Summary of Contents for Planar PE190
-
Page 2: Table Of Contents
Troubleshooting ... 8 Preface This manual is designed to assist users in setting up and using the LCD Monitor. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. -
Page 3: Chapter 1 Installation
4. Do not remove the cover or attempt to service this unit by yourself. Servicing of any nature should be performed by an authorized technician. 5. Store LCD Monitor in a room with a room temperature of -20° ~ 60°C (or -4° ~ 140°F). Storing the LCD Monitor outside this range could result in permanent damage. -
Page 4: Interface For Arm Applications
Connecting the Display to your Computer Power off your computer. Connect one end of the signal cable to the LCD Monitor’s VGA port (See Fig 1-5) Connect the other end of the signal cable to the VGA port on your Make sure connection are secure. -
Page 5: Power Management System
This LCD Monitor complies with the VESA DPMS (version 1.0) Power Management guidelines. The VESA DPMS provides four power saving modes through detecting a horizontal or vertical sync. signal. When the LCD Monitor is in power saving mode, the monitor screen will be blank and the power LED indicator will light yellow. -
Page 6: Function Description
Function Description Icon Function Brightness Contrast H. Position V. Position Sharpness OSD Transparency Phase Clock Color Temperature OSD H. Position OSD V. Position Graph / Text Recall Language Auto Exit Icon Function 9300 CIE coordinated Color Temperature of 9300°K 7500 CIE coordinated Color Temperature of 7500°K 6500 CIE coordinated Color Temperature of 6500°K... -
Page 7: Chapter 3 Technical Information
Chapter 3 Technical Information Specifications LCD Panel Size Display Type Resolution Display Dot Display Area (mm) Display Color Brightness Contrast Ratio Response Time Lamp Voltage Lamp Current Viewing Angle Video Input Signal Input Impedance Polarity Amplitude Multi-mode Supported Control Power switch (hard and soft types) Brightness Contrast Horizontal Position... - Page 8 Sync Input Signal Polarity Plug & Play External Connection Power Input (AC input) Video Cable Environment Operating Condition: Storage Condition: Power Supply (AC Input) Input Voltage Input Current Size and Weight Dimensions Net Weight Gross Weight Pin Assignment Separate TTL compatible horizontal and vertical synchronization Positive and negative Supports VESA DDC2B functions Power cord...
-
Page 9: Standard Timing Table
3. If step 2 doesn’t work, connect your PC system to another external CRT. If your PC system Functions properly with a CRT Monitor but it does not function with the LCD Monitor, the output timing of the VGA card may be out of the LCD’s synchronous range.
