Chapter 1

Mainboard Specification

CPU
Socket 478 for P4 processors (Willimate 478 and Northwood 478) with 400/
533 MHz (100/133MHz QDIR)
Core frequency from 1.7GHz to 2.53 GHz and up
Chipset
SiS 645DX/650GX/651 HMAC/IGUI HMAC /IGUI HMAC (702 pin BGA)
®
- High performance host interface 400/533 (645 DX and 651 only) MHz
- Support 64-bit high performance DDR333 (645 DX and 651 only) /
DDR266/DDR 200 and PC133/100 memory controller
- Support AGP 4X/2X interface with fast write transaction
- High throughput SiS HyperZip connect to SiS962L/962 HyperZip Media
I/O
- High performance 2D/3D and Video Accelerator (650GX and 651 only)
- Complete TV-out/Digital flat panel solution and MPEG-2/1 Video
decoder (651 only)
SiS 962L/962 HyperZip Media I/O (371BGA)
®
- High performance HyperZip connect to Sis series NB
- Integrated multi-threaded I/O link ensures concurrency of up/down stream
data transfer with 1.2GB/s bandwidth
- Integrated HyperZip connect to PCI bridge
- Dual IDE Master/Slave controller
- Integrated USB 2.0/1.1 host controller and Fast Ethernet MAC controller
- Integrated audio controller with AC97 interface
- Advanced power management and PC2001 compliance
- Integrated RTC and DMA interrupt and keyboard controller
- Integrated PCI to LPCC bridge
- Integrated IEEE 1394 Host controller (SiS962 only)
Main Memory
Supports four memory banks using two 184-pin unbuffered DDR DIMM.
Supports up to 2GB memory size.
Slots
One AGP (Accelerated Graphics Port) 2X/4X slot.
Three PCI 2.2 32-bit PCI bus slots (support 3.3V/5V PCI bus interface).
One CNR (Communication Network Riser) slot.
1-2
