Chapter 10
How can
I do that?
For example,
in a small office, my PC can surf the internet through
Router A, but I also want to visit my company's network. Now I
have a switch and Router B. I connect the devices as shown in
the following figure so that the physical connection between my
PC and my company's server is established. To surf the internet
and visit my company's network at the same time, I need to
configure the static routing.
LAN: 192.168.0.1
1. Change the routers' LAN IP addresses to two different IP
addresses on the same subnet. Disable Router B's DHCP
function.
2. Visit http://tplinkwifi.net, and log in with the password you
set for Router A.
3. Go to
Advanced > Network
4. Click
Add
and finish the settings according to the following
explanations:
Customize Your Network Settings
Router A
Router B
LAN: 192.168.0.2
Switch
PC
192.168.0.100
>
Advanced
Company's server
WAN: 172.30.30.100
172.30.30.1
Routing.
52
