Summary of Contents for Planar PE150M
-
Page 2: Table Of Contents
Identifying Components The LCD Monitor — Front View The LCD Monitor — Rear View Adjusting the Tilting Angle Raising Your Monitor to an Upright Position and Adjusting Monitor Angle Connecting AC Power, Video and Audio Cable Power Management System CHAPTER 2 ... 6 LCD Monitor Control Panel Adjusting the Monitor’s Display... -
Page 4: Chapter 1
Unpacking After you unpack your LCD monitor, make sure the following items are included in the box and in good condition: Standard Items PE150M LCD monitor VGA Cable With 15-Pin D-Sub VGA Connector (Male) Power cord User’s Manual CD Manual Landing Strip 1.5M Stereo Jack audio cable... -
Page 5: Identifying Components
This LED indicator stays lit when the power is on and blinks when the LCD monitor is in power saving mode 2. Monitor Stand 3. LCD Screen The LCD monitor screen is a 15-inch TFT 1024 x 768 screen. 4. LCD Monitor Control Panel Refer to Chapter 2 for details. -
Page 6: The Lcd Monitor - Rear View
3. VGA Cable With 15-Pin D-Sub VGA Connector (Male) 4. VESA interface: It can be mounted to VESA arm. (75mm pitch) Adjusting the Tilting Angle The LCD monitor’s angle settings range from -5 to 25 . See Figure 1-3. Figure 1-3: Tilting the Monitor... -
Page 7: Raising Your Monitor To An Upright Position And Adjusting Monitor Angle
Raising Your Monitor to an Upright Position and Adjusting Monitor Angle... -
Page 8: Connecting Ac Power, Video And Audio Cable
Connecting AC Power, Video and Audio Cable Turn off your PC and the LCD monitor before connecting your LCD monitor to the computer. Power Management System The LCD monitor complies with the VESA DPMS power management proposal. When the LCD monitor is in power saving mode or detects an incorrect timing, the monitor screen will be blank and the power LED indicator starts blinking. -
Page 9: Chapter 2
OSD. Press either button to scroll through the main menu and submenu items 4. Power Switch Push the power switch to turn the monitor on and off. This switch is also a hot-key button to close the OSD menu. The Display Controls... -
Page 10: Adjusting The Monitor's Display
Pressing the OSD Menu button causes the following screen to appear: The Auto Adjust Option Choosing the Auto Adjust option lets the monitor determine and select the settings that are most appropriate for your system requirements. With the Auto Adjust icon selected, press the Adjustment control button to apply the monitor settings automatically. - Page 11 H-Position: To move the LCD monitor’s display left or right on a horizontal plane. V-Position: To move the LCD monitor’s display up or down on a vertical plane. Phase: To adjust the focus and clarity of the display. Clock: To adjust the display pixel alignment.
- Page 12 Contrast: To adjust the contrast level of the display screen. Brightness: To adjust the light level on the display screen. Color: To select the LCD monitor’s color display. The available options are 9300, 6500 and User. Selecting the user option lets you make individual adjustments to the R, G and B items.
- Page 13 Signal out of monitor’s supported range Then the frequency range of the signal is out of the monitor's specifications, the display will show messages in the following manner: Case 1: The incoming frame rate is higher than 75Hz.
-
Page 14: Hot-Key Buttons For Quick Adjustment Of Monitor Settings
Hot-Key Buttons for Quick Adjustment of Monitor Settings. 1. “ Auto-adjust” hot-key button: Press the 2 function button to apply the monitor setting automatically. A small “Auto Adjust” OSD is also displayed. 2. “Contrast-adjust” hot-key button: Press the 1 adjustment control button to allow you to adjust the contrast of the display directly. -
Page 15: Appendix A
TFT LCD Monitor Specifications LCD Panel Control Functions Power On-Screen Display Main Menu (OSD) Auto Adjust Monitor Control OSD Control Misc. Control Graphic Control Graph/Text OSD Exit Display Area (mm) Display Colors Video Interface Scanning Frequency H/V, Hz Response Time (TR/TF) (typ.) -
Page 16: Supported Timing
Item Standards NEC PC98 NEC PC98 MAC 13" mode MAC 16" mode MAC 17" mode VESA VESA VESA SVGA VESA VESA VESA VESA *Once a mode is optimized, there is no need to make any further adjustment as long as the VGA card remains unchanged. *Specifications are subject to change without notice. -
Page 17: Appendix C
Troubleshooting Procedures This LCD monitor comes pre-adjusted with standard VGA timing. Due to output timing differences among various VGA cards, you may initially experience an unstable or unclear display when a new display mode or new VGA card is selected. - Page 18 PROBLEM: There is no LCD Display If there is no display on the LCD, refer to the following: 1. Make sure that the power indicator on the LCD monitor is lit, all connections are secure, and the system is running on the correct timing.
-
Page 19: Preface
FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subjected to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. -
Page 20: Radio Frequency Interference Statement
Caution: To comply with the limits for an FCC Class B computing device, always use the shielded signal cord supplied with this unit. The Federal Communications Commission warns that changes or modifications of the unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 21: Important Operating Instructions
Servicing of any nature should be performed only by an authorized technician. 6. Safe storage of the LCD monitor is in a range of minus 20 to plus 60 degrees Celsius. Storing your LCD monitor outside this range could result in permanent damage. - Page 22 01/04 6200506511...
