Summary of Contents for Planar PE170
-
Page 2: Table Of Contents
Table of Contents Preface ...1 Chapter 1 Installation...2 Unpacking ... 2 Connecting the LCD Monitor and Base ... 2 Viewing Angle Adjustment ... 2 Detaching LCD Monitor from Its Stand ... 3 Interface for Arm Applications ... 3 Connecting the Display ... 3 Connecting the AC Power ... -
Page 3: Chapter 1 Installation
Important Safety Instructions Please read the following instructions carefully. This manual should be retained for future use. 1. To clean LCD Monitor screen; -- Power off LCD Monitor and unplug the AC Cord. -- Spray a non-solvent cleaning solution onto a rag. -- Gently clean the screen with dampened rag. -
Page 4: Detaching Lcd Monitor From Its Stand
Detaching LCD Monitor from Its Stand Unscrew screws the swivel base support column and pull down the hinge to release. Interface for Arm Applications Before installing to mounting device, please refer to Fig.1-3. The rear of this LCD display has four integrated 4 mm, 0.7 pitches threaded nuts, as well as four 5 mm access holes in the plastic covering as illustrated in Figure 1-4. -
Page 5: Chapter 2 Display Controls
Chapter 2 Display Controls User Controls A brief description and the location of all LCD Monitor function controls and indicators: Press the power switch to switch the monitor ON/OFF. DC Power Switch LED lights Green color --- Power is ON. DC Power-On LED lights Yellow --- Monitor is in "Power Saving Mode". -
Page 6: Function Description
Function Description Icon Function Brightness Contrast H. Position V. Position Sharpness OSD Transparency Phase Clock Color Temperature OSD H. Position OSD V. Position Graph / Text Recall Language Auto Exit Icon Function 9300 CIE coordinated Color Temperature of 9300°K 7500 CIE coordinated Color Temperature of 7500°K 6500 CIE coordinated Color Temperature of 6500°K... -
Page 7: Chapter 3 Technical Information
Chapter 3 Technical Information Specifications LCD Panel Size 17" (43 cm) Display Type Active matrix color TFT LCD Resolution 1280 x 1024 Display Dot 1280 x (RGB) x 1024 Display Area (mm) 337.92 x 270.336 (H x V) Display Color 262K Brightness (typical) 260 cd/m... -
Page 8: Standard Timing Table
Video Cable Environment Operating Condition: Storage Condition: Power Supply (AC Input) Input Voltage Input Current Size and Weight Dimensions Net Weight Gross Weight Pin Assignment Signal Description Green Blue Digital GND Digital GND Standard Timing Table If the selected timing is NOT included in table below, this LCD monitor will use the most suitable available timing. TIMING FH(KHZ) SYNC... -
Page 9: Troubleshooting
VESA-600-72Hz 72.188 800x600 46.875 VESA-600-75Hz 1024x768 48.363 – 60.004 – 1024x768 53.964 COMPAQ-XGA 66.132 1024x768 56.476 – VESA-768-70Hz 70.069 – 1024x768 60.023 VESA-768-75Hz 75.029 1024x768 60.24 – APPLE MAC-768 75.02 – 1152x864 54.054 (60Hz) 59.270 1152x864 63.851 (70Hz) 70.012 1152x864 67.50 (75Hz) 75.00...
