14. Entry/exit
A trip starts entry delay 1. This zone bypasses
delay 1 with
when the group bypass command is entered at the
group bypass
keypad. The lack of a trip during exit delay enables
the automatic bypass or instant mode if
programmed.
15. Interior
This zone is instant when the system is armed and
follower with
no entry or exit delays are being timed. It is delayed
group bypass
during entry/exit delay times. This zone bypasses
when the group bypass command is entered at the
keypad. This zone automatically bypasses if
enabled in segment 1.
16. Instant with
This zone creates an instant alarm whenever it is
group bypass
tripped and the armed LED is on. This zone
bypasses when the group bypass command is
entered at the keypad.
17. Entry/exit
A trip starts entry delay 1. The lack of a trip during
delay 1 with
exit delay enables the automatic bypass or instant
tamper
mode if programmed. This zone type is used to
enable the tamper on a wireless transmitter.
18. Interior
This zone is instant when the system is armed and
follower with
no entry or exit delay is being timed. It is delayed
tamper and
during entry and exit delay times. This zone
autobypass
automatically bypasses if enabled in segment 1.
This zone type is used to enable the tamper on a
wireless transmitter.
19 Instant with
This zone creates an instant alarm whenever it is
tamper
tripped and the armed LED is on. This zone type is
used to enable the tamper on a wireless
transmitter.
20. Entry/exit
A trip starts entry delay 2. The lack of a trip during
delay 2 with
exit delay enables the automatic bypass or instant
tamper
mode if programmed. This zone type is used to
enable the tamper on a wireless transmitter.
21. Gas
This zone creates an instant alarm regardless of
detection
the armed state of the control panel. It displays on
the keypad and activates the keypad sounder.
22. Low
This zone creates an instant silent alarm regardless
temperature
of the armed state of the control panel. It displays
detection
on the keypad and activates the keypad sounder.
23. High
This zone creates an instant silent alarm regardless
temperature
of the armed state of the control panel. It displays
detection
on the keypad and activates the keypad sounder.
24. Manual fire
This zone illuminates the fire LED and sounds the
temporal siren each time the zone is shorted. It
also flashes (rapidly) the fire LED, indicating a
problem if the zone is open.
25. Chime only
This zone creates no alarm regardless of the
armed state of the control panel. It chimes anytime
it is faulted and displays on the keypad. Local only.
26. Interior
This zone is instant when the system is armed and
follower delay 2
no entry or exit delay is being timed. It is delayed 2
times during entry and exit. This zone automatically
bypasses if enabled in segment 1.
27. Interior
This zone is instant when the system is armed and
follower force
no entry or exit delay is being timed. It is delayed 1
armable
time during entry and exit. This zone automatically
bypasses if enabled in segment 1.
28. Entry/exit
A trip starts entry delay 2. The lack of a trip during
force armable
exit delay enables the automatic bypass or instant
delay 2
mode if programmed.
6
29. Interior
This zone is instant when the system is armed and
follower with
no entry or exit delay is being timed. It is delayed
activity
during entry and exit delay times. It sends a report
supervision
if the zone activity time is reached without a change
of state. This zone automatically bypasses if
enabled in segment 1.
30. Entry/exit
A trip starts entry delay 1. It sends a report if the
with activity
zone activity time is reached without a change of
supervision
state. The lack of a trip during exit delay enables
the automatic bypass or instant mode if
programmed.
Underwriters laboratories information
The NetworX NX-6V2 holds the following listings from
Underwriters Laboratories (US and Canadian)
UL365
Police station connected burglar alarms.
UL609,
Mercantile, police station connect with basic line
CAN/ULC-S303-
security requires NX-003-C enclosure
M91
UL985,
Household fire
CAN/ULC-S545-
M89
UL1023, ORD-
Household burglary
C1023-1974
UL1610
Central station burglar alarm unit
UL1635
Digital alarm communicator system units
UL1637
Home health care signaling
When installing an NX-6V2 in compliance with Underwriters
Laboratories, the following instructions must be observed:
•
Initiating and indicating devices must be rated at 11.5 to
12.4 VDC residential, 12.0 VDC commercial.
•
Force arming and auto arming must not be enabled.
•
For residential fire applications, the indicating devices
shall be a Wheelock 34T-12 or equivalent.
•
The listen in feature shall not be enabled.
•
The siren/bell test must be enabled. The auxiliary outputs
controlling the audible device require a minimum cutoff
time of 15 minutes for commercial burglary, four minutes
for residential applications, or 30 minutes for commercial
burglary for Canada.
•
For residential fire installations, the dynamic battery test
time cannot exceed four hours.
•
Ringback must be enabled on UL commercial burglary
installations.
•
On commercial burglary installations, the fire initiating
circuits must not be connected.
•
The entry guard feature must be disabled.
•
Group bypassing must be disabled.
•
Delay before dial seizure must be set to 0.
NX-6V2 Control Panel Installation Instructions
