- Page 1 PLANAR LCD MONITOR PX191 MANUAL www.planar.com...
-
Page 2: Table Of Contents
Table of Contents Usage Notice Precautions ................. 2 Introduction About the Product ................ 3 Package Overview ..............4 Installation Product Overview ................ 5 Connecting the Display ............... 7 User Controls Front Panel Controls ..............10 How to Use the OSD Menus............11 On-Screen Display Menus ............ -
Page 3: Usage Notice
Usage Notice To prevent the risk of fire or shock hazards, do not Warning- expose this product to rain or moisture. Please do not open or disassemble the product as this Warning- may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 4: Introduction
Introduction About the Product Having a 19” flat panel screen with an active matrix, thin-film transistor (TFT) liquid crystal display (LCD) , this product also demonstrates following outstanding features: Analog and Digital signal input Active matrix TFT LCD technology 1280 x 1024 addressable pixels 19”... -
Page 5: Package Overview
Package Overview LCD Display Power Adapter Power Cord DVI-D Cable VGA Signal Cable User’s Manual Quick Start Guide Planar Product Family CD English... -
Page 6: Installation Product Overview
Installation Product Overview Front View LCD Display Panel Controls Stand Rear View Kensington Lock Connector Ports Digital Port VGA Input Power-In English... -
Page 7: Vesa Mount On Your Monitor
VESA Mount on your monitor This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface Standard which defines a physical mounting interface for flat panel monitors, and corresponding standards for flat panel monitor mounting devices, such as wall and table arms.The VESA mounting interface is located on the back of your monitor. -
Page 8: Connecting The Display
Connecting the Display (Figure 8.1) To setup this display, please refer to the following figure and procedures. 1. Be sure all equipments are off. 2. Connect the DC power cord to the power connector; plug one end of the AC power cord into the power adapter, and then the other end into an electrical outlet( 3. - Page 9 Figure 8.1 Œ Power Adapter Cable & Power Cord Ž DVI-D Cable English...
-
Page 11: User Controls Front Panel Controls
User Controls Front Panel Controls ÂÃÄ ÅÂÆÂÇÈÉÄÈ Œ Ž ‘ No./ Icon Control Function Œ MENU Menu button To pop up the OSD menus. SELECT/AUTO Select/Auto Select- To select the adjust- ment items from OSD menus. Auto-To activate the “Auto Adjustment”... -
Page 12: How To Use The Osd Menus
How to Use the OSD Menus 1. Press the “M” button to pop up the on-screen menu and to select between the four Main Menus. 2. Choose the adjustment items by pressing the “S” button. 3. Adjust the value of the adjustment items by pressing the “ - ” or “ + ” button. -
Page 13: On-Screen Display Menus
On-Screen Display Menus First OSD Menu: Auto-Adjustment Chooses this function to obtain an optimum image. Contrast Adjusts the contrast of the display image. Brightness Adjusts the brightness of the display image. Horizontal Position Changes the horizontal position of the image. Vertical Position Changes the vertical position of the image. -
Page 14: Display Mode
Second OSD Menu: Display Mode Selects this function to demonstrate the display resolution, vertical refresh, and horizontal scan of the current mode. OSD Off-Time Adjusts the time period for OSD menu disappear. Language Chooses the language you need. Sharpness Adjust the sharpness of the image. Reset Returns the display parameters of the current mode to its factory default settings. -
Page 15: Input Select
Third OSD Menu: Input Select It allows you to select the type of signal. English... -
Page 16: Color Setting
Fourth OSD Menu: Color Setting Adjusts the color temperature. Color Adjustment-Red It allows you to adjust the red color of the display. Color Adjustment-Green It allows you to adjust the green color of the display. Color Adjustment-Blue It allows you to adjust the blue color of the display. English... -
Page 17: Appendices
Appendices Troubleshooting If you are experiencing trouble with the LCD display, refer to the follows. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Check that all the I/O and power connectors are correctly and well connected as described in the “... -
Page 18: Warning Signal
Warning Signal Sometimes you probably will see the warning messages from this LCD screen. This means that the LCD display cannot exactly receive the signal from the computer graphic card. There are three kind of situations may happen.Please check with the connected cables or contact your local dealer for more information. -
Page 19: Product Dimensions
Product Dimensions 417.78mm/16.45” 508.74mm/20.03” Front View 59mm/2.32” Side View 215.40mm/8.48” Top View English... -
Page 20: Compatibility Modes
Compatibility Modes t u l English... - Page 21 3/2003...
