Summary of Contents for Electrolux EOD5H70BZ
- Page 1 User Manual Oven EOD5H70BZ KODEC70BZ electrolux.com/register...
-
Page 2: Table Of Contents
WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. -
Page 3: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. -
Page 4: Safety Instructions
similar accommodation where such use does not exceed (average) domestic usage levels. Only a qualified person must install this appliance and • replace the cable. Do not use the appliance before installing it in the built-in • structure. Disconnect the appliance from the power supply before •... - Page 5 • The appliance is equipped with an electric replaced, this must be carried out by our cooling system. It must be operated with Authorised Service Centre. the electric power supply. • Do not let mains cables touch or come near the appliance door or the niche below the appliance, especially when it Cabinet minimum height 580 (600) mm...
- Page 6 2.3 Use • Always cook with the appliance door closed. • If the appliance is installed behind a WARNING! furniture panel (e.g. a door) make sure the Risk of injury, burns and electric door is never closed when the appliance shock or explosion.
-
Page 7: Installation
• This product contains a light source of • Contact your municipal authority for energy efficiency class G. information on how to dispose of the • Use only lamps with the same appliance. specifications. • Disconnect the appliance from the mains supply. -
Page 8: Product Description
3.2 Securing the oven to the cabinet 4. PRODUCT DESCRIPTION 4.1 General overview Control panel Power lamp / symbol Knob for the heating functions Display Control knob (for the temperature) Temperature indicator / symbol Air vents for the cooling fan Heating element Lamp Shelf support, removable... -
Page 9: Before First Use
5.2 Sensor fields / Buttons To set the time. To set a clock function. To set the time. 5.3 Display A. Clock functions B. Timer 6. BEFORE FIRST USE WARNING! Refer to Safety chapters. 6.1 Before first use The oven can emit an odour and smoke during preheating. Make sure that the room is ventilated. -
Page 10: Daily Use
7. DAILY USE WARNING! Step 2 Turn the control knob to select the tem‐ Refer to Safety chapters. perature. Step 3 When the cooking ends, turn the knobs 7.1 How to set: Heating function to the off position to turn off the oven. Step 1 Turn the knob for the heating functions to select a heating function. -
Page 11: Clock Functions
Heating func‐ Application Heating func‐ Application tion tion To add humidity during the To roast large meat joints or cooking. To get the right colour poultry with bones on one shelf and crispy crust during baking. position. To make gratins and to True Fan Cooking Turbo Grilling To give more juiciness during... - Page 12 8.2 How to set: Clock functions How to set: Time of Day - flashes when you connect the oven to the electrical supply, when there was a power cut or when the timer is not set. - press to set the time. After approximately 5 sec., the flashing stops and the display shows the time.
-
Page 13: Using The Accessories
9. USING THE ACCESSORIES devices. The high rim around the shelf WARNING! prevents cookware from slipping of the shelf. Refer to Safety chapters. 9.1 Inserting accessories A small indentation at the top increases safety. The indentations are also anti-tip Wire shelf: Push the shelf between the guide bars of the shelf support and make sure that the feet point down. -
Page 14: Additional Functions
Step 1 Mount the telescopic runners on the shelf Step 2 Make sure that the telescopic runner's supports. tip (A) points upward. 10. ADDITIONAL FUNCTIONS 10.1 Cooling fan 10.2 Safety thermostat When the appliance operates, the cooling fan Incorrect operation of the oven or defective turns on automatically to keep the surfaces of components can cause dangerous the appliance cool. - Page 15 cooking time, etc.) for your cookware, recipes and quantities when you use this appliance. 11.2 Moist Fan Baking - recommended accessories Use the dark and non-reflective tins and containers. They have better heat absorption than the light colour and reflective dishes. Ramekins Pizza pan Baking dish...
- Page 16 (°C) (min) Muffins, 12 pieces baking tray or dripping pan 30 - 40 Savory pastry, 16 baking tray or dripping pan 35 - 45 pieces Short crust biscuits, 20 baking tray or dripping pan 40 - 50 pieces Tartlets, 8 pieces baking tray or dripping pan 20 - 30 Vegetables, poached,...
-
Page 17: Care And Cleaning
12. CARE AND CLEANING WARNING! Refer to Safety chapters. 12.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild de‐ tergent. Clean and check the door gasket around the frame of the cavity. Use a cleaning solution to clean metal surfaces. - Page 18 Step 1 Turn off the oven and wait until it is cold. Step 2 Pull the front of the shelf support away from the side wall. Step 3 Pull the rear end of the shelf support away from the side wall and remove Step 4 Install the shelf supports in the oppo‐...
- Page 19 Step 2 Lift and pull the latches until they click. Step 3 Close the oven door halfway to the first opening position. Then lift and pull to remove the door from its seat. Step 4 Put the door on a soft cloth on a stable sur‐ face and release the locking system to re‐...
-
Page 20: Troubleshooting
Step 8 After cleaning, install the glass panel and the oven door. If the door is installed correctly, you will hear a click when closing the latches. When installed correctly the door trim clicks. Make sure that you install the internal glass panel in the seats correctly. -
Page 21: Energy Efficiency
......... Serial number (S.N.) ......... 14. ENERGY EFFICIENCY 14.1 Product Information and Product Information Sheet Supplier's name Electrolux EOD5H70BZ 944068341 Model identification KODEC70BZ 944068340 Energy Efficiency Index 95.1 Energy efficiency class Energy consumption with a standard load, conventional mode 0.89 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.78 kWh/cycle... -
Page 22: Environmental Concerns
14.2 Energy saving Residual heat When the cooking duration is longer than 30 min, reduce the appliance temperature to The appliance has features minimum 3 - 10 min before the end of which help you save energy cooking. The residual heat inside the during everyday cooking. - Page 24 electrolux.com...
