Juniper Secure Analytics Quick Start Guide
The instructions in this guide help you connect the Juniper Secure Analytics (JSA)
appliance to your network. For details, see the JSA Hardware Guide at
http://www.juniper.net/techpubs/en_US/release-independent/jsa/information-products/p
athway-pages/jsa-series/product/.
JSA Models
The following JSA appliances are available:
Appliance
Memory
Storage Configuration
JSA1500-BSE
24 GB
Two 1-TB HDDs, RAID1 mirror
JSA3500-BSE
32 GB
Six 1-TB HDDs, RAID10
JSA5500-BSE
96 GB
Eight 1-TB HDDs, RAID10
JSA7500-BSE
128 GB
28 drives of 900 GB HDDs, RAID10
JSA1500 Front Panel
Callout Description
1
Empty
2
Hard drive
3
IOC expansion slots
4
Network ports
5
USB port
Callout Description
6
Console port
7
Fault LED
8
Hardware disk activity LED
9
Power LED
JSA1500 Back Panel
Callout Description
1
Cooling fan
2
Power switch
JSA3500 Front Panel
Callout Description
1
Hard drive
2
IOC expansion slots
3
Network ports
4
USB port
Callout Description
3
Redundant power supply slot
4
Power supply
Callout Description
5
Console port
6
Fault LED
7
Hardware disk activity LED
8
Power LED
Advertisement
Related Manuals for Juniper JSA1500-BSE
Summary of Contents for Juniper JSA1500-BSE
- Page 1 Juniper Secure Analytics Quick Start Guide The instructions in this guide help you connect the Juniper Secure Analytics (JSA) JSA1500 Back Panel appliance to your network. For details, see the JSA Hardware Guide at http://www.juniper.net/techpubs/en_US/release-independent/jsa/information-products/p athway-pages/jsa-series/product/. JSA Models The following JSA appliances are available:...
- Page 2 JSA3500 Back Panel JSA5500 Back Panel Callout Description Callout Description Callout Description Callout Description Cooling fans Redundant power supply slot Cooling fans Redundant power supply Power switch Power supply Power switch Redundant power supply JSA5500 Front Panel JSA7500 Front Panel Callout Description Callout Description Power LED...
- Page 3 JSA7500 with Fan JSA7500 has internal hot-swappable cooling fans. See the following illustration for Callout Description Callout Description details on the fan location in JSA7500. Hard drive USB ports Network port 0 DB-9 Serial Console port Network port 1 Power switch Network port 2 Redundant power supply IOC expansion slots...
- Page 4 Insert the appliance coupler end of the power cord into the AC receptacle on the rear For more information on the appliance ID, see the KB article KB14832 at panel of the appliance. https://kb.juniper.net/KB14832. If your JSA contains two power supplies: Select normal from the following types of setup: Plug a power cord into each of the AC receptacles.
-
Page 5: Contacting Juniper Networks
<root password> is the new root password you set during the installation process. Click Login To JSA. The JSA interface appears. You are now ready to start tuning JSA and high availability (HA) settings. For more information, see the JSA Administration Guide. Contacting Juniper Networks For technical support, see www.juniper.net/support/requesting-support.html. Page... - Page 6 Juniper Networks, Inc. All other trademarks, service marks, registered trademarks, or registered service marks are the property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice. Products made or sold by Juniper Networks or components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S.
