Extreme Networks AP60C Hardware User's Manual

AP60C Hardware Guide
AP460C Hardware User Guide
Read about and view specifications and compliance information for the AP460C devices in this topic. Install the AP460C devices using this topic.
The AP460C is a Tri Radio 802.11ax access point based on advanced radio technology and is IP67 rated for harsh and extreme outdoor envir-
onments, with an extended temperature range (-40 C - +60 C). The AP460C tri-radio design delivers 802.11ax 2x2:2 and 4x4:4 data rates con-
currently on the 2.4 and 5 GHz radios, and has a third radio for a dedicated dual-band sensor.
For regulatory and compliance information, see "Regulatory Compliance Statements".
Important! Change the Country Code
If your access point is configured for the World Regulatory Domain, it is important to set the country code to the country in which the AP will be
deployed to meet regulatory requirements and for optimal wireless operation. To do this, follow these steps:
The country code selection is for World models only and is not available to FCC, CAN, and other country-specific models. Per FCC reg-
ulations, all Wi-Fi products marketed in the United States must be set to U.S. channels only.
1. Power on the AP and allow it to find and connect to ExtremeCloud IQ. Once the AP is connected it appears in the table of devices on the
Manage > Devices page.
2. Select the check box next to the AP, and then choose Assign Country Code from the Actions drop-down list. In the dialog box, select the
appropriate country from the drop-down list, and then click Save.
3. Upload your changes to the device.
Safety Guidelines
Safety Guidelines
The information in this section applies to AP460C devices.
The following safety icons are used in these guidelines to identify the type of precaution:
AP460C Hardware Guide
