2 . P a n e l E
2 . P a n e l E
2 . 1 V i g o r 2
2 . 1 V i g o r 2
LED
(Act ivit y)
(DSL)
(Wireless LAN
On/ Of f / WPS)
(Wireless LAN
On/ Of f / WPS)
~
(LAN1/ 2/ 3/ 4)
(USB)
x p l a n a t i o
x p l a n a t i o
7 6 5 a c / V i g o r 2
7 6 5 a c / V i g o r 2
Status Explanation
Blinking The rout er is ready and operat ing normally
Of f The rout er is powered of f
On DSL connect ion synchronised
Blinking DSL connect ion not current ly synchronizing or
(Slowly) not det ect ed
Blinking DSL connect ion is synchronising
(Quickly)
On (Green) 2. 4GHz Access Point is act ive
Blinking Dat a is being t ransmit t ed on t he rout er' s 2. 4
(Green) GHz wireless int erf ace
Blinking WPS pairing mode is act ive f or t wo minut es
(Orange)
Of f 2. 4GHz Access Point is t urned of f
On (Green) 5GHz Access Point is act ive
Blinking Dat a is being t ransmit t ed on t he rout er' s 5GHz
(Green) wireless int erf ace
Blinking WPS pairing mode is act ive f or t wo minut es
(Orange)
On Et hernet LAN (RJ45) is connect ed
Blinking Dat a is t ransmit t ing (sending/ receiving)
Of f Et hernet LAN is disconnect ed
On USB device is connect ed and ready f or use
Blinking Dat a is being t ransmit t ed over USB
n
n
7 6 6 a c
7 6 6 a c
