- Page 1 ExtremeWireless™AP3000 Access Point Installation Guide 9037460-00 AA May 2023...
- Page 2 Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
-
Page 3: Table Of Contents
Install the Access Point on a Junction Box........................32 Install the Access Point on a Beam............................ 33 Connect a Power Supply................................35 Lock Your Access Point................................36 Post Installation....................................36 Regulatory and Compliance Information................38 Safety Guidelines....................................38 ExtremeWireless™AP3000 Access Point Installation Guide... - Page 4 UK Statement and CE Statement............................42 Industry Canada Notice................................43 Taiwan Regulatory Statement...............................44 European Waste Electrical and Electronic Equipment (WEEE) Notice..........44 Supplement to Product Instructions..........................45 Declaration of Conformity in Languages of the European Community..........45 Index..............................49 ExtremeWireless™AP3000 Access Point Installation Guide...
-
Page 5: Preface
Helpful tips and notices for using the product Note Useful information or instructions Important Important features or instructions Caution Risk of personal injury, system damage, or loss of data Warning Risk of severe personal injury ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 6: Documentation And Training
When a backslash separates two lines of a command input, enter the entire command at the prompt without the backslash. Documentation and Training Find Extreme Networks product information at the following locations: Current Product Documentation Release Notes ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 7: Help And Support
Extreme Optics Compatibility Other resources such as white papers, data sheets, and case studies Extreme Networks offers product training courses, both online and in person, as well as specialized certifications. For details, visit www.extremenetworks.com/education/. Help and Support If you require assistance, contact Extreme Networks using one of the following... -
Page 8: Send Feedback
You can modify your product selections or unsubscribe at any time. Send Feedback The Information Development team at Extreme Networks has made every effort to ensure that this document is accurate, complete, and easy to use. We strive to improve our documentation to help you in your work, so we want to hear from you. -
Page 9: Ap3000 Overview
• Extreme IQ Controller The AP3000 ships with the AH-ACC-BKT-AX-TB mounting bracket for mounting the AP to a flat t-bar with flat ceiling tiles, flat surface, or a wall. You do not have to use a country-specific SKU unless you are ordering for Israel or Egypt. -
Page 10: Product Specifications
Product Specifications AP3000 Overview Figure 1: The AP3000 Access point Product Specifications The AP3000 access point supports both PoE 802.3af and 802.3at. It is supported on the following platforms: • ExtremeCloud™ IQ • Extreme IQ Controller Antennas The AP3000 has the following internal antennas: •... -
Page 11: Ports And Connectors
• One software reset button Hardware Ports The AP3000 has several ports and hardware features to help you when you install the access point. Use the following diagrams and locate the ports and other hardware features. ExtremeWireless™AP3000 Access Point Installation Guide... - Page 12 Hardware Ports AP3000 Overview Figure 2: AP3000 Hardware ports Table 5: AP3000 Ports and Connections Item Port Description 12VDC 12-volts of direct current. ETH1 port 1GB/1GE/100/10. ETH0/PoE+ port 2.5GE/1GE/100 with PoE In. ExtremeWireless™AP3000 Access Point Installation Guide...
-
Page 13: Led Status
Use the port when you troubleshoot the AP. The best practice is to use the Extreme Networks micro USB cable (ACC-WIFI-MICRO-USB). When you connect to the device, the management station must have a VT100 emulation program, such as the terminal emulator TeraTerm Pro or Hilgraeve HyperTerminal. - Page 14 LED State Description Dark The AP is not being powered or the LED is turned off from the controller. Solid white The AP is starting up and a connection is being established to ExtremeCloud IQ Controller. ExtremeWireless™AP3000 Access Point Installation Guide...
-
Page 15: Power Profile
A firmware upgrade is in progress. Fast-blinking amber The AP is acquiring Dynamic Host Configuration Protocol (DHCP) IP address. Power Profile The following table shows the AP3000 power profile. Use this information when you plan your installation. Table 9: AP3000 power profile AP3000 AF profile... -
Page 16: Supported Power Accessories
AP with an external power supply, you can purchase a 12V DC power supply. There is no wall mount bracket for the 12VDC power supply. Table 11: Power accessories Part number Description 37215 PWR 12VDC, 2A (24W), 2.5 mm X 5.5 mm connector ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 17: Other Accessories
(provided with Windows operating systems from XP forward). Figure 5: Micro-B model Console Port Pin Information Table 12: Micro-B USB Pin Information Pin number Pin name and description R×D (input to access point) T×D (output to terminal) Signal (GND) Signal (GND) ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 18: Mac Address
Non-abrasive soap Note Do not wash the AP3000. You will damage the device and void the warranty. Instead you can wipe the radome with a damp cloth. But you must avoid the ports and connectors. Do not power wash the AP. -
Page 19: Purchase Order Information
AP3000 Overview Purchase Order Information Purchase Order Information The AP3000 access point is sold with the AH-ACC-BKT-AX-TB mounting bracket. Use the information below when you order the AP. Table 13: Access point part number Part number Description AP3000-WW Indoor Dual Radio Wi-Fi 6E AP, 2.4 GHz and 5 GHz or 5GHz and 6GHz, Multirate Port, Internal antennas. -
Page 20: Access Point Installation
36 Post Installation on page 36 The AP3000 access point is an indoor access point that can be installed on a ceiling rail, on non-standard ceilings, and on a wall. For more information about selecting the Extreme right access point bracket and accessory for your installation needs, see the Networks 11.ax Access Points Accessories Guide . -
Page 21: Installation Work Flow
Confirm that you have received the following items before you install your device. Table 15: Hardware Quantity Item Extreme AP 3000 access point Quick reference guide for your access point AH-ACC-BKT-AX-TB mounting bracket Phillips pan head wood screws Screw-in anchors ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 22: Install The Access Point On A Wall Or A Flat Ceiling
Use the AH-ACC-BKT-AX-WL bracket when you need a 1.25 inch space between the wall and the access point. Procedure 1. Using the -WL bracket as a template, mark and drill mounting holes on the wall. ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 23: Install The Access Point On A Silhouette Ceiling
You need the following items: • AP3000 • AH-ACC-BKT-AX-SL bracket About This Task You can mount the access point to a ceiling grid with 1/8 in. or 1/4 in. bottom opening. Silhouette is an Armstrong Ceiling Solutions name. ExtremeWireless™AP3000 Access Point Installation Guide... - Page 24 Gently rotate the bracket counterclockwise and if there is resistance, the other white tab in the back of the accessory must also be released. ExtremeWireless™AP3000 Access Point Installation Guide...
- Page 25 4. Align the red dot on the back of the access point against the accessory bracket red dot. Note The accessory has a circular tip that fits into the circular depression on the back of the access point. ExtremeWireless™AP3000 Access Point Installation Guide...
-
Page 26: Install The Access Point To A 9/16Th T-Bar Ceiling
You need the following items: • AP3000 • One AH-ACC-BKT-AX-IL accessory bracket About This Task You can mount the access point to a ceiling that has a 9/16 in. wide T-bar with a center protrusion. ExtremeWireless™AP3000 Access Point Installation Guide... - Page 27 Gently rotate the bracket counterclockwise and if there is resistance, the other white tab in the back of the accessory must also be released. ExtremeWireless™AP3000 Access Point Installation Guide...
- Page 28 4. Align the red dot on the back of the access point against the accessory red dot. Note The bracket has a circular tip that fits into the circular depression on the back of the access point. ExtremeWireless™AP3000 Access Point Installation Guide...
-
Page 29: Install The Access Point On A 15/16-Inch T-Bar
Obtain the following items: • One AP3000 • One ACC-BKT-TB-NF adapter • One AH-ACC-BKT-AX-TB accessory About This Task Use the ACC-BKT-TB-NF bracket when you install the AP on a suspended ceiling with 15/16-inch grid system. ExtremeWireless™AP3000 Access Point Installation Guide... - Page 30 Center the -TB accessory on the attached -NF parts. b. Push up and rotate the -TB accessory clockwise until the metal hinges hook over the bottom halves of the -NF adapter ends and the plastic tabs on the -TB accessory click into place. ExtremeWireless™AP3000 Access Point Installation Guide...
- Page 31 6. Press and rotate the access point one-eighth of a turn clockwise until it clicks into place on the accessory. 7. Connect the network cable. 8. Replace the ceiling tiles. ExtremeWireless™AP3000 Access Point Installation Guide...
-
Page 32: Install The Access Point On A Junction Box
A metal part that attaches to the junction box (also called the sheet-metal junction box hole plate) Figure 15: ACC-BKT-AX-JB accessory bracket metal part • A plastic part that attaches to the metal part and the access point (also called the plastic twist plate) ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 33: Install The Access Point On A Beam
• AP3000 • ACC-BKT-AX-BEAM mounting bracket Find a location that supports the following requirements: • The beam must be able to support the access point in all environmental conditions. • The beam must be flat. ExtremeWireless™AP3000 Access Point Installation Guide... - Page 34 5. Open the top screw as necessary and place the beam clip onto a beam. Note You must hold the access point when attaching the beam clip. Figure 17: ACC-BKT-AX-BEAM accessory bracket 6. Tighten the beam clip top screw to a torque of 50 in-lbs. ExtremeWireless™AP3000 Access Point Installation Guide...
-
Page 35: Connect A Power Supply
Power Profile for power consumption specifications. Note Power over Ethernet (PoE) is disabled when you use an external power supply. Figure 18: AP3000 Power connector Procedure Plug the power supply into the 12-volt power connector. The LED lights up. ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 36: Lock Your Access Point
AP to meet your needs and assign it to one or more Virtual Network Services (VNS). You can also modify the settings for each radio on the AP. ExtremeWireless™AP3000 Access Point Installation Guide... - Page 37 Access Point Installation Post Installation Each AP has a tab in the controller where you can find the settings and configurations. You can configure both individual APs or a group of APs. ExtremeWireless™AP3000 Access Point Installation Guide...
-
Page 38: Regulatory And Compliance Information
A qualified person understands the requirements and risks involved with installing outdoor electrical equipment in accordance with national codes. ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 39: Professional Installation Instruction
FCC Notice (Part 15 - Class B) This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 40: Fcc Radiation Exposure Statement
Warning This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 47 cm between the radiator and your body. ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 41: Conformitè Europëenne (Ce) Information
The operation of this equipment is subject to the following two conditions: 1. it is possible that this equipment or device does not cause disruptive interference 2. this equipment or device must accept any interference, including interference that may cause undesired operation. ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 42: Extreme Networks Eu Importer Address
UK - The device is restricted to indoor use only when operating in the 5945 to 6425 MHz frequency range. Hereby, Extreme Networks declares that the radio equipment AP3000 is in compliance with Radio Equipment Regulations 2017. Operation on oil platforms, cars, trains, boats, and aircraft shall be prohibited except for on large aircraft flying above 10,000 ft. -
Page 43: Industry Canada Notice
Radio Frequency (RF) exposure. This device was tested with a separation distance of 31 mm. Always keep the device away from your body to ensure exposure levels remain at or below the tested levels. ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 44: Taiwan Regulatory Statement
4. It is the user's responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please contact Extreme Environmental Compliance at Green@extremenetworks.com. ExtremeWireless™AP3000 Access Point Installation Guide... -
Page 45: Supplement To Product Instructions
Supplement to Product Instructions Declaration of Conformity in Languages of the European Community English Hereby, Extreme Networks declares that the radio equipment type (AP3000) is in compliance with Directive 2014/53/EU. For full text of the EU Declaration of Conformity, contact Extreme Regulatory Compliance at compliancerequest@extremenetworks.co... - Page 46 European Community Regulatory and Compliance Information Dutch Hierbij verklaart Extreme Networks dat het toestel Radio LAN device (AP3000) in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 2014/53/EU. Neem voor de volledige tekst van de EU-...
- Page 47 Declaration of Conformity in Languages of the Regulatory and Compliance Information European Community Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Extreme Networks ΔΗΛΩΝΕΙ ΟΤΙ Radio LAN device (AP3000) ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 2014/53/EU. Για το πλήρες κείμενο της δήλωσης συμμόρφωσης ΕΕ, παρακαλούμε...
- Page 48 European Community Regulatory and Compliance Information Portuguese Extreme Networks declara que este Radio LAN device (AP3000) está conforme com os requisitos essenciais e outras disposições da Directiva 2014/53/EU. Para o texto integral da declaração de conformidade da UE, contacte a conformidade regulamentar extrema em compliancerequest@extremenetworks.co...
-
Page 49: Index
Index access point features 10, 11 junction box installation 32 access point overview 9 announcements 7 AP3000 access point overview 9 MAC address location 18 AP3000 features 10, 11 Media Access Control address (MAC address) 18 Mexico compliance statement 41... - Page 50 Index technical support contacting 7 UK address 42 wall installation with AH-ACC-BKT-AX-WL 22 warnings 5...
