Summary of Contents for Toshiba MMK-UP0151HP-E
- Page 1 Installation Manual Indoor Unit Model name: For commercial use High-Wall Type MMK-UP0151HP-E, MMK-UP0151HPL-E MMK-UP0181HP-E, MMK-UP0181HPL-E MMK-UP0241HP-E, MMK-UP0241HPL-E When the HPL model (MMK-UP*HPL-E) is installed, PMV kit (RBM-PMV0903E) is necessary English Installation Manual...
-
Page 2: Table Of Contents
Installation Manual Original Instruction Please read this Installation Manual carefully before installing the Air Conditioner. This Manual describes the installation method of the indoor unit. For installation of the outdoor unit, follow the Installation Manual attached to the outdoor unit. ADOPTION OF NEW REFRIGERANT This Air Conditioner is a new type which adopts a new refrigerant HFC (R410A) instead of the conventional refrigerant R22 in order to prevent destruction of the ozone layer. - Page 3 The qualified service person is a person who installs, repairs, maintains, relocates and removes the air conditioners made by Toshiba Carrier Corporation. He or she has been trained to install, repair, maintain, relocate and remove the air conditioners made by Toshiba Carrier Corporation...
- Page 4 Installation Manual Definition of Protective Gear When the air conditioner is to be transported, installed, maintained, repaired or removed, wear protective gloves and ‘safety’ work clothing. In addition to such normal protective gear, wear the protective gear described below when undertaking the special work detailed in the table below.
- Page 5 Installation Manual Warning indications on the air conditioner unit Warning indication Description WARNING WARNING ELECTRICAL SHOCK HAZARD ELECTRICAL SHOCK HAZARD Disconnect all remote electric power supplies Disconnect all remote electric power supplies before servicing. before servicing. WARNING WARNING Moving parts. Moving parts.
-
Page 6: Precautions For Safety
Installation Manual PRECAUTIONS FOR SAFETY • Ensure that all Local, National and International regulations are satis ed. • Read this “PRECAUTIONS FOR SAFETY” carefully before Installation. • The precautions described below include the important items regarding safety. Observe them without fail. •... - Page 7 Installation Manual • Do not climb onto or place objects on top of the outdoor unit. You may fall or the objects may fall off of the outdoor unit and result in injury. • When work is performed at heights, use a ladder which complies with the ISO 14122 standard, and follow the procedure in the ladder’s instructions.
- Page 8 Installation Manual topple over or give rise to noise, vibration, water leakage or other trouble. • Carry out the specied installation work to guard against the possibility of high winds and earthquake. If the air conditioner is not installed appropriately, a unit may topple over or fall down, causing an accident.
- Page 9 Installation Manual • Install a circuit breaker that meets the speci cations in the installation manual and the stipulations in the local regulations and laws. • Install the circuit breaker where it can be easily accessed by the agent. • When installing the circuit breaker outdoors, install one which is designed to be used outdoors.
- Page 10 Installation Manual Relocation • Only a qualifi ed installer(*1) or qualifi ed service person(*1) is allowed to relocate the air conditioner. It is dangerous for the air conditioner to be relocated by an unqualifi ed individual since a fi re, electric shocks, injury, water leakage, noise and/or vibration may result.
-
Page 11: Accessory Parts
Installation Manual ACCESSORY PARTS Part name Q’ty Shape Usage (Hand over to customers) (For other languages that do not appear in Installation Manual This manual this installation Manual, please refer to the enclosed CD-R.) (Hand over to customers) (For other languages that do not appear in Owner’s Manual this installation Manual, please refer to the enclosed CD-R.) -
Page 12: Selection Of Installation Place
Installation Manual SELECTION OF INSTALLATION PLACE WARNING • Install the air conditioner at enough strong place to withstand the weight of the unit. If the strength is not enough, the unit may fall down resulting in injury. CAUTION • Do not install the air conditioner in a location subject to a risk of exposure to a combustible gas. - Page 13 Installation Manual Installation diagram of Indoor and outdoor units For the rear left and left piping Before installing the wireless remote controller Hook Wall 1. Remove the battery cover. Installation 2. Insert 2 new batteries plate (R03 [AAA] type) Insert the cushion between the positions.
-
Page 14: Installation Of Indoor Unit
Installation Manual Wireless remote controller Indoor unit range INSTALLATION OF INDOOR UNIT WARNING Install the air conditioner certainly to sufficiently withstand the weight. REQUIREMENT be sure to use buffering cloth, etc. to not damage the unit. parts, etc. specified. NO GOOD NO GOOD Screen 13-EN... -
Page 15: Cutting A Hole And Mounting Installation Plate
Installation Manual CUTTING A HOLE AND MOUNTING INSTALLATION PLATE Cutting a hole When the installation plate is directly mounted on the wall In case of installing the refrigerant pipes from the rear: 1. Decide the hole position for piping at wall by screwing it in the upper and lower 180 mm from the arrow mark ( ) on the parts to hook up the indoor unit. -
Page 16: Piping And Drain Hose Installation
Installation Manual PIPING AND DRAIN HOSE INSTALLATION Piping and drain hose forming * Since dewing results in a machine trouble, make sure to insulate both connecting pipes. (Use polyethylene foam as insulating material.) Rear right Rear left Bottom left Left Bottom right Right 1. - Page 17 Installation Manual How to remove the drains cap Clip the drain cap by needle-nose pliers and pull out. 2) Firmly insert drains cap. Do not apply lubricating oil (refrigerant machine oil) when inserting the drain cap. Application causes deterioration and drain leakage from the plug.
- Page 18 Installation Manual In case of bottom right or bottom left piping • After scribing slits of the front panel with a knife or a marking-off pin, cut them with a pair of nippers or an equivalent tool. Slit Left-hand connection with piping Bend the connecting pipe so that it is laid within 43 mm above the wall surface.
-
Page 19: Indoor Unit Fixing
Installation Manual INDOOR UNIT FIXING DRAINAGE 1. Run the drain hose sloped downwards. 1. Pass the pipe through the hole in the wall, and hook the indoor unit on the installation NOTE plate at the upper hooks. • Hole should be made at a slight downward 2. -
Page 20: Refrigerant Piping
Installation Manual REFRIGERANT PIPING Refrigerant Piping Permissible Piping Length and Height Difference Use copper pipe with 0.8 mm or more thickness. (In case pipe size is dia. 15.9, They vary according to the outdoor unit. with 1.0 mm or more.) For details, refer to the Installation Manual attached to the outdoor unit. - Page 21 Installation Manual Tightening connection Heat insulation Heat insulation for the pipes should be done CAUTION separately for the liquid side and gas side. Because both of the liquid and gas side pipes become a low temperature during cooling done to prevent condensation. •...
-
Page 22: Electrical Connection
Installation Manual ELECTRICAL CONNECTION REQUIREMENT WARNING 1. Using the specified wires, ensure to Local Regulation in each country. connect the wires, and fix wires securely so that the external tension to the wires do not follow the Installation Manual of each outdoor affect the connecting part of the terminals. - Page 23 Installation Manual Power supply wire and communication wires specifications Power supply wire and communication wires are procured locally. For the power supply specifications, follow the table below. Power supply wiring and communication wiring are to be procured locally. For specifications of the power capacity of the outdoor unit and the power supply wires, refer to the Installation Manual supplied with the outdoor unit.
- Page 24 Installation Manual <In the case of combining with outdoor units of Super Modular Multi System u series (SMMS-u)> 0.5 mm² (Up to 500 m) Uv line and Uc line (L2, L3, L4) Wire size : (2-core shield wire, non-polarity) 0.75 to 1.25 mm² (Up to 1000 m) 0.75 to 1.25 mm²...
- Page 25 Installation Manual <In the case of combining with outdoor units other than Super Modular Multi System u series (SMMS-u)> Control wiring between indoor units, and outdoor unit (L2, L3) (2-core shield wire, non-polarity) 1.25 mm² (Up to 1000 m) Wire size : 2.0 mm²...
- Page 26 Installation Manual Wired remote controller wiring This wiring is not required when using the supplied wireless remote controller. Total wire length of wired remote controller wiring and remote CAUTION The remote controller wire (Communication line) and AC 208 – 240V wires cannot be parallel to contact each other and cannot be stored in the same conduits.
- Page 27 Installation Manual Wiring between indoor unit and outdoor units ■ NOTE A wiring diagram below is an example for connection to SMMS-u series. For connecting to other • outdoor unit series, refer to the Installation Manual attached to the outdoor unit to be connected. ▼...
- Page 28 Installation Manual Wired remote controller wiring As the wired remote controller wire has non-polarity, there is no problem if connections to indoor unit terminal blocks A and B are reversed. Wiring diagram Terminal block for remote controller Terminal block wiring of indoor unit Wired remote controller unit Wired remote controller wire...
- Page 29 Installation Manual Wiring Connection Power supply terminal block How to connect the power supply wiring Terminal block for communication/remote and control wiring controller wiring The power supply wire and the control wire can be Screw connected without removing the front panel. Terminal cover REQUIREMENT Earth screw...
- Page 30 Installation Manual indoor unit. 1. Remove the air inlet grille. Open the air inlet grille upward and pull it toward you. 2. Remove the terminal cover and the clamp base. 3. Insert the control wire fully into the control/wired remote controller terminal block and secure it tightly with screws.
-
Page 31: Applicable Controls
Installation Manual APPLICABLE CONTROLS REQUIREMENT When the air conditioner is used for the fi rst time, it will take some moments after the power has been turned on before the remote controller becomes available for operations: This is normal and is not indicative of trouble. Concerning the automatic addresses •... - Page 32 Installation Manual Change of lighting time of filter Push OFF timer button. sign By doing so, the setup is completed. To change other settings of the selected • According to the installation condition, the lighting indoor unit, repeat from Procedure time of the filter sign (Notification of filter cleaning) When all the settings have been can be changed.
- Page 33 Installation Manual Adjustment of air direction 1. Using the remote controller switch, change the up/down air direction by moving the horizontal louver. 2. Adjust the right/left air direction by bending the vertical grille inside of the air outlet port with hands. REQUIREMENT Do not touch the horizontal louver directly with hands;...
-
Page 34: Test Run
Installation Manual TEST RUN Before test run Wired remote controller ■ Be sure to stop the air conditioner before Before turning on the power supply, carry out • making settings. the following procedure. 1) By using insulation tester (500VMΩ), check (Change the setup while the air conditioner is not that resistance of 1MΩ... - Page 35 Installation Manual In case of wireless remote controller different way.) REQUIREMENT • For the operation procedure, be sure to follow the Owner’s Manual. • Finish the forced cooling operation in a short time because it applies excessive strength to the air conditioner. •...
-
Page 36: Troubleshooting
Installation Manual TROUBLESHOOTING A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Confirmation and check ■ If a problem occurs with the air conditioner, the OFF timer indicator alternately shows the check code and the indoor Unit No. - Page 37 Installation Manual Check method On the remote controller (Wired remote controller, Central control remote controller) and the interface P.C. board of the outdoor unit (I/F), a check display LCD (Remote controller) or 7-segment display (on the outdoor interface P.C. board) to display the operation is provided. Therefore the operation status can be known.
- Page 38 Installation Manual Check code Wireless remote controller Wired Sensor block display of Judging Outdoor unit 7-segment display Check code name remote receiving unit device controller Auxiliary code Operation Timer Ready Flash display 01: Outdoor unit of other line connected Other line connected during automatic 02: Indoor unit of other line address connected...
- Page 39 Installation Manual Check code Wireless remote controller Wired Sensor block display of Judging Outdoor unit 7-segment display Check code name remote receiving unit device controller Auxiliary code Operation Timer Ready Flash display ─ Low pressure protective operation ─ Oil level down detective protection 01: TK1 sensor trouble 02: TK2 sensor trouble 03: TK3 sensor trouble...
- Page 40 Installation Manual Check code Wireless remote controller Wired Sensor block display of Judging Outdoor unit 7-segment display Check code name remote receiving unit device controller Auxiliary code Operation Timer Ready Flash display Outdoor heat exchanger freezing ─ trouble ─ ─ Indoor unit fan motor trouble Indoor unit ─...
- Page 41 Installation Manual *1 Inverter quantity information (Super Modular Multi System e and u series (SMMS-e, SMMS-u)) Comp. Inverter Inverter Trouble Comp. 1 Comp. 2 Comp. 1 + Comp. 2 Fan1 Comp. 1 + Fan1 Comp. 2 + Fan1 Comp. 1 + Comp. 2 + Fan1 Fan2 Comp.
- Page 42 Installation Manual WARNINGS ON REFRIGERANT LEAKAGE Check of Concentration Limit NOTE 2 The standards for minimum room volume are as The room in which the air conditioner is to be follows. installed requires a design that in the event of (1) No partition (shaded portion) refrigerant gas leaking out, its concentration will not exceed a set limit.
- Page 43 Installation Manual CONFIRMATION OF INDOOR UNIT SETUP Prior to delivery to the customer, check the address and setup of the indoor unit, which has been installed in this time and fill the check sheet (Table below). Data of four units can be entered in this check sheet. Copy this sheet according to the No.
- Page 44 144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road, Tambol Bangkadi, Amphur Muang, Pathumthani 12000, Thailand 1121250498...
