under the same conditions when you simply press when you wake up and stop it when you leave the the ON/OFF button of the remote controller.
- Page 22 Owner’s Manual High power operation ECO operation • The ECO mode provides ECO operating status High power (Hi POWER) by automatically control room temperature to • The Hi POWER (high power operation) mode save energy (except in DRY and FAN ONLY automatically controls room temperature, air ow mode).
- Page 23 Owner’s Manual Preset Operation CAUTION Set your preferred operation mode for future use. The COMFORT SLEEP mode is not enabled in the The setting is memorized by the unit for future DRY or FAN ONLY operation. operation (except air ow direction). NOTE •...
- Page 24 Owner’s Manual Adjusting airfl ow direction To automatically swing the airflow direction Perform this function when the air conditioner is in Adjust the airflow direction properly. Otherwise, operation. it might cause discomfort and make the room temperature uneven. Adjust the vertical airflow using the remote controller.
- Page 25 Owner’s Manual CAUTION The FIX and SWING buttons will be disabled when the air conditioner is not in operation (including when the ON timer is set). Do not operate the air conditioner for long hours with the airflow direction set downward during the cooling or dry operation.
-
Page 26: Hints For Economical Operation
Owner’s Manual HINTS FOR ECONOMICAL OPERATION Maintain room temperature at comfortable level Clean air lters The clogged air lters impairs the performance of the air conditioner. Gee, chilly Clean them once two weeks. Control Never open doors and windows more often than necessary Clean, please To keep cool or warm air in the room, never open... -
Page 27: Temporary Operation
Owner’s Manual TEMPORARY OPERATION TEMPORARY operation This function is used to operate the unit temporarily in case you misplace the wireless remote controller or its batteries are exhausted. Push the [RESET] button once (less than 3 seconds) to start the air conditioner. The last operation conducted with the wireless remote controller will be performed. -
Page 28: Maintenance
Owner’s Manual MAINTENANCE WARNING Before you clean the air conditioner, be sure to turn off the circuit breaker or main power switch. Cleaning of indoor unit and remote controller CAUTION • Use a dry cloth to wipe the indoor unit and remote controller. •... - Page 29 Owner’s Manual Cleaning the air fi lter 4. Insert the upper portion of air fi lter confi rming to fi t its right and left edges on the indoor unit until Clean the air fi lters every 2 weeks. If the air fi lters it is fi rmly set.
- Page 30 Owner’s Manual 3. Wipe out water from the air inlet grille and dry it. When not used for a long time 4. Fit the left and right arms of the air inlet grille to to dry inside. the shafts on the two sides of the air conditioner and push in completely.
-
Page 31: Troubles And Causes
Owner’s Manual TROUBLES AND CAUSES For contents of the outdoor unit, combinations, etc., refer to the owner’s manual supplied with the outdoor unit. CAUTION If any of the following conditions occur, stop the air conditioner immediately, set to off the main power switch and contact the dealer: Switch operation are erratic. - Page 32 Owner’s Manual These are not failures. The back of indoor unit is dewed. • Dewdrops on the back of the indoor unit are automatically collected and drained out. Indoor unit or outdoor unit makes a strange noise. • When temperature sharply changes, the indoor or outdoor unit occasionally makes a strange noise because of expansion/contraction of parts or change of refrigerant ow.
- Page 33 MEMO - 32 - BE 14:52 OM_1121250207_EN.indd 32 6/8/2562 BE 14:52 1130550206_EN.indd 33 1130550206_EN.indd 33 2/11/2565 BE 15:49 2/11/2565 BE 15:49...
- Page 34 MEMO - 33 - OM_1121250207_EN.indd 33 6/8/2562 BE 14:52 1130550206_EN.indd 34 1130550206_EN.indd 34 2/11/2565 BE 15:49 2/11/2565 BE 15:49...
- Page 35 BE 14:52 1130550206_EN.indd 35 1130550206_EN.indd 35 2/11/2565 BE 15:49 2/11/2565 BE 15:49...
- Page 36 144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road, Tambol Bangkadi, Amphur Muang, Pathumthani 12000, Thailand 1130550206 1130550206_EN.indd 36 1130550206_EN.indd 36 2/11/2565 BE 15:49 2/11/2565 BE 15:49...
